  • Page 1 User Manual MIOE-3816 1 MS/s, 16-bit, 16-ch Multifunction Card with MIOE interface...

  • Page 2: Product Warranty (2 Years)

    Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 3: Technical Support And Assistance

    This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
  • Page 4 MIOE-3816 User Manual...

  • Page 5: Table Of Contents

    Installation..........7 Unpacking ....................8 Driver Installation ..................9 Figure 2.1 Setup Screen of Advantech Automation Software ..9 Figure 2.2 Different Options for Driver Setup ......10 Device Setup & Configuration ..............11 Figure 2.3 The Device Setting of MIOE-3816......11 Figure 2.4 Device Setting page ..........
  • Page 6 B.1.6 Analog Input Trigger Source............35 Table B.2: Analog Input Data Format ........36 Table B.3: Full Scale Values for Input Voltage Ranges..... 36 MIOE-3816 Analog Output Operation............. 36 B.2.1 Analog Output Ranges ............... 36 B.2.2 Analog Output Operation Modes ..........37 B.2.3...

  • Page 7: Chapter 1 Introduction

    Chapter Introduction This chapter introduces MIOE- 3816 and and its typical applica- tions. Sections include:  Features  Applications  Installation Guide  Software Overview  Roadmap  Accessories...

  • Page 8: Features

    (up to 500 kHz) for each channel. Onboard Ring Buffer Memory There are 4k samples ring buffer for AI and AO on MIOE-3816. This is an important feature for faster data transfer and more predictable performance under Windows system.

  • Page 9: Applications

    Waveform acquisition and analysis  Process control and monitoring  Vibration and transient analysis Installation Guide Before you install your MIOE-3816 card, please make sure you have the following necessary components:  MIOE-3816 DA&C card  MIOE-3816 User Manual ...
  • Page 10 Figure 1.1 Installation Flow Chart MIOE-3816 User Manual...

  • Page 11: Software Overview

    Software Overview Advantech offers a rich set of DLL drivers, third-party driver support and application software to help fully exploit the functions of your MIOE-3816 card:  Device Drivers (on the companion DVD-ROM)  LabVIEW driver  Advantech DAQ NAVi ...
  • Page 12 Advantech Navigator. Programming with DAQNavi Device Drivers Function Library Advantech DAQNavi Device Drivers offer a rich function library that can be utilized in various application programs. This function library consists of numerous APIs that support many development tools, such as Visual Studio .Net, Visual C++, Visual Basic, Delphi and C++ Builder.

  • Page 13: Chapter 2 Installation

    Chapter Installation This chapter provides a packaged item checklist, proper instructions for unpacking and step-by-step procedures for both driver and card installation. Sections include:  Unpacking  Driver Installation  Hardware Installation  Device Setup & Configuration...

  • Page 14: Unpacking

    Unpacking After receiving your MIOE-3816 package, inspect the contents first. The package should include the following items:  MIOE-3816 card  Companion DVD-ROM (Device Drivers included)  Startup Manual The MIOE-3816 card harbor certain electronic components vulnerable to electrostatic discharge (ESD). ESD can easily damage the integrated circuits and certain compo- nents if preventive measures are ignored.

  • Page 15: Driver Installation

    Driver Installation We recommend you to install the driver before you install the MIOE-3816 card into your system, since this will guarantee a smooth installation process. The Advantech DAQNavi Device Drivers Setup program for the MIOE-3816 card is included in the companion DVD-ROM that is shipped with your DA&C card package.
  • Page 16 Manual After your card is properly installed on your system, you can now configure your device using the Advantech Navigator Program that has itself already been installed on your system during driver setup. A complete device installation procedure should include device setup, configuration and testing. The following sections will guide you through the Setup, Configuration and Testing of your device.

  • Page 17: Device Setup & Configuration

    Device Setup & Configuration The Advantech Navigator program is a utility that allows you to set up, configure and test your device, and later stores your settings on the system registry. These settings will be used when you call the APIs of Advantech Device Drivers. Take the following- PCIE-1810 details as an example.
  • Page 18 Configuring the Device Please go to the Device Setting to configure your device. Here you can config- ure not only the Analog Input/Output of MIOE-3816 but also Digital Input/Output. Figure 2.4 Device Setting page After your card is properly installed and configured, you can go to the Device Test page to test your hardware by using the testing utility supplied.

