- Page 1 VDX-6329/ VDX-6329-512 DM&P Vortex86DX 800MHz 3.5” CPU Module with 6S/2USB/VGA/LCD/AUDIO/2LAN/CF/FDD 256MB DDR2 Onboard User’s Manual (Revision 1.1A)
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the ICOP Technology Inc.. ©Copyright 2008 ICOP Technology Inc.
-
Page 3: Table Of Contents
T a b l e C o n t e n t s T a b l e o f C o n t e n t s .............iii C h a p t e r 1 Introduction……………………………………………1 Packing List............1 Product Description .......... -
Page 4: Chapter 1 Introduction
Package Embedded Vortex86DX CPU All-in-One Board Manual & Drivers CD x 1 RS232 cable x 6 PRINT cable x1 IDE cable x 1 VDX-6329 VGA cable x 1 & Audio cable x 2 FDD cable x 1 VDX-6329-512 USB cable x 1... -
Page 5: Product Description
3.5” controller. The VDX-6329 family of controller is designed as a plug in replacement, with backward compatibility to support legacy software to help extend existing product life cycle without heavy re-engineering. -
Page 6: Specifications
Specifications Features VDX-6329 DM&P SoC CPU Vortex86DX- 800MHz Real Time Clock with Lithium Battery Backup Cache L1:16K I-Cache, 16K D-Cache, L2 Cache 128KB BIOS AMI BIOS Bus Interface PC/104 Standard Compliant 32-bit x-PCI interface, compatible with PCI Rev.2.1 System Memory... - Page 7 Flash Disk Support Onboard 4MB SPI Flash Disk (Driver: A) 44-pin IDE Flash Disk( EmbedDisk 16MB or above) Type I/II CF Card 44-pin IDE to Micro SD (Optional) SRAM support 512KB (Optional) Power Requirement Single Voltage +5V @ 800mA Dimension 102 X 144mm (4.01 x 5.67 inches) Weight 150g...
-
Page 8: Board Dimension
Board Dimension Vortex86DX™ 3.5” CPU Module Vortex86DX-6329... -
Page 9: Chapter 2 Installation
C h a p t e r 2 Installation Board Outline (Note1: COM2 RS232/422/485 is selected by BIOS setting) (Note2: J39 Default setting of JTAG Has to be Disable: Pin 1 & Pin 2 short) (Note3: VDX-6329-512 is optional) Vortex86DX™ 3.5” CPU Module Vortex86DX-6329... -
Page 10: Connectors & Jumpers Location
Connectors & Jumpers Location Connectors Vortex86DX™ 3.5” CPU Module Vortex86DX-6329... - Page 11 Jumpers & LEDs Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
-
Page 12: Connectors & Jumpers Summary
Connectors & Jumpers Summary Summary Table Description Type of Connections Pin nbrs. 44-pin Box Header, 2.0∅ ,22x2 CF Card Master/Slave Select 2-pin Pin Header, 2.54∅, 2x1 10-pin Box Header,2.0∅ , 5x2 JTAG 6-pin Wafer, 1.25∅ , 6x1 Reset 2-pin Pin Header, 2,54∅,1x2 PS2 Keyboard 5-pin Box Header,2,54∅, 1x5... - Page 13 x-PCI 64-pin Box Header, 2.0∅ , 32x2 COM1 10-pin Box Header, 2.0∅ 5x2 Compact Flash 50-pin Type I/II CF Connector PWR_L POWER Active LED (Red) IDE_LE IDE Active LED (Green ) MTBF- MTBF-Out (Orange) LED-SMD BUZZER Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
-
Page 14: Pin Assignments & Jumper Settings
Pin Assignments & Jumper Settings J1: IDE (44 Pins) Pin # Signal Name Pin # Signal Name IDERST IDED7 IDED8 IDED6 IDED9 IDED5 IDED10 IDED4 IDED11 IDED3 IDED12 IDED2 IDED13 IDED1 IDED14 IDED0 IDED15 IDEREQ IDEIOW IDEIOR ICHRDY IDEACK IDEINT IDESA1 IDECBLID IDESA0... - Page 15 J4: USB Pin # Signal Name Pin # Signal Name LUSBD0- LUSBD1- LUSBD0+ LUSBD1+ GGND GGND J7: JTAG Pin # Signal Name Pin # Signal Name J8: RESET Pin # Signal Name Pin # Signal Name Reset J9: PS/2 Keyboard Pin # Signal Name Pin # Signal Name KBCLK...
