  • Page 1 User Manual VSX-6153-V3 with DM&P Vortex86SX 300MHz processor Version 2.0...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior to written permission of ICOP Technology Inc. ⓒ Copyright 2025 ICOP Technology Inc Trademarks Acknowledgement Vortex86SX is the registered trademark of DM&P Electronics Inc.
  • Page 3: Revision History

    VSX-6153-V3 User Manual Revision History Revision Date Remark Aug 1, 2010 First version released Apr 25, 2025 V2 version released ICOP Technology Inc.
  • Page 4: Table Of Contents

    J13: GPIO (Port0/1 or PWM x16) ....................10 J15: RS485 (Auto direction) ......................11 J16: Power Connector ........................11 J17: COM3 (Optional: TTL)......................11 J18: Parallel ............................ 12 J19: COM4 (Optional: TTL)......................12 J20: PC/104 Connector (64pins) ....................13 ICOP Technology Inc.
  • Page 5 2.8 SPI Flash ............................. 20 2.9 PWM ............................21 Driver Installation ..................... 22 Software Resources ................... 23 4.1 ICOP Technical Resource Website ....................23 Technical Support Directly from ICOP ..............24 User Manual Feedback ..................... 24 Appendix ........................25 Flat Panel Wiring and Lighting ......................25 TCP/IP Library for DOS Real Mode ....................
  • Page 6: General Information

    VSX-6153-V3 User Manual General Information 1.1 Packing List Product Name Package VSX-6153-V3 board x1 LAN cable x1 RS232 cable x4 GPIO cable x1 VSX-6153-V3 Parallel cable x1 USB cable x1 IDE cable x1 PS2KB x1 PS2KB(TEST) x1 VSX-6153-AU-V3 board x1...
  • Page 7: Specifications

    2.0mm 8-pin header for Ethernet x1 Type I/II Compact Flash Slot x1 Power DC +5V @ 700mA Requirement Operating -20°C - +70°C Temperature -40°C - +85°C (Optional) Dimension 90 x 96mm Weight O/S Support Windows Embedded CE6.0 Free BSD ICOP Technology Inc.
  • Page 8: Ordering Information

    DRAM (DDR2) 256MB IDE DoM IDE DoM Storage Compact Flash SPI Flash SPI Flash Display VGA, LVDS, TFT-LCD VGA, TFT-LCD PC/104 RS232 RS485 1(Configurable from RS232) Parallel GPIO 16 bits Keyboard Mouse Audio Line-out / Mic-in (Optional) ICOP Technology Inc.
  • Page 9: Hardware Information

    VSX-6153-V3 User Manual 2 Hardware Information 2.1 Dimension ICOP Technology Inc.
  • Page 10 VSX-6153-V3 User Manual ICOP Technology Inc.
  • Page 11: Board Outline And Connector Location

    VSX-6153-V3 User Manual 2.2 Board Outline and Connector Location Note: 1. COM2 can be configured as RS232/422/485 in BIOS 2. J15 RS485 is only active when COM2 is configured as RS485 in BIOS. ICOP Technology Inc.
  • Page 12: Connector And Jumper Summary

    Wafer, 1.25mm, 4x1 MIC-in (Optional) Wafer, 1.25mm, 4x1 CF Mater/Slave Switch Pin Header, 2.0mm, 5x2 LVDS Pin Header, 2.0mm, 8x2 Compact Flash Type I/II CF Slot Power Active LED (Red) IDE Active (Green) MTBF MTBF LED (Orange) Buzzer ICOP Technology Inc.
  • Page 13: Pin Assignments & Jumper Settings

    Pin# Signal Name Pin # Signal Name IDERST IDED7 IDED8 IDED6 IDED9 IDED5 IDED10 IDED4 IDED11 IDED3 IDED12 IDED2 IDED13 IDED1 IDED14 IDED0 IDED15 IDEREQ IDEIOW IDEIOR ICHRDY IDEACK IDEINT IDESA1 IDECBLID IDESA0 IDESA2 IDECS-0 IDECS1 IDELED ICOP Technology Inc.
  • Page 14: J2: Usb

    LED0+ LED1+ LED1 J6: Reset Pin# Signal Name Pin # Signal Name Reset J9: PS/2 Keyboard Pin# Signal Name Pin # Signal Name KBCLK KBDATA J10: PS/2 Mouse Pin# Signal Name Pin # Signal Name MSCLK MSDATA ICOP Technology Inc.
  • Page 15: J11: Com1 (Optional: Ttl/Gpio-P4/Pwm X8)

    TXD2/ 422RX+ DTR2 / 422RX- DSR2 RTS2 CTS2 J13: GPIO (Port0/1 or PWM x16) Pin# Signal Name Pin # Signal Name GP00 GP10 GP01 GP11 GP02 GP12 GP03 GP13 GP04 GP14 GP05 GP15 GP06 GP16 GP07 GP17 ICOP Technology Inc.
  • Page 16: J15: Rs485 (Auto Direction)

    VSX-6153-V3 User Manual J15: RS485 (Auto direction) Pin# Signal Name RS485+ RS485- J16: Power Connector Pin# Signal Name J17: COM3 (Optional: TTL) Pin# Signal Name Pin # Signal Name DCD3 RXD3 TXD3 DTR3 DSR3 RTS3 CTS3 ICOP Technology Inc.
  • Page 17: J18: Parallel

