Jet Profile300LT
300W LT Profile Moving head, with
4° - 44° zoom and CMY
USER MANUAL
English version
Rev.01 - Preliminary

Advertisement

loading
Need help?

Need help?

Do you have a question about the Jet Profile300LT and is the answer not in the manual?

Questions and answers

Related Manuals for ProLights Jet Profile300LT

Summary of Contents for ProLights Jet Profile300LT

  • Page 1 Jet Profile300LT 300W LT Profile Moving head, with 4° - 44° zoom and CMY USER MANUAL English version Rev.01 - Preliminary...
  • Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
  • Page 3 20 - MODULE REMOVAL (ANIMATION, COLOR, GOBOS WHEEL) 21 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............44 REPLACING THE FUSE ....................44 VISUAL CHECK OF PRODUCT HOUSING ..............44 RESETTING THE MAINTENANCE TIME MESSAGE ............45 PROLIGHTS - Jet Profile300LT...
  • Page 4 • Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center.
  • Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
  • Page 6 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - Jet Profile300LT...
  • Page 7 Check the updated accessories list, description and informations of the product at the following link: https://www.prolights.it/product/JETPROFILE300#accessories 2 - TECHNICAL DRAWING Ø491mm 232mm [9.1in] [19.3in] 403mm 250mm 429mm [15.9in] [9.8in] [16.9in] Fig. 01 Weight: 21,4 kg - 47,18 lbs PROLIGHTS - Jet Profile300LT...
  • Page 8 3 - PAN AND TILT LOCK PAN Mechanism lock and release LOCK UNLOCK TILT Mechanism lock and release LOCK UNLOCK Fig. 02 PROLIGHTS - Jet Profile300LT...
  • Page 9 Warning! When clamping the fixture to a truss or other structure at any angle, use clamps of half-cou- pler type. Do not use any type of clamp that does not completely encircle the structure when fastened. Steel security cable C6002 clamp OS24 PLUS 108 [4.3] Fig.03 PROLIGHTS - Jet Profile300LT...
  • Page 10 • Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - Jet Profile300LT...
  • Page 11 4. DMX IN/OUT (5-p XLR): 1 = GND, 2 = sign-, 3 = sign+, 4 N/C, 5 N/C. 5. MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only (T6.25A 250V). 6. POWER IN/OUT: for connection to the Mains 100-240V~/50-60Hz. 7. SAFETY EYES: to attach safety cable. Fig 04 PROLIGHTS - Jet Profile300LT...
  • Page 12 ... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 06 - Example 46 DMX channels configuration PROLIGHTS - Jet Profile300LT...
  • Page 13 2. Reach the addressing menu, then select the DMX ADDRESS settings. 3. Select the address from 1 to 512 using the navigation arrows/buttons and confirm by pressing ENTER. 4. Press Menu to exit and return to the Home screen. PROLIGHTS - Jet Profile300LT...
  • Page 14 • Switch on the display using backup battery. Hold for 5s. • Switch off display by pressing button 4 for 5s while on being on Home screen. • USB port for Firmware Upgrade. PROLIGHTS - Jet Profile300LT...
  • Page 15 SLOW To set the home position. HOME POSITION STANDARD CUSTOM Check pag.18 for further details. DIMMER DIMMER CURVE LINEAR S-CURVE SQUARE LAW INVERSE SQUARE LAW AUTO DIMMER SPEED Check pag.19 for further details. FAST MEDIUM SLOW PROLIGHTS - Jet Profile300LT...
  • Page 16 2000 Hz 4000 Hz 6000 Hz 25 kHz 50 kHz RESET To reset these functions. TILT PAN & TILT COLOR1 COLOR2 COLOR3 ROT GOBO ZOOM FOCUS PROLIGHTS - Jet Profile300LT...
  • Page 17 R GOBO 1 FOCUS … R GOBO 7 FOCUS R GOBO 1 INDEX … R GOBO 7 INDEX CYAN MAGENTA YELLOW FRAME ROT BLADE 1 POSITON BLADE 1 ROT … BLADE 4 POSITON BLADE 4 ROT PROLIGHTS - Jet Profile300LT...
