  • Page 1 QPC-CH CCS AC63...
  • Page 2 TRI RAPID CHARGER – INSTRUCTION MANUAL This document is copyrighted, 2014 by Circontrol, S.A. All rights are reserved. Circontrol, S.A. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 3: Table Of Contents

    INTEGRATION SETUP WEB PAGE ................31 OCPP ENGINE SETUP WEB PAGE ................32 7.2.1 APPLICATION PARAMETERS ................33 CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...
  • Page 4 SCADA DEVICES STATUS ..................55 11.1.1 VIEW SELECTION ....................56 11.1.2 DISPLAYING REALTIME DEVICES ..............56 CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 5: Introduction

    This manual contains all the information necessary for safe use of quick charge point and helping to get the best performance results. Circontrol’s quick charging stations are the fastest way of charging today’s electric vehicles. Their innovative, original design offers a fast, easy to use charging solution, in line with CHAdeMO’s current standards for the quick, direct current charging of electric...

  • Page 6: Security Warnings

    (repairing or handling of any equipment connections) and wait minimum 15 minutes while capacitors are being discharged. Do not modify the unit. If modified, CIRCONTROL will reject all responsibility and the warranty will be void. WARNING People who use electronic medical devices such as...

  • Page 7: Important Safety Information

     Do not use this unit for anything other than electric vehicle charging.  Do not modify this unit. If modified, Circontrol will reject all responsibility and the warranty will be void.  Comply strictly with current safety regulations according to your country rules.

  • Page 8: Basics

    Below information shows different charging modes and plug types available in the electric vehicles and charge points. 2.1 CHARGING MODES CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 9: Plug Types

    TRI RAPID CHARGER – INSTRUCTION MANUAL – 2.2 PLUG TYPES CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 10: Quick Charger At A Glance

    CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 11: Unit Overview

    3. Air output cover 4. Air filter cover 5. MCB and RCB cover access CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 12: User Front Panel

    AC Plug – Control buttons RFID reader DC Plug – Control buttons Emergency Push-Button CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 13: Colour Code Of The Charger Beacons

    CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 14: Charge Point Plugs

    Charge point is not capable of carrying CHADEMO and Combo 2 simultaneously. Only one plug (CHAdeMO or Combo 2) can be used in DC. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com –...

  • Page 15: Instructions For Use

    This section describes how to starting or ending a recharge session when only one DC outlet is installed on the rapid charger for electric vehicles. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com –...

  • Page 16: Charging Information Screen

    Battery status Battery current status. Additional information Current status charging and how to stop it. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 17: Charging Summary Screen

    Battery current status. NOTE: This screen is displayed for 1 minute after recharge is completed or stopped. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 18: Emergency Stop

    2- Press stop button until the LED beacons turns green (20 seconds approx.) 3- Unit returns to display the idle state. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com –...

  • Page 19: Setting Up The Unit

    Windows 8 (x86/x64) Crossover Cable UTP Cat.5e o Cat6 Software needed: IPSetup.exe. (Supplied with charge point) CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 20: Network Topology

    EXAMPLE Crossover UTP cable IP: 192.168.1.11 IP: 192.168.1.10 NETMASK: 255.255.255.0 NETMASK: 255.255.255.0 CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 21: Lan Connection Procedure

    On the left pane, click the option: “Change adapter settings”. Right click on “Local Area Connection” and then click on “Properties” CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com –...
  • Page 22 EXAMPLE Click OK twice to complete the process to assigning IP address to the computer. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...
  • Page 23 Gateway: leave default settings. EXAMPLE Wait 30 seconds approximately until the process is complete. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...
  • Page 24 Check IP address entered. Check the MAC of the device entered. Try with another UTP CAT5e cable. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 25: Setup Web Page

    To access to the setup web page, open a web browser and enter the following address: http://”IP ADDRESS”/html/setup.html Direct link: CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 26: Network Setup

    Gateway Gateway/router IP address Primary DNS server DNS server IP addresses Secondary DNS server CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 27: Public Address Manager

    Allows selecting the country currency according to your country. Language Allows selecting the screen unit language. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 28: Time Setup

    CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 29: Security Setup

    It will require returning the unit to the service centre. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 30: System Information

    PowerStudio Engine version Link that allows viewing the status of the Devices status configured devices. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 31: System Upgrade

     List of available devices that can communicate with the WallBox. http://”IP_ADDRESS”/services/system/info.html Direct link: CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 32: Log Web Page

    Log web page allows showing a temporary log since CHADEMO is powered ON. If CHADEMO has http://”IP_ADDRESS”/html/log Direct link: EXAMPLE CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 33: Quick Charger Ocpp Integration

    OCPP 1.2: Open Charge Point Protocol (OCPP) is an open protocol between charging stations and managing central system. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 34: Ocpp Engine Setup Web Page

    NOTE: Remember to remove the quotes when entering an address into the web browser. NOTE: Remember to have an integration enabled before accessing this site. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 35: Application Parameters

    3 – Debug System including error and information messages. Default parameter: 2 – Info CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 36: Powerstudio Engine

    Default factory parameters: Password Username: admin Password: 1234 CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 37: Charge Box (Cb)

    OCPP Listening port (public) User (for the CB server) New password Authentication parameters. Repeat password CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 38: Ocpp Settings

    Use OCPP time synchronization point. Optional: Time can be synchronized through NTP server under setup.html web page. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...
  • Page 39 Meter value sample interval NOTE: Set 0 to disable meter values messages. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 40: Management System (Cs)

    Authentication for central system. Password Tag format stored and sent to the Central ID tag endianness System. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 41: Ssl Certificates

    Description Save settings and apply. Refresh data entered. Import an XML file template configuration. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 42: Logs

    System logs OCPP messages. Operative system messages. Application logs Show only OCPP logs stored. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 43: Step By Step Integrations Procedure

    This page allows setup the integration enabled in step above. Use following default credentials: Username admin Password 1234 CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...
  • Page 44 Click on Save setup to confirm. Wait a few seconds until equipment restarts. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 45: Url Summary Table

    PowerStudio version http://”IP_ADDRESS”/html/devstat.html Devices status http://”IP_ADDRESS”/html/log http://”IP_ADDRESS”:65432 Integration enable/disable http://”IP_ADDRESS”:8080 Active Integration configurator CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 46: Charge Station Monitoring

    Default factory credentials can be changed using CirCarLife NOTE Scada Editor Software (not included with charge point) CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 47: Circarlife Client Software

    Enter IP address and port shown in the last example. IP address: Port: 80 EXAMPLE Click OK to connect to the charge point. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...
  • Page 48  Also is it possible to login into the system as an anonymous user. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com –...

  • Page 49: Web Browser

     Note: If you want to log as an anonymous user, enter the word “anonymous” in username and password fields. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com –...

  • Page 50: Circarlife Scada Client Overview

    Screen information Status bar Following section describes in detail each of the points mentioned above. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 51: Menu Bar

    Exports currently active view. This option can be active or not Export depending on the view in progress. Exit Close the client software. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 52: Views Menu

    Displays the events log or the active events window. Device status Display the general status of all connected devices. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 53: General Menu

    Changes the appearance of the client application (Skin). Graphs properties Changes graph appearance. About Displays client application information. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 54: Toolbar

    Displays the properties window of the current view. Print Allows us to print the current view. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...

  • Page 55: Toolbar Setup Menu

    Engine status Status Description Online CirCarLife Scada engine and working properly. Offline CirCarLife Scada engine. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...
  • Page 56 “Enable menu and toolbar” option in editor “Preferences”. In the latter case it will not be possible to make it appear again from the client application. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com –...

  • Page 57: Appendix A: Scada Software Features

    Channel error Unable to open communications port. Communications fault Some devices cannot communicate properly. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail: circontrol@circontrol.com...

  • Page 58: View Selection

    “Devices” option is located under "Views" option from the menu bar. Also accessible from toolbar. CIRCONTROL, S.A. – Innovació, 3 – 08232 – Viladecavalls (Barcelona) Tel.: +34 937 362 940 – Fax: +34 937 362 941 Web: www.circontrol.com – E-mail:...
