- Page 1 BARDY PANEL BED ASSEMBLY INSTRUCTION 12850-Q...
- Page 2 WARNING 12850-Q Seller and Manufacturer disclaim all and any liability for property damage, personal injury, or loss, direct, indirect, or incidental, resulting from the incorrect assembly, inadequate maintenance, improper use, or neglect of this product. NOTICE • Keep these assembly instructions for future reference.
- Page 3 HARDWARE M8 x 20 M6 x 30 M6 x 40 M6 x 50 8 PCS 20 PCS 8 PCS 8 PCS SCREW 32MM SPRING WASHER ALLEN KEY 100MM ALLEN KEY 70MM 8 PCS 1 PC 1 PC 10 PCS FLAT WASHER SUPPORT LEG ADJUSTER 12 PCS 4 PCS...
- Page 4 BARDY PANEL BED PARTS SIDE RAIL LEGS 2 PCS HEADBOARD 1 PC FOOTBOARD 1 PC SIDE RAIL SUPPORT WOOD 4 PCS SLAT 4 PCS SIDE RAIL 4 PCS SUPPORT LEGS 4 PC HEADBOARD LEGS 2 PCS SIDE WING 2 PCS FOOTBOARD SIDE LEG 2 PCS...
- Page 5 ASSEMBLY INSTRUCTION STEP 1 COMPONANTS AND HARDWARE TO BUILD THE BED IS LOCATED IN THE HEADBOARD. UNZIP THE ZIPPER COMPARTMENT LOCATED AT THE BACK OF THE HEADBOARD TO ACCESS THESE PARTS. HEADBOARD BACK VIEW STEP 2 ATTACH LEGS TO FOOTBOARD AND HEADBOARD AS SHOWN. HEADBOARD BACK VIEW MATCH THE LABEL TO ENSURE THE HEADBOARD LEGS ARE INSTALLED ONTO THE CORRECT SIDE OF THE HEADBOARD...
- Page 6 STEP 4 ATTACH THE SIDE WING (11) TO THE HEADBOARD (A). MATCH THE LABEL TO INSTALL THE SIDE WINGS, UNZIP THE BLACK NON WOVEN FABRIC AND REZIP ONCE THE SIDE WINGS ARE INSTALLED. HEADBOARD BACK VIEW STEP 5 ATTACH THE SIDE RAIL SUPPORT WOOD (G) TO THE SIDE RAIL (C).
- Page 7 STEP 6 ATTACH THE SIDE RAIL LEG (F) TO THE SIDE RAIL (C). STEP 7 ATTACH SIDE RAIL (C) TO HEADBOARD (A) AND FOOTBOARD (B) BY PUSHING THE BRACKET DOWN TO FIT IT.
- Page 8 STEP 8 ATTACH THE SUPPORT LEGS (I) TO THE SLATS (H). ROTATE PART S CLOCKWISE OR COUNTER CLOCKWISE TO ADJUST SLAT HEIGHT FOR PROPER BOX SPRING SUPPORT STEP 9 SCREW SLAT ONTO WOOD SLATE SUPPORT ON THE SIDE RAIL. DO NOT PLACE THE MATTRESS DIRECTLY ON TOP OF THE SLATS. A BOX SPRING IS REQUIRED AND A LOW PROFILE BOX SPRING IS PREFERRED.