  • Page 18 ANIMATION ROTATION FRAME ROT BLADE 1 POSITON BLADE 1 ROT … BLADE 4 POSITON BLADE 4 ROT CONTROL RELOAD DEFAULT BASIC RELOAD Default of all parameters excepted Calibra- tion FACTORY RELOAD Delete all USER PRESETS stored PROLIGHTS - Jet Profile300LT...
  • Page 19 ERROR MESSAGE Show error message DEVICE LABEL Show RDM Label. JETPROFILE300LT DEVICE MODEL Show RDM fixture model JETPROFILE300LT RDM UID Show RDM UID of the fixture. SOFTWARE Show firmware version of the fixture 1U01 V1.0.00... VERSION PROLIGHTS - Jet Profile300LT...
  • Page 20 3. SQUARE LAW - Light intensity is finer at low levels and becomes coarser at higher levels. 4. INVERSE SQUARE LAW - Light intensity is coarser at low levels and finer at higher levels. LINEAR S-CURVE DMX % DMX % SQUARE LAW INVERSE SQUARE LAW DMX % DMX % PROLIGHTS - Jet Profile300LT...
  • Page 21 220 + PAN FINE This Reload also reset DMX address and mode. This CHANNEL SET TO 255, Basic Reload combination need to be performed while fixture is within 3s PAN FINE need resetting to be set to 0 PROLIGHTS - Jet Profile300LT...
  • Page 22 0x0122 DMX_BLOCK_ADDRESS 0x0140 DMX_FAIL_MODE 0x0141 DMX_STARTUP_MODE 0x0142 SENSOR_DEFINITION 0x0200 Sensors SENSOR_VALUE 0x0201 RECORD_SENSORS 0x0202 DIMMER_INFO 0x0340 MINIMUM_LEVEL 0x0341 MAXIMUM_LEVEL 0x0342 CURVE 0x0343 Dimmer Settings CURVE_DESCRIPTION 0x0344 OUTPUT_RESPONSE_TIME 0x0345 OUTPUT_RESPONSE_TIME_ DESCRIPTION 0x0346 MODULATION_FREQUENCY 0x0347 MODULATION_FREQUENCY_ DESCRIPTION 0x0348 PROLIGHTS - Jet Profile300LT...
  • Page 23 PAN_TILT_SWAP 0x0602 Configuration REAL_TIME_CLOCK 0x0603 LOCK_PIN 0x0640 LOCK_STATE 0x0641 LOCK_STATE_DESCRIPTION 0x0642 IDENTIFY_DEVICE 0x1000 RESET_DEVICE 0x1001 POWER_STATE 0x1010 PERFORM_SELFTEST 0x1020 SELF_TEST_DESCRIPTION 0x1021 CAPTURE_PRESET 0x1030 Control PRESET_PLAYBACK 0x1031 IDENTIFY_MODE 0x1040 PRESET_INFO 0x1041 PRESET_STATUS 0x1042 PRESET_MERGEMODE 0x1043 POWER_ON_SELF_TEST 0x1044 PROLIGHTS - Jet Profile300LT...
  • Page 24 1: Custom CURRENT_HOURS 0x82C5 0-65535 0: No CLEAN_ALL_DATA 0x82C8 1: Yes 0: Hold DMX_FAULT 0x82DD 1: Blackout MAINTENANCE_T_ALERT_PERIOD 0x82DF MAINTENANCE_T_ELAPSED_TIME 0x82E0 0: No error 1: Bus display TX fail ERROR_MESSAGE 0x82EA 38: Prism 6s Index POWER_CONSUMPTION 0x82EF PROLIGHTS - Jet Profile300LT...
  • Page 25 Tilt = 128 Tilt = 255 Tilt movement range: 260° Pan movement range: 540° Pan = 0 Pan = 128 Pan = 255 Tilt = 42 Tilt = 42 Tilt = 42 Display Display Display Fig. 09 PROLIGHTS - Jet Profile300LT...
  • Page 26 3. As you adjust the zoom, the focus will automatically follow, keeping the projection focused. 4. If you select a different function via channel 35/39 ("Focus Tracking"), the focus will automatically adjust to track the new selection. PROLIGHTS - Jet Profile300LT...
  • Page 27 Color Wheel 2 Blade 4 position Fine Positioning Blade 4 swivelling Rot Gobo Wheel Frame rotation Gobo Rot Frame macros Gobo Rot Fine Frame macros speed Prism 1 Focus Tracking Prism 1 Index/Rot Control Prism 2 PROLIGHTS - Jet Profile300LT...
  • Page 28 High Cri + Lavander Lavander Lavander + Cyan Cyan Color Wheel 1 Color Slot Open Dark Red High Cri Lavander Cyan Color Wheel Rotation Forward rainbow - Fast to slow No rotation Backwards rainbow - Slow to fast PROLIGHTS - Jet Profile300LT...
  • Page 29 Color Wheel 2 Color Slot Open Dark Blue Light Orange Light Green Magenta Color Wheel Rotation Forward rainbow - Fast to slow No rotation Backwards rainbow - Slow to fast Color Wheel 2 Fine positioning Fine Positioning PROLIGHTS - Jet Profile300LT...
  • Page 30 Backwards rotation - Slow to fast Gobo Indexing Gobo index 0° - 360° Gobo Rotation Gobo Rot No rotation Forward gobo rotation - Fast to slow No rotation Backwards gobo rotation - Slow to fast Gobo Rot Fine Fine indexing/rotation PROLIGHTS - Jet Profile300LT...
