- Page 1 ARGO STORAGE BED ASSEMBLY INSTRUCTION 12350-Q / 12350-K...
-
Page 2: Tools Required
WARNING Seller and Manufacturer disclaim all and any liability for property damage, personal injury, or loss, direct, indirect, or incidental, resulting from the incorrect assembly, inadequate maintenance, improper use, or neglect of this product. NOTICE • Keep these assembly intructions for future reference. •... - Page 3 HARDWARE M6 x 40 M6 x 50 3 PCS 9 PCS ALLEN KEY 100MM ALLEN KEY 70MM 1 PC 1 PC SCREW SCREW SCREW SCREW 16MM 25MM 32MM 50MM 64 PCS 8 PCS 46 PCS 32 PCS SPRING WASHER SUPPORT LEG ADJUSTER 6 PCS 3 PCS CASTER...
- Page 4 ARGO STORAGE BED PARTS HEADBOARD 1 PC SIDE RAIL SUPPORT LEG 4 PCS FOOTBOARD 1 PC DRAWER FRONT PANEL 4 PCS DRAWER BACK PANEL 4 PCS SIDE RAIL 2 PCS DRAWER LEFT SIDE PANEL 4 PCS HEADBOARD LEG 2 PCS DRAWER RIGHT SIDE FOOTBOARD PANEL 4 PCS...
-
Page 5: Assembly Instruction
ASSEMBLY INSTRUCTION STEP 1 STEP 2 BOTTOM DRAWER VIEW TAPPED HOLE INDICATES BACK OF DRAWER SLIDE PART N TOWARDS THE FRONT DRAWER FABRIC PANEL INDICATES FRONT OF DRAWER STEP 3 STEP 4 BOTTOM DRAWER VIEW BOTTOM DRAWER VIEW ALIGN CASTER MOUNTING HOLE TO NOTCHES ON PART O THEN INSTALL CASTER... - Page 6 STEP 5 *BACK OF HEADBOARD STEP 6 LIGHTLY TAP INTO PLACE STEP 7 ATTACH PART I BY ALIGNING PRECUT HOLES LOCATED ON ONE SIDE OF THE PART TO PART 11, THEN INSTALL PART I TO PART C...
- Page 7 STEP 8 STEP 9...
- Page 8 STEP 10 ROTATE PART 10 CLOCKWISE OR COUNTER CLOCKWISE TO ADJUST SLAT HEIGHT FOR PROPER BOX SPRING SUPPORT STEP 11 SCREW SLAT ONTO WOOD SLAT SUPPORT ON THE SIDE RAIL...