  • Page 19: Chapter 3 Signal Connections

    Chapter Signal Connections This chapter provides useful informa-tion about how to con- nect input and output signals to the MIOE-3816 card via the I/O connector. Sections include:  Overview  BoardID Settings  Signal Connections  Field Wiring Considerations...

  • Page 20: Overview

    MIOE-3816 card via the I/O connector. Jumper Settings Please refer to Figure 3.1 for jumper and switch locations on MIOE-3816. Figure 3.1 Connectors and jumper locations Default configuration after power on, and hardware reset is to set all the analog input and analog output channels to open status (the current of the load can’t be sink) so...

  • Page 21: Signal Connections

    Signal Connections Pin Assignments The I/O connectors on the MIOE-3816 are terminal blocks. Figure 3.2 shows the pin assignments for the terminal blocks on the MIOE-3816, and Table 3.3 shows its I/O connector signal description. Figure 3.2 I/O Connector Pin Assignments...

  • Page 22: I/O Connector Signal Description

    Digital Ground. This pin supplies the refer- ence for the digital channels at the I/O connec- tor as well as the +5V and +12V DC supply. The ground references (AGND and DGND) are connected together on the MIOE-3816. MIOE-3816 User Manual...

  • Page 23: Analog Input Connections

    (0.3A maximum) 3.3.2 Analog Input Connections The MIOE-3816 supports either 16 single-ended or 8 differential analog inputs. Single-ended Channel Connections Single-ended connections use only one signal wire per channel. The voltage on the line references to the common ground on the card. A signal source without a local ground is called a “floating”...
  • Page 24 To avoid the ground loop noise effect caused by common-mode voltages, connect the signal ground to the LOW input. Do not connect the LOW input to the MIOE-3816 ground directly. In some cases you may also need a wire connection between the MIOE-3816 ground and the signal source ground for better grounding.

  • Page 25: Digital Signal Connections

    Analog Output Connection The MIOE-3816 provides two AO output channels. You can use the internal precision -5 V or -10 V reference to generate 0 to +5 V or 0 to +10 V AO output. Use an exter- nal reference for other AO output ranges. The maximum reference input voltage is ±10 V and maximum output scaling is ±10 V.

  • Page 26: Field Wiring Considerations

    Field Wiring Considerations When you use MIOE-3816 cards to acquire data from outside, noises in the environ- ment might significantly affect the accuracy of your measurements if due cautions are not taken. The following measures will be helpful to reduce possible interference run- ning signal wires between signal sources and the MIOE-3816 card.

  • Page 27: Appendix A Specifications

    Appendix Specifications...

  • Page 28: Analog Input

    Bipolar Range Unipolar Range ±1 LSB For Full Scale Step ±10V 1.04 us ±5V, 0 ~ 10V 1.04 us ±2.5V 0 ~ 5V 1.04 us ±1.25V, 0 ~ 2.5V 4 us ±0.625V 0 ~ 1.25V 5 us MIOE-3816 User Manual...

  • Page 29: Analog Output

    Output Impedance Max. 500 pF Capacitive Load Digital Input/Output 24 (shared), TTL compatible Channels 0.8V max. Input Voltage High 2.0 V min. 0.8 V max.@ +15 mA (sink) Output Voltage High 2.0 V min.@ -15 mA (source) MIOE-3816 User Manual...

  • Page 30: Counter/Timer

    3.3 V @ 2.49 A, 12 V @ 408 mA Max. 0~50°C (32~122°F) (refer to IEC 68-2-1,2) Operating Temperature -20 ~ 70°C (-4 ~ 185°F) Storage 5~85%RH non-condensing (refer to IEC 68-1,-2,-3) Operating Relative Humidity 5~95%RH non-condensing (refer to IEC 68-1,-2,-3) Storage CE/FCC certified Certifications MIOE-3816 User Manual...

  • Page 31: Appendix B Operation Theory

    Appendix Operation Theory...

  • Page 32: Analog Input Operation

    AI converter.  AI converter conceives the rectified voltage from PGIA and transfers it into the corresponding digital data format.  Trigger/Clock control logic enables/disables the whole process and deter- mines acquisition timing interval. MIOE-3816 User Manual...