  • Page 31 Swivelling from -30° towards 0° Blade 1 0 degrees swivelling Swivelling from 0° towards +30° Blade 2 position Movement from outward to inward Swivelling from -30° towards 0° Blade 2 0 degrees swivelling Swivelling from 0° towards +30° PROLIGHTS - Jet Profile300LT...
  • Page 32 Blade 4 position Movement from outward to inward Swivelling from -30° towards 0° Blade 4 0 degrees swivelling Swivelling from 0° towards +30° -45 degrees to 0 degrees Frame rotation 0 degrees 0 degrees to +45 degrees PROLIGHTS - Jet Profile300LT...
  • Page 33 Macro 23 Macro 24 Macro 25 Macro 26 Macro 27 Macro 28 Macro 29 Macro 30 Macro 31 Macro 32 Macro 33 Macro 34 Macro 35 Macro 36 Frame macros Lineary from 0 to 100% speed PROLIGHTS - Jet Profile300LT...
  • Page 34 Display 10s Display 20s Display 30s Flip display on Flip display off Flip display auto Key lock on Key lock off Fan mode auto Fan mode silent Fan mode high No signal hold No signal blackout PROLIGHTS - Jet Profile300LT...
  • Page 35 Reset blade 1 rot Reset blade 2 positon Reset blade 2 rot Reset blade 3 positon Reset blade 3 rot Reset blade 4 positon Reset blade 4 rot Reset frame rot Reserved Factory default of control functions Reserved PROLIGHTS - Jet Profile300LT...
  • Page 36 • Ø of image (ID)= 16,0 mm • Thinckness= up to 3 mm OD = Ø20 mm [0.8 in] Up to 3 mm [0.12 in] ATTENTION! Load with mirror surface toward the light source. Fig. 10 PROLIGHTS - Jet Profile300LT...
  • Page 37 15 - COLOR WHEEL CYAN - COLOR WHEEL 1 MAGENTA - COLOR WHEEL 2 DARK BLUE LAVANDER LIGHT 6000K ORANGE CRI 85 LIGHT DARK GREEN YELLOW - COLOR WHEEL 3 LINEAR CTO UP TO 2800K Fig. 12 PROLIGHTS - Jet Profile300LT...
  • Page 38 16 - ANIMATION WHEEL Fig. 13 PROLIGHTS - Jet Profile300LT...
  • Page 39 Color wheel 3 (yellow/cto) sensor/motor/driver failure 4U GOBO WHEEL Gobo wheel sensor/motor/driver failure 4U GOBO INDEX Rotating Gobo Index Sensor/Motor/Driver Fault 4U ANIMATION Animation sensor/motor/driver failure 4U FAN1 EFFECTS speed < 1000 rpm BUS 4U GOBO+COLOR 4U card not responding PROLIGHTS - Jet Profile300LT...
  • Page 40 BUS 6U FOCUS+ZOOM 6U card not responding NTC LED MODULE ntc led module fault NTC LED DRIVER ntc fault on led driver board FIRMWARE MISMATCH at least one card has a different fw than the display card PROLIGHTS - Jet Profile300LT...
  • Page 41 IDENTIFICATION OF ELECTRONIC BOARDS 6U PCB 5U PCB 2U PCB 3U PCB 6U PCB 5U PCB 4U PCB 1U PCB Fig. 13 PROLIGHTS - Jet Profile300LT...
  • Page 42 AND TILT LOCK" paragraph (pag. 6). Loosen and remove the marked screws and opening the head covers (1) from both sides. Unclip the safety cable on both sides (2). Fig. 14 PROLIGHTS - Jet Profile300LT...
  • Page 43 Gently remove the gobo holder from the gobo wheel (3, 4). Remove the spring and the gobo (5, 6). NOTE: the mirrored part of the gobo must be placed in the direction of the LED Source Fig. 15 PROLIGHTS - Jet Profile300LT...
  • Page 44 • Disconnect the two connectors, power and serial bus plugs (marked A in drawing 2.1); • Unscrew the two screws marked in the front view (marked B in drawing 2.2); • Remove the plate with gobo wheels raising it up (C) and then pulling out (D) (drawing 2.2). Fig. 16 PROLIGHTS - Jet Profile300LT...
  • Page 45 PROLIGHTS - Jet Profile300LT...
  • Page 46 WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel.
  • Page 47 • Check if the Fuse is intact and eventually replace it if fault necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in...
  • Page 48 Note...
  • Page 50 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
