- Page 1 Jet Wash7 7x20W RGBW moving wash light with a 4°- 56° zoom USER MANUAL English version REV.01-04/22...
- Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
-
Page 3: Table Of Contents
14 - ACCESSORIES INSTALLATION EGG CRATE (ASTRAW7PEC - OPTIONAL)..............23 15 - PERIODICAL CLEANING 16 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............25 REPLACING THE FUSE ....................25 VISUAL CHECK OF PRODUCT HOUSING ..............25 TROUBLESHOOTING ..................... 26 PROLIGHTS - Jet Wash7... -
Page 4: Safety Information
• Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. - Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
- Page 6 4. This device must accept any interference received, including interference that may cause undesired operation. Other approvals • The product meets the safety requirements of the certification procedures of the market in which it is placed and sold. PROLIGHTS - Jet Wash7...
-
Page 7: Packaging
• ASTRAW7PEC: egg Crate for ASTRAWASH7PIX / JETWASH7; • OS24: quick-lock omega bracket; • UPBOX2: firmware uploader kit, USB IN, 3-pin XLR DMX OUT. 2 - TECHNICAL DRAWING Fig. 01 Weight: 8.3 kg - 18.29 lbs PROLIGHTS - Jet Wash7... -
Page 8: Installation
Warning! When clamping the fixture to a truss or other structure at any angle, use clamps of half-cou- pler type. Do not use any type of clamp that does not completely encircle the structure when fastened. RSR0630A/B Steel security cable C6002 clamp OS24 Fig. 02 PROLIGHTS - Jet Wash7... -
Page 9: Connection To The Mains Supply
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - Jet Wash7... -
Page 10: Product Overview
5. MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only (3.15A TBC). 6. POWER IN: for connection to the Mains 100-240V~/50-60Hz. 7. POWER OUT: power output for connection of multiple units in series. 3 4 5 Fig. 03 PROLIGHTS - Jet Wash7... -
Page 11: Dmx Connection
... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 05 - Example 25 DMX channels configuration PROLIGHTS - Jet Wash7... -
Page 12: Construction Of The Dmx Termination
2. Reach the addressing menu, then select the DMX ADDRESS settings. 3. Select the address from 1 to 512 using the navigation arrows/buttons and confirm by pressing ENTER. 4. Press Menu to exit and return to the Home screen. PROLIGHTS - Jet Wash7... -
Page 13: Control Panel
• Browse downwards through the menu list and de- creases the numeric value displayed. • Commute from units, tens, hundred in the menu. • Used to access the menu tree or to return a previous menu window. PROLIGHTS - Jet Wash7... -
Page 14: Menu Structure
To choose pan values in case of Custom position. 315° CUSTOM T DEGREE To choose tilt values in case of Custom position. 100% FIXTURE AUTO FAN MODE Select Fan behaviour. SETTINGS SILENT HIGH TUNGSTEN Activate Tungsten Emulation. EMULATION PROLIGHTS - Jet Wash7... - Page 15 PASSWORD For the calibration of these functions. 050 password for user reset TILT MANUAL For manual control of the unit. CONTROL RELOAD BASIC RELOAD ON - OFF DEFAULT FACTORY RELOAD ON - OFF 050 password needed PROLIGHTS - Jet Wash7...
