- Page 1 Assembly and Operating Instructions Art. No. TF-ADJ-STAND-75 ~ 60 Min. TFADB75.01.01 TFADJSTAND75.01.01 Art. No. TF-ADB-75 Taurus Selectabell Dumbbell...
- Page 2 SelectaBell Dumbbell...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List ADB-75... - Page 4 SelectaBell Dumbbell...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 7: General Information
GENERAL INFORMATION Technical Data TF-ADB-75 Packaging dimensions (L x W x H): approx. 60 cm x 27.5 cm x 29.8 cm Article weight (gross, including packaging): 37 kg TF-ADJ-STAND-75 Packaging dimensions (L x W x H): approx. 70,8 cm x 45,7 cm x 13,2 cm... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 11: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. - Page 12 Step 3: Alignment of the Reinforced Tube Assemble the reinforced tube (H) to the stand bases (B1&B2) with four screws (E). Step 4: Assembly of the Trays Assemble the trays to the stand bases (B1&B2) with four screws (G). Step 5: Assembly of the Dumbbells NOTICE Make sure the trays are securely tightened before placing the dumbbells.
-
Page 13: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and settings of the device before you start your training. Have a specialist explain the proper use of this product to you. CAUTION ⚠ Do not move the tray when lifting the dumbbell. Unattached weights may fall causing injury! To select the required weight, pull the adjustment pin (A) upwards, slide it left and right to the required weight plate (B) and re-insert it in place. -
Page 14: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... - Page 15 The weight plates are not correctly aligned If the plates are not correctly aligned, the dumbbell is hard to adjust. Check if there are any foreign objects (dirt/small objects) are in the dumbbell tray. Choose the maximum weight of 75lbs and lift up the dumbbell 3 - 5 times. Change the order of the outer weight plates.
- Page 16 Loosen the screws underneath the dumbbell tray and push or pull the tray in the direction so that the weight plates can correctly stay positioned in the dumbbell tray. Re-tighten the screws. Detached weight plates Please make sure that the dumbbells are never dropped. In case the dumbbell is accidentally dropped, the adjusting pin can spring inwards, resulting in some weight plates detaching.
-
Page 17: Maintenance And Inspection Calendar
Internal weight plate adjustment not smooth running If the adjustment of the inner weight plates is not smooth, set the adjustment lever to 0lb (no weight selected). Lift the dumbbell and set it down 3-5 times quickly. Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. -
Page 18: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For training equipment like smith machines, weight benches or racks this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes. -
Page 19: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / dumbbells Model Name: SelectaBell 75LB / Stand Article Number: TF-ADB-75... -
Page 20: Parts List Adb-75
Parts List ADB-75 Name Qty. 10LB Handle bar Adjustment Rod Weight Plate A Weight Plate B (End plate) 1.25LB weight Plate A (innter) 1.25LB weight Plate B (outer) Tray Exploded Drawing ADB-75 SelectaBell Dumbbell... -
Page 21: Parts List Adj-Stand-75
Parts List ADJ-STAND-75 Name Qty. Stand Leg Rear Tube Reinforced tube Stand Base Right Stand Base Left Screw M6 x 80mm M6 Nut Screw M6 x 15mm Self Tapping Screw M6 x 15mm Exploded Drawing ADJ-STAND-75... -
Page 22: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 23 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