- Page 16 J12: COM2 RS232 / RS422 / RS485 (Optional: TTL) Pin # Signal Name Pin # Signal Name DCD2/ 422TX- / RS485- RXD2 / 422TX+ / RS485+ TXD2 / 422RX+ DTR2 / 422RX- DSR2 RTS2 CTS2 J15: RS485 (Auto direction) Pin # Signal Name RS485＋...
- Page 17 J18: PRINT Pin # Signal Name Pin # Signal Name STB- AFD- ERR- INIT- SLIN- ACK- BUSY SLCT J19: COM4 (Optional: TTL) Pin # Signal Name Pin # Signal Name DCD4 RXD4 TXD4 DTR4 DSR4 RTS4 CTS4 Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
- Page 18 J20: FDD Pin # Signal Name Pin # Signal Name DENSEL INDEX\ MTRO\ DS1\ DS0\ MTR1\ DIR\ STEP\ TR0\ HDSEL\ DSKCHG\ J21: COM5 (Optional: TTL) Pin # Signal Name Pin # Signal Name DCD5 RXD5 TXD5 DTR5 DSR5 RTS5 CTS5 Vortex86DX™...
- Page 19 J23: COM6 (Optional: TTL) Pin # Signal Name Pin # Signal Name DCD6 RXD6 TXD6 DTR6 DSR6 RTS6 CTS6 J25: PC104 Connector – 64pin Pin # Signal Name Signal Name IOCHCHK * RESETDRV IRQ9 DRQ2 -12V +12V IOCHRDY SMEMW * SA19 SMEMR * SA18...
- Page 20 J26: PC104 Connector – 40pin Pin # Signal Name Pin # Signal Name MEMCS16 * SBHE * IOCS16 * SA23 IRQ10 SA22 IRQ11 SA21 IRQ12 SA20 IRQ15 SA19 IRQ14 SA18 DACK0 * SA17 DRQ0 MEMR * DACK5 * MEMW * DRQ5 DACK6 * DRQ6...
- Page 21 J30: VGA Signal Signal Pin # Pin # Name Name R OUT G OUT B OUT HSYNC VSYNCD J32~J38: Display type setup (CRT /LCD) Connector Pin # Signal Name GPIOA GPIOB GPIOC GPIOD GPIOE Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
- Page 22 GPIOA (Please refer to Appendix D, for Display type setup) J33: LCD (DVO) Connector Pin # Signal Name Pin # Signal Name +3.3V +3.3V LCLK LHSYNC LVSYNC LBACKL LVDDEN (Please refer to Appendix A, for TFT Flat Panel Data Output) Vortex86DX™...
- Page 23 J39: JTAG Disable (Default setting: Pin 1 & Pin 2 short) Pin # Signal Name Pin # Signal Name JTAG Disable J40: LINE OUT Pin # Signal Name LOUTR LOUTL J41: MIC-IN Pin # Signal Name MICVREF MIC-IN J42: LAN1 Pin # Signal Name Pin # Signal Name TX+1...
- Page 24 J44: LAN1 Enable/Disable Pin # Signal Name CLOSE LAN Off OPEN LAN ON J45: LAN2 Enable/Disable Pin # Signal Name CLOSE LAN Off OPEN LAN ON J46: PS/2 Mouse Pin # Signal Name Pin # Signal Name MSCLK MSDATA Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
- Page 25 J47: x-PCI Pin # Signal Name Pin # Signal Name AD10 AD11 AD12 AD13 AD14 AD15 AD16 AD17 AD18 AD19 AD20 AD21 AD22 AD23 AD24 AD25 AD26 AD27 AD28 AD29 AD30 AD31 VCC3 VCC3 CBE-0 CBE-1 CBE-2 CBE-3 PGNT-0 PREQ-0 PGNT-1 PREQ-1 PGNT-2...
- Page 26 J48: COM1 (Optional: TTL/ GPIO-P4 / PWMx8) Signal Signal Pin # Pin # Name Name DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
-
Page 27: System Mapping
System Mapping Vortex86DX™ 3.5” CPU Module Vortex86DX-6329... - Page 28 Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
- Page 29 Vortex86DX™ 3.5” CPU Module Vortex86DX-6329...