  • Page 33: Analog Input Ranges And Gains

    B.1.2 Analog Input Ranges and Gains The MIOE-3816 can measure both unipolar and bipolar analog input signals. A uni- polar signal can range from 0 to 10 V FSR (Full Scale Range), while a bipolar signal extends within ±10 V FSR. The MIOE-3816 provides various programmable gain lev- els and each channel is allowed to set its own input range individually.
  • Page 34 SCAN CLKs from SCAN CLK counter. Once the acquisition procedure inside Acquisition Windows is set, the incoming CLKs must fit in the user-specified acquisition sequence, or the CLKs may be gated off. Refer to the following figures for more details. MIOE-3816 User Manual...
  • Page 35 Other scanning procedure applications timing diagram. MIOE-3816 User Manual...
  • Page 36 MIOE-3816 User Manual...

  • Page 37: Analog Input Trigger Modes

    B.1.4 Analog Input Trigger Modes The MIOE-3816 supports four trigger modes and pause function. User can start or stop the operation by trigger mode selection. An extra 32-bit counter is dedicated to delay-trigger mode and about-trigger mode, and user can set it as the number of delay SCAN CLKs before trigger or the number of holding SCAN CLKs after trigger.
  • Page 38 SCAN CLKs has been taken after the trigger event. User can set the delay number of SCAN CLKs by a 32-bit counter. Delay to start trigger acquisition starts when the MIOE-3816 detects the trig-ger event and stops when you stop the opera- tion.
  • Page 39 Once a trigger event happens, the on-going data acquisition will continue until the designated amount of SCAN CLKs have been reached. When the MIOE-3816 detects the selected about-trigger event, the card keeps acquiring the preset number of samples, and kept them on the buffer.

  • Page 40: Analog Input Scan/Conv Clock Source

    B.1.5 Analog Input SCAN/CONV Clock Source The MIOE-3816 can adopt both internal and external clock sources to accomplish pacer acquisition. You can set the clock and trigger sources conveniently by soft- ware. The figure can help you understand the routing route of clock and trigger gen- eration.

  • Page 41: Analog Input Trigger Source

    External digital (TTL) trigger  Analog threshold trigger  With MIOE-3816, user can also define the type of trigger source as rising-edge or falling-edge. These following sections describe these trigger sources in more detail.  External Digital (TTL) Trigger For analog input operations, an external digital trigger event occurs when the MIOE- 3816 detects either a rising or falling edge on the External AI TTL trigger input.

  • Page 42: Mioe-3816 Analog Output Operation

    User should connect ana-log signals from external device or analog output channel on board to external input signal ATRG0/1. On the MIOE-3816, the threshold level is set using a dedicated 16-bit DAC. By software, you can program the thresh- old level by writing a voltage value to this DAC;...

  • Page 43: Analog Output Operation Modes

    DACs’ buffers on MIOE-3816. When MIOE-3816 detects a trigger, it outputs the values stored in its buffer. When the buf- fer’s storage decreases, the card sends an interrupt request to the host PC which in turn sends samples to the buffer.

  • Page 44: Analog Output Clock Sources

    B.2.3 Analog Output Clock Sources The MIOE-3816 can adopt both internal and external clock sources for pacing the analog output of each channel:  Internal AO clock with 32-bit Divider  External AO output clock from connector The internal and external AO clocks are described in more detail as follows: ...

  • Page 45: Digital Input/Output Operation

    Digital Input/Output Operation The MIOE-3816 supports 24 digital I/O channels. You can use each byte as either an input port or an output port by configuring the corresponding parameter; and all four channels of the byte have the same configuration.
  • Page 46 MIOE-3816 counter will use internal clock as time base, to fulfill the fre- quency you want to set. See the figure below as example, the desired frequency is 5 MHz.
  • Page 47 Delay Pulse Generation: Using MIOE-3816 internal clock, you can change the logic level within a specific period, starting from a trigger signal connecting to counter gate input. For example, if you define the count equals to 3 (as figure below), a counter output will change its status after 3 pulses of internal clock sig- nals pass, after a trigger signal from counter gate becomes high.
  • Page 48 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2017...
