- Page 1 190400-Q 1-866-4-DGCASA service@dgcasa.com www.dgcasa.com...
- Page 2 IMPORTANT INFORMATION Seller and Manufacturer disclaim all and any liability for property damage, personal injury, or loss, direct, indirect, or incidental, resulting from the incorrect assembly, inadequate maintenance, improper use, or neglect of this product. NOTICE Keep these assembly instructions for future reference. �...
- Page 3 BED PARTS Headboard Footboard Headboard Rail Headboard Post Left Headboard Post Right Footboard Leg Side Rail A Side Rail B Side Rail Support Leg Bed Slat x 12 Slat Support Support Leg...
- Page 4 HARDWARE HARDWARE Screw Hex Nut Bolt x 12 M4 x 32mm M6 x 35mm Bolt Spring Washer M6 x 60mm Half Moon Washer Threaded Rod M8 x 30mm M8 x 65mm Dowel Adjustable Feet Hex Key Wrench x 14 M10 x 40mm Open End Wrench...
- Page 5 BED ASSEMBLY STEP 1 Footboard Footboard Hex Nut Half Moon Washer M8 x 30mm Threaded Rod Dowel Open End Wrench M8 x 65mm M10 x 40mm Insert into Attach with using an Open End Wrench...
- Page 6 BED ASSEMBLY STEP 2 Side Rail A Side Rail B Side Rail Bolt Support Leg M6 x 35mm Spring Washer Hex Key Wrench Attach with as shown using Hex Key Wrench...
- Page 7 BED ASSEMBLY STEP 3 Headboard Headboard Headboard Threaded Rod Rail Post Left Post Right M8 x 65mm Half Moon Hex Nut Dowel Open End Washer Wrench M8 x 30mm M10 x 40mm D & E D & E Insert into Attach with using an Open End Wrench...
- Page 8 BED ASSEMBLY STEP 4 Headboard Bolt Hex Key Wrench M6 x 35mm Adjustable headboard height. Assemble bolts at preferred height as shown below. Highest Position Lowest Position D & E Attach to Assembled Headboard Leg with using a Hex Key Wrench as shown.
- Page 9 BED ASSEMBLY STEP 5 Threaded Rod Dowel M8 x 65mm M10 x 40mm & Insert into...
- Page 10 BED ASSEMBLY STEP 6 Hex Nut Half Moon Open End Washer Wrench M8 x 30mm D , E & F G & & H Attached Assembled Headboard and Assembled Footboard to Assembled Side Rail with using an Open End Wrench...
- Page 11 BED ASSEMBLY STEP 7 Bed Slat Slat Support Support Leg Bolt M6 x 60mm Adjustable Hex Key Feet Wrench Note: See Bed Assembly Step 9 to properly adjust part Insert into . Attach with using a Hex Key Wrench as shown.
- Page 12 BED ASSEMBLY STEP 8 Screw Philips Screwdriver M4 x 32mm Not provided Wood Screw location Attach Assembled Bed Slat to Assemble Bed Frame with using a Philips Screwdriver as shown.
- Page 13 BED ASSEMBLY STEP 9 Rotate clockwise or counter clockwise until it is firmly against the floor.
- Page 14 FAQs FREQUENTLY ASKED QUESTIONS WE ARE OPEN MONDAY TO FRIDAY TO ASSIST YOU AND WILL REPLY TO ANY OF YOUR MESSAGES WITHIN 24-48 HOURS. THE AVERAGE RESPONSE TIME IS WITHIN 24 HOURS. IF YOU ENCOUNTER AN ISSUE THAT IS NOT MENTIONED BELOW, PLEASE MESSAGE US IN OUR CONTACT PAGE BY VISITING WWW.DGCASA.COM WHERE IS THE REST OF MY ORDER? THE PACKAGE I RECEIVED SAYS CARTON NO.