-
Page 30: Watchdog Timer
Watchdog Timer There are two watchdog timers in Vortex86SX/DX CPU. One is compatible with M6117D watchdog timer and the other is new. The M6117D compatible watchdog timer is called WDT0 and new one is called WDT1. We also provide DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file:... -
Page 31: Gpio
GPIO (General Purpose Input / Output) 40 GPIO pins are provided by the Vortex86SX/DX for general usage in the system. All GPIO pins are independent and can be configured as inputs or outputs, with or without pull-up/pull-down resistors. We also offer DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file:... -
Page 32: Spi Flash
SPI flash (Serial Peripheral Interface) As SPI Flash Serial Peripheral Interface) offers many benefits including: reduced controller pin count, smaller and simpler PCBs, reduced switching noise, less power consumption, and lower system cost Many of users may consider using a formatted SPI flash to boot for the system or emulate SPI flash as Floppy (A: Driver or B: Driver). -
Page 33: Ide To Sd
44 pins IDE to SD Adapter can be easily installed on all Vortex86DX-63xx CPU boards. You or your customers just do the BIOS setting and use SD-1917 to connect IDE connector of Vortex86DX-63xx directly. For further inquiries of SD-1917, please contact ICOP sales team or mail to: info@icop.com.tw for your request. -
Page 34: Chapter 3 Driver Installation
C h a p t e r Driver Installation The Vortex86DX processor also use external Display chip ““Volari™ Z9s” which is an ultra low powered graphics chipset with total power consumption at around 1-1.5 W. It is capable in providing VGA display output upto 1600x1200. With DVO interface, developers could easily connect flat Panel to support TFT and LVDS output. -
Page 35: Appendix
Appendix TFT Flat Panel Data Output Vortex86DX™ 3.5” CPU Module Vortex86DX-6329... -
Page 36: Tft Flat Panel Support List
TFT Flat Panel Support List Size Brand Resolution Model No. 5.7” Data image 320x240 FG050701DSSWBG01 5.7” Optrex 320x240 55264GD057J-FW-ABN 5.7” TOSHIBA 320x240 LTA057A343F 5.7” Sharp 320x240 (QVGA / VGA) LQ057Q3DC02 5.7” Kyocera 320x240 (QVGA / VGA) TCG057QV1AC-G10 5.7” 320x240 (QVGA / VGA) PD057VU4 /U5 5.7”... - Page 37 Size Brand Resolution Model No. 8” 800x600 (TFT 24bits) A080SN01 V0 8.4” Sharp 800x600 LQ084S3DG01 10.4” 640x480 PD104VT1/VT2 10.4” 640x480 NL6448AC33-18 10.4” 640x480 NL6448AC33-29 10.4” 640x480 NL6448BC33-59 10.4” Sharp 640x480 LQ104V1DG51/DG61 10.4” Sharp 640x480 LQ10d368 11” Sharp 800x480 LQ110Y3DG01 12.1” 800x600 NL8060BC31-01 Vortex86DX™...
-
Page 38: Lvds Flat Panel Support List
C. Flat Panel Hardware Setting: The Vortex86DX-6329 offers the Hardware setting for the various TFT LCD Flat Panels support and please make sure the jumper setting (J32~J38) before you connect the LCD. Display type setup Connector Note: "C" means close; "X" means open Vortex86DX™... -
Page 39: Flat Panel Hardware Setting
LVDS Flat Panel Support List If you would like to use LVDS Flat Panel with Vortex86SX / Vortex86DX series, please contact our regional sales to get ICOP-0096 information or visit ICOP website: http://www.icop.com.tw/pddetail.aspx?id=65&pid=4 ICOP–0096 : 18-bit TFT to LVDS converter and Cable-LVDS-30: LVDS Cable 30cm... -
Page 40: Flat Panel Wiring And Lighting
Wiring LCD Cable Please refer to Page 19 (J33: LCD connector) and Page 32~37. Or for more LCD lighting and integration service, please contact our regional sales or mail to info@icop.com.tw you have any questions. Vortex86DX™ 3.5” CPU Module Vortex86DX-6329... -
Page 41: Tcp/Ip Library For Dos Real Mode
Mity-Mite Serial Server, Web Camera Tiny Server and RSIP Serial Server. DSock is free for All ICOP products using M6117D/Vortex86/Vortex86SX/Vortex86DX CPU and ICOP also provide the business version of DSock for those customers who are using other x86 CPUs. -
Page 42: Bios Default Setting
BIOS Default setting If the system cannot be booted after BIOS changes are made, Please follow below procedures in order to restore the CMOS as default setting. Press “End” Key, when the power on Press <Del> to enter the AMI BIOS setup Press “F9”... -
Page 43: Warranty
Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