    User Manual J18: Parallel Pin# Signal Name Pin # Signal Name STB- AFD- ERR- INIT- SLIN- ACK- BUSY SLCT J19: COM4 (Optional: TTL) Pin# Signal Name Pin # Signal Name DCD4 RXD4 TXD4 DTR4 DSR4 RTS4 CTS4 ICOP Technology Inc.
  • Page 18: J20: Pc/104 Connector (64Pins)

    Pin # Signal Name IOCHCHK* RESETDRV IRQ9 DRQ2 -12V +12V IOCHRDY SMEMW* SA19 SMEMR* SA18 IOW* SA17 IOR* SA16 DACK3* SA15 DRQ3* SA14 DACK1* SA13 DRQ1* SA12 REFRESH* SA11 SYSCLK SA10 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 DACK2* BALE ICOP Technology Inc.
  • Page 19: J21: Pc/104 Connector (40Pins)

    IRQ12 SA20 IRQ15 SA19 IRQ14 SA18 DACK0* SA17 DRQ0 MEMR* DACK5* MEMW* DRQ5 DACK6* DRQ6 SD10 DACK7* SD11 DRQ7 SD12 SD13 MASTER* SD14 SD15 J22: 4P Power Source (Power source from PC/104) Pin# Signal Name -12V +12V ICOP Technology Inc.
  • Page 20: J25: Lcd

    VSX-6153-V3 User Manual J25: LCD Pin# Signal Name Pin # Signal Name +3.3V +3.3V LCLK LHSYNC LVSYNC LBACKL LVDDEN J33: Lint-out J34: MIC-in (Optional) (Optional) Pin# Signal Name Pin# Signal Name LOUTR MICVREF LOUTL MIC-IN ICOP Technology Inc.
  • Page 21: J36: Vga

    VSX-6153-V3 User Manual J36: VGA Pin# Signal Name Pin # Signal Name R OUT G OUT B OUT HSYNC_A VSYNC_A J37: LVDS Pin# Signal Name Pin # Signal Name VCC3 VCC3 CLK- CLK+ ICOP Technology Inc.
  • Page 22: System Mapping

    004Ch – 004Dh Empty 004Eh – 004Fh Forward to LPC Bus 0050h – 005Fh Empty 0060h Keyboard Data Port 0061h Port B + NMI Control Port 0062h – 0063h 8051 Download 4K Address Counter 0064h Keyboard Status Port ICOP Technology Inc.
  • Page 23 8259 Edge/Level Control Register 0CF8h – 0CFFh PCI Configuration Port D400h – D4FFh Onboard LAN FC00h – FC05h SPI Flash BIOS Control Register FC08h – FC0Dh External SPI Bus Control Register (Output pin configurable GPIO3 [0 -3]) ICOP Technology Inc.
  • Page 24 USB / Ethernet 10/100M LAN IRQ10 Serial Port 3 IRQ11 Serial Port 4 IRQ12 Mouse IRQ13 Math Processor IRQ14 Hard Disk Controller #1 IRQ15 DMA Mapping DMA# Description Usage DMA0 DMA1 DMA2 Floppy Disk Controller DMA3 DMA4 DMA5 DMA6 DMA7 ICOP Technology Inc.
  • Page 25: Watchdog Timer

    SPI Flash is often configured as a disk for booting up system or as floppy (A: Driver or B: Driver). Users may need to know how to do BIOS setup configuration for SPI flash and boot it up in DOS. For technical support, please visit http://www.dmp.com.tw/tech http://www.dmp.com.tw/tech/Vortex86SX/ ICOP Technology Inc.
  • Page 26: Pwm

    New Age x86 SoC platform and we also offer the sample code of PWM which will guide the engineer to control the PWM functionality smoothly. For more inquire of this sample code that please contact our sales team or mail to: info@icop.com.tw ICOP Technology Inc.
  • Page 27: Driver Installation

    EEPROM. Operating system support The Vortex86SX-6153-V3 PC/104 CPU board provides the VGA and LAN drivers for DOS 6.22 Windows CE 5.0 and CE 6.0. For drivers support, please visit http://www.dmp.com.tw/tech/Vortex86SX/ ICOP Technology Inc.
  • Page 28: Software Resources

    32-bit Window operating systems. For details, please kindly visit the following link: http://tech.icop.com.tw/ For resource of 32-bit Linux operating systems, please directly contact us at info@icop.com.tw or contact your ICOP contact window. ICOP Technology Inc.
  • Page 29: Technical Support Directly From Icop

    Technical Support Directly from ICOP To offer you more accurate and specific solutions for the technical situations you have, please prepare the information below before contacting ICOP: —Product name and serial number —Description of the H/W environment ( i.e.: working temperature, I/O...
  • Page 30: Appendix

    Application systems: Mity-Mite Serial Server, Web Camera Tiny Server and RSIP Serial Server. DSock is free for All ICOP products using M6117D/Vortex86/Vortex86SX/Vortex86SX CPU and ICOP also provide the business version of DSock for those customers who are using other x86 CPUs.
  • Page 31: Bios Default Setting

    CMOS as default setting.  Press “End” Key, when the power on  Press <Del> to enter the AMI BIOS setup  Press “F9” to Load Optimized Defaults  Press “F10” to Save configuration changes and exit setup ICOP Technology Inc.
  • Page 32: Warranty

    Returned goods should always be accompanied by a clear problem description. Should you have questions about warranty and RMA service, please contact us directly. ICOP Technology Inc. Address: No. 15 Wugong 5th Road, Xinzhuang Dist. New Taipei City, Taiwan (R.O.C.) 24890...
