Advantech MIO-5376 Startup Manual

MIO-5376 3.5" MI/O-Compact SBC, AMD Ryzen™
Embedded R2000 Series, DDR4, 3xGbE,
PoE 802.3af, HDMI, DP , CANBus, M.2 2230/80,
M.2 3042/52, DC-In 12-24V, & iManager
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 x SATA cable, 30 cm (P/N: 1700006291)
2. 1 x SATA power cable, 35 cm (P/N: 1700031583-01)
3. 1 x USB 2.0 cable, 20 cm (P/N: 1700030406-01)
4. 1 x USB 3.2 cable, 35 cm (P/N: 1700032181-01)
5. 1 x Audio cable, 20 cm (P/N: 1700019584-01)
6. 2 x COM RS-232/422/485 cables, 20 cm (P/N:
1700030404-01)
7. 2 x COM RS-232 cables, 20 cm (P/N: 1700031582-01)
8. 1 x Heatsink for 12W/15W(P/N:1970005548T001)
9. 1 x Screw kit (2 sets of screws for the M.2 device & 4
sets of screws and stand-off for the heatsink/cooler)
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1:
For detailed contents of MIO-5376, please refer
to information on the support website: http://sup-
port.advantech.com.tw
Note 2:
Adobe Reader is required to view any PDF file.
Adobe Reader can be downloaded at: http://get.
adobe.com/tw/reader/otherversions. (Adobe is a
trademark of Adobe Systems Incorporated.)
For more information about this and other Advantech
products, visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and customer service, visit our
support website at:
http://support.advantech.com.tw
This manual is for the MIO-5376 series.
Part No. 2046537600
Printed in China
Specifications
General
• CPU:
- R2314 SoC with AMD Radeon™ Graphics
- R2514 SoC with AMD Radeon™ Graphics
• System Memory: Dual Channel/SODIMM DDR4-2666
MT/s, up to 32GB
• BIOS: AMI EFI 256 Mbit
• Watchdog timer: 65536 levels, 0~65535 sec
• iManager 3.0: Yes
• Battery: Lithium 3V/210mAH
• Audio: Supports High Definition Audio (HD), Line-In,
Line-Out, and Mic-In.
Expansion Interface
• 1x M.2 E-Key 2230 module (PCIe x1, USB 2.0 to support
a wireless module)
• 1 x M.2 B-Key 3042/3052 module (PCIe x1, USB 3.2/2.0
to support a 5G_GNSS/LTE module)
• 1 x M.2 M-Key 2280 module (PCIe Gen3 x4, optional
SATA)
Display
• Controller: Integrated AMD Radeon Graphics
• Maximum resolution:
- 1 x LVDS dual channel 18/24-bit LVDS up to 1920 x
1200
- 1 x HDMI2.0 up to 4Kx2Kx24 bpp @60Hz
- 1 x DP1.4 up to 4096x2304x36 bpp @60Hz
• Multiple displays: 3 simultaneous displays
Ethernet Interface
• Max. Speed: 2.5Gbe/port
• Controller: 3 x Intel® i226
• PoE (Optional): LAN2 & LAN3 port features PoE sup-
port 802.3af 15.4W/port with optional MIOe-PSE power
module.
I/O
• Internal I/O: 1 x SATA, 2 x USB 2.0, 2 x USB 3.2, 2 x
RS-232/422/485, 2 x RS-232, 1x I2C/SMB (optional), 8-bit
GPIO, Inverter, HD Audio, 1 x CANBus 2.0
• Rear I/O: 3 x RJ-45, 1 x HDMI, 2 x USB 3.2, 1 x DP
• Power connector type: 2-pin phoenix connector
Mechanical and Environmental
• Dimensions (L x W): 146 x 102 mm (5.7" x 4")
• Power requirement: Vin: 12 V-24 V ±10%
• Operating temperature:
- Standard: 0 ~ 60 °C (32 ~ 140 °F)
- Extended: -40 ~ 85° C (-40 ~ 185 °F)
Edition 1
Mar. 2023