-
Page 16: Shortcut
Directly flip display without enter inside menu. after power on DOWN Reset without Fixture will be powered on without reset on pan/tilt then power on pan/tilt movements movements. ENTER + UP Bootloader Force firmware upgrade. then power on PROLIGHTS - Jet Wash7... -
Page 17: Rdm Functions
0x0140 DMX_FAIL_MODE 0x0141 DMX_STARTUP_MODE 0x0142 Dimmer DIMMER_INFO 0x0340 Settings MINIMUM_LEVEL 0x0341 MAXIMUM_LEVEL 0x0342 CURVE 0x0343 CURVE_DESCRIPTION 0x0344 OUTPUT_RESPONSE_TIME 0x0345 OUTPUT_RESPONSE_TIME_ DESCRIPTION 0x0346 MODULATION_FREQUENCY 0x0347 MODULATION_FREQUENCY_ DESCRIPTION 0x0348 Sensors SENSOR_DEFINITION 0x0200 SENSOR_VALUE 0x0201 RECORD_SENSORS 0x0202 BURN_IN 0x0440 PROLIGHTS - Jet Wash7... - Page 18 0x0601 PAN_TILT_SWAP 0x0602 REAL_TIME_CLOCK 0x0603 LOCK_PIN 0x0640 LOCK_STATE 0x0641 LOCK_STATE_DESCRIPTION 0x0642 Control IDENTIFY_DEVICE 0x1000 RESET_DEVICE 0x1001 POWER_STATE 0x1010 PERFORM_SELFTEST 0x1020 SELF_TEST_DESCRIPTION 0x1021 CAPTURE_PRESET 0x1030 PRESET_PLAYBACK 0x1031 IDENTIFY_MODE 0x1040 PRESET_INFO 0x1041 PRESET_STATUS 0x1042 PRESET_MERGEMODE 0x1043 POWER_ON_SELF_TEST 0x1044 PROLIGHTS - Jet Wash7...
-
Page 19: Dmx Charts
Pan Fine Tilt Tilt Fine Dimmer Dimmer Fine Shutter / Strobe Tint Crossfade from CCT to Color Red Fine Green Green Fine Blue Blue Fine White White Fine Color Macro CTO on colors Zoom Zoom Fine Control PROLIGHTS - Jet Wash7... - Page 20 038 ÷ 039 Primary Green 040 ÷ 041 Special Lavender 042 ÷ 043 Pale Lavender 044 ÷ 045 Deep Golden Amber 046 ÷ 047 Medium Blue 048 ÷ 049 Bright Pink 050 ÷ 051 Mauve 052 ÷ 053 PROLIGHTS - Jet Wash7...
- Page 21 250 ÷ 251 10000K 252 ÷ 253 Full On 254 ÷ 255 CTO ON COLORS Linear from 0% to 100% 000 ÷ 255 ZOOM Linear from wide to narrow 000 ÷ 255 ZOOM FINE 000 ÷ 255 PROLIGHTS - Jet Wash7...
- Page 22 RESET ALL 114 ÷ 115 RESET PAN 116 ÷ 117 RESET TILT 118 ÷ 119 RESET PAN/TILT 120 ÷ 121 RESET ZOOM 122 ÷ 123 Reserved 124 ÷ 253 FACTORY DEFAULT OF CONTROL FUNCTIONS 254 ÷ 255 PROLIGHTS - Jet Wash7...
-
Page 23: Error Messages
Yellow TEMPERATURE ERROR] lamp has been switched OFF by the product protection system. First of the blowers for cooling the lamp [HEAD FAN ERROR] Yellow failed, the lamp has been switched OFF. PROLIGHTS - Jet Wash7... - Page 24 IDENTIFICATION OF ELECTRONIC BOARDS 3U PCB 2U PCB 1U PCB Fig. 08 PROLIGHTS - Jet Wash7...
-
Page 25: Accessories Installation
14 - ACCESSORIES INSTALLATION EGG CRATE (ASTRAW7PEC - OPTIONAL) Loosen and remove the marked three screws (1). Then insert the egg crate (2) and fix the three screws (3). Fig. 09 PROLIGHTS - Jet Wash7... -
Page 26: Periodical Cleaning
15 - PERIODICAL CLEANING WARNING! Turn OFF power and allow approximately 20 minutes for the fixture to cool down. Use a soft cloth dampened with any detergent liquid for cleaning to remove the dirt from the optics Fig. 10 PROLIGHTS - Jet Wash7... -
Page 27: Maintenance
WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel. -
Page 28: Troubleshooting
• Check if the Fuse is intact and eventually replace it if fault. necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in... - Page 29 Note...
- Page 30 Note...
- Page 32 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
