  • Page 2 VSX-6124 DM&P Vortex86SX 300MHz Half-Size CPU Module with 4S/4USB/VGA/LCD/LAN/GPIO 128MB DDR2 Onboard User’s Manual (Revision 1.2A)
  • Page 3 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the ICOP Technology Inc.. ©Copyright 2007 ICOP Technology Inc.

  • Page 4: Table Of Contents

    T a b l e C o n t e n t s T a b l e o f C o n t e n t s .............iii C h a p t e r 1 Introduction……………………………………………1 Packing List............1 Product Description ..........

  • Page 5: Chapter 1 Introduction

    Package Embedded Vortex86SX CPU All-in-One Board Manual & Drivers CD x 1 RS232 cable x 3 PRINTER cable x1 VSX-6124 IDE cable x 1 USB cable x 2 (USB port x 2 GPIO cable x 1 YKB for PS/2 Keyboard & Mouse x 1 Vortex86SX-6124 Vortex86SX™...

  • Page 6: Product Description

    Half-Size controller. The VSX-6124 family of controller is designed as a plug in replacement, with backward compatibility to support legacy software to help extend existing product life cycle without heavy re-engineering.

  • Page 7: Specifications

    1.3 Specifications Features VSX-6124 DM&P SoC CPU Vortex86SX- 300MHz Real Time Clock with Lithium Battery Backup Cache L1:16K I-Cache, 16K D-Cache BIOS AMI BIOS Bus Interface PC/104 Standard Compliant (Optional: PCI-104) System Memory 128MB DDR2 onboard Watchdog Timer Software programmable from 30.5 us to 512 seconds x2...
  • Page 8 Flash Disk Support On board 2MB SPI Flash Disk (Driver: A) 44-pin IDE Flash Disk( EmbedDisk 16MB or above) Power Requirement Single Voltage +5V @640mA Dimension 184mm X 122mm (7.24 x4.80 inches) Weight 176g Operating C ~ +70 Temperature -40°C ~ +85°C (Optional) Vortex86SX-6124 Vortex86SX™...

  • Page 9: Board Dimension

    1.4 Board Dimension Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 10: Chapter 2 Installation

    C h a p t e r 2 Installation 2.1 Board Outline (Note1: PCI-104 connector is optional) Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 11: Connectors & Jumpers Location

    Connectors & Jumpers Location Connectors Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...
  • Page 12 Jumpers & LEDs Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 13: Connectors & Jumpers Summary

    Connectors & Jumpers Summary Summary Table Description Type of Connections Pin nbrs. 40-pin Box Header, 2.54∅ , 20x2 USB1 10-pin Box Header, 2.54∅ , 5x2 USB2 10-pin Box Header, 2.54∅ , 5x2 JTAG 6-pin Wafer, 1.25∅ , 6x1 Reset 2-pin Pin Header, 2,54∅,1x2 Redundancy 7-pin...
  • Page 14 Display type Setup 3-pin Pin Header, 2.54∅ , 3x1 10/100Base-T Ethernet LAN 8-pin RJ45 Connector PWR-LE Power Active LED (Red) LED-SMD IDE- IDE Active LED (Green ) LED-SMD MTBF- MTBF-Out (Orange) LED-SMD BUZZER Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 15: Pin Assignments & Jumper Settings

    2.4 Pin Assignments & Jumper Settings J1: IDE (40 Pins) Pin # Signal Name Pin # Signal Name IDERST IDED7 IDED8 IDED6 IDED9 IDED5 IDED10 IDED4 IDED11 IDED3 IDED12 IDED2 IDED13 IDED1 IDED14 IDED0 IDED15 IDEREQ IDEIOW IDEIOR ICHRDY IDEACK IDEINT IDESA1 IDECBLID...
  • Page 16 J4: JTAG Pin # Signal Name Pin # Signal Name J5: RESET Pin # Signal Name Pin # Signal Name VCC3 J6: Redundancy Pin # Signal Name Pin # Signal Name SYS-FAIL-OUT GPCS0 SYS-FAIL-IN SYS-GPCS-IN TXD9\ RXD9\ J7: Redundancy (System-Fail-Switch) Pin # Signal Name SYS-SW-IN...
  • Page 17 J9: COM 1 Signal Signal Pin # Pin # Name Name DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 J10: COM2 RS232 / RS422 / RS485 Pin # Signal Name Pin # Signal Name DCD2/ 422TX- / RS485- RXD2 / 422TX+ / RS485+ TXD2 / 422RX+ DTR2 / 422RX- DSR2...
  • Page 18 J12: RS485 (Auto direction) Pin # Signal Name RS485＋ RS485－ J13: RS232 COM2 Operation Mode Selector Pin combination Description RS232 RS485 RS422 J14 /J15 /J16: COM2: RS232 /RS422 /RS485 setting RS232 (Close) RS422 / RS485 (Close) J17: Power Connector – 4-pin Header (P4 Molex 5mm) Signal Pin # Name...
  • Page 19 J18: Power Connector (Terminal Block 5.0mm) Pin # Signal Name J19: COM3 Pin # Signal Name Pin # Signal Name DCD3 RXD3 TXD3 DTR3 DSR3 RTS3 CTS3 J20 PRINT Pin # Signal Name Pin # Signal Name STB- ACK- BUSY SLCT AFD- ERR-...
  • Page 20 J22: PC104 Connector – 64pin Pin # Signal Name Pin # Signal Name IOCHCHK * RESETDRV IRQ9 DRQ2 -12V +12V IOCHRDY SMEMW * SA19 SMEMR * SA18 IOW * SA17 IOR * SA16 DACK3 * SA15 DRQ3 SA14 DACK1 * SA13 DRQ1 SA12...
  • Page 21 J24: PC104 Connector – 40pin Pin # Signal Name Pin # Signal Name MEMCS16 * SBHE * IOCS16 * SA23 IRQ10 SA22 IRQ11 SA21 IRQ12 SA20 IRQ15 SA19 IRQ14 SA18 DACK0 * SA17 DRQ0 MEMR * DACK5 * MEMW * DRQ5 DACK6 * DRQ6...
  • Page 22 J28: VGA (D-Sub connector) Pin # Signal Name Pin # Signal Name R OUT G OUT B OUT DDCDAT HSYNC VSYNC DDCCLK J29: LCD Connector Pin # Signal Name Pin # Signal Name VCC3 VCC3 LCLK LHSYNC LVSYNC LBACKL LVDDEN (Please refer to Appendix A, for TFT Flat Panel Data Output) Vortex86SX-6124 Vortex86SX™...
  • Page 23 J30~J35: Display type setup (CRT /LCD) Connector Pin # Signal Name GPIOA GPIOB GPIOC GPIOD GPIOE GPIOF (Please refer to Appendix D, for Display type setup) J36: LAN Pin # Signal Name Pin # Signal Name Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 24: System Mapping

    System Mapping Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...
  • Page 25 Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...
  • Page 26 Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 27: Watchdog Timer

    Watchdog Timer There are two watchdog timers in Vortex86SX CPU. One is compatible with M6117D watchdog timer and the other is new. The M6117D compatible watchdog timer is called WDT0 and new one is called WDT1. We also provide DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file:...

  • Page 28: Gpio

    GPIO (General Purpose Input / Output) 40 GPIO pins are provided by the Vortex86SX for general usage in the system. All GPIO pins are independent and can be configured as inputs or outputs, with or without pull-up/pull-down resistors. We also offer DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file:...

  • Page 29: Spi Flash

    SPI flash (Serial Peripheral Interface) As SPI Flash Serial Peripheral Interface) offers many benefits including: reduced controller pin count, smaller and simpler PCBs, reduced switching noise, less power consumption, and lower system cost Many of users may consider using a formatted SPI flash to boot for the system or emulate SPI flash as Floppy (A: Driver or B: Driver).

  • Page 30: Chapter 3 Driver Installation

    C h a p t e r Driver Installation The Vortex86SX processor also use external Display chip ““Volari™ Z9s” which is an ultra low powered graphics chipset with total power consumption at around 1-1.5 W. It is capable in providing VGA display output upto 1600x1200. With DVO interface, developers could easily connect flat Panel to support TFT and LVDS output.

  • Page 31: Appendix

    Appendix A. TFT Flat Panel Data Output Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 32: Tft Flat Panel Support List

    B.TFT Flat Panel Support List Size Brand Resolution Model No. 5.7” Sharp 320x240 LQ057Q3DC02 5.7” Kyocera 320x240 TCG057QV1AC-G10 5.7” 320x240 PD057VU5 5.7” Data image 640x480 FG050710DSSWJG01 5.7” Ampire 640x480 AM-640480GTMQW-T00H 5.7” Sharp 640x480 LQ057V3DG01 5.7” 640x480 CLAA057VA01 6.4” LG-PHILIPS 640x480 LB064V02 6.4”...

  • Page 33: Lvds Flat Panel Support List

    C. LVDS Flat Panel Support If you would like to use LVDS Flat Panel with Vortex86SX series, please contact our regional sales to get ICOP-0096 information or visit ICOP website: http://www.icop.com.tw/products_detail.asp?ProductID=178 ICOP–0096 : 18-bit TFT to LVDS converter Cable-LVDS-30: LVDS Cable 30cm...

  • Page 34: Flat Panel Hardware Setting

    D. Flat Panel Hardware Setting: The VortexSX-6124 offers the Hardware setting for the various TFT LCD Flat Panels support and please make sure the jumper setting (J30~J35) before you connect the LCD. Display type setup Connector Note: "C" means close; "O" means open Vortex86SX-6124 Vortex86SX™...

  • Page 35: Flat Panel Wiring And Lighting

    Wiring LCD Cable Please refer to Page 18 (J29: LCD connector) and Page 27~30. Or for more LCD lighting and integration service, please contact our regional sales or mail to info@icop.com.tw you have any questions. Vortex86SX-6124 Vortex86SX™ Half-Size CPU Module...

  • Page 36: Warranty

    Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
