Hollywood Racks HR7060 Assembly Instructions Manual

Crosstrack 2 bikes
Hide thumbs

Advertisement

Quick Links

Download this manual
• 2 Bikes
• Max tire width: 4"
• Max wheelbase: 52"/1320mm
• Max Capacity: 66 lbs per bike
• 1-1/4" or 2" class 2 hitch receiver
required
INFO@HOLLYWOODRACKS.COM
ASSEMBLY INSTRUCTIONS
CROSSTRACK
For video assistance
For video assistance
scan the QR code:
HR7060
2 BIKES
HR7060-V1.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HR7060 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hollywood Racks HR7060

Summary of Contents for Hollywood Racks HR7060

  • Page 1 HR7060 ASSEMBLY INSTRUCTIONS CROSSTRACK • 2 Bikes • Max tire width: 4” • Max wheelbase: 52”/1320mm • Max Capacity: 66 lbs per bike 2 BIKES • 1-1/4“ or 2” class 2 hitch receiver required For video assistance For video assistance scan the QR code: INFO@HOLLYWOODRACKS.COM...
  • Page 3 M10 SELF LOCKING NUTS: QTY 8 LOCKING 5/8” DIAMETER THREADED M10 WASHERS: QTY 8 HITCH PIN WITH 8’ CABLE AND KEYS COMBINATION 14MM/19MM WRENCH 5/8” x 3” REFLECTOR TAPE 4MM,5MM, 5/32” ALLEN 6 PCS 15 x 80 WRENCH SET 13MM, 17MM SOCKET SET HR7060-V1.

  • Page 4: Installation

    Insert the bike racks hitch tube into the vehicles receiver and align the holes. Install the threaded hitch pin through the receiver tube and hitch tube. Tighten securely using the combination wrench. Snap the locking head onto the end of the threaded hitch pin. HR7060-V1.
  • Page 5 After the hardware on both sides has been installed and the hitch tightener is correctly positioned, tighten the nuts securely using Handle the 17mm combination wrench. Step 3 Pull the handle on the Crosstrack mainframe to tilt the rack to the in use position. HR7060-V1.
  • Page 6 To open the wheel arms, press the red button on the ratchet trigger and lift the arm up. Note: For safety, the red button must be pressed in while lifting the arm. BUTTON HR7060-V1.
  • Page 7 External Bridge (D) Wheel Tray (B2) Wheel Tray (B1) Support Bracket Insert the Bolts(F) through the Bridge Spacers (E) and pass them through the external bridge, wheel trays and support bracket. Bolts (F) Bolts (F) Bridge Spacers (E) Bridge Spacers (E) HR7060-V1.
  • Page 8 Tip: Tilt the bike rack up for easy access to the nuts and tighten securely with the 17mm socket tool. 17mm socket tool Repeat Step 5 for wheel trays (C1) and (C2). * For refernce only. Location of wheel trays on vehicle HR7060-V1.
  • Page 9 Included is a set of 6 reflector tape pieces. You may place as needed. Suggested areas are shown below. Wheel Tray Handle Wheel Tray Arm (underneath) HR7060-V1.
  • Page 10 24” location shown on the left. (note: Depending on your bikes geometry, the best hole position may be different than the recommended location shown on the left.) 20” Always stay within the tire spindle range shown on page 10. HR7060-V1.
  • Page 11 (sold seperately) 3. Mount the heaviest bike onto the innermost tray. Handlebars on the drivers side. Front wheel should be resting firmly against the wheel block. Bike tires should be at the recommended tire pressure. HR7060-V1.
  • Page 12 4. Press the wheel arms firmly against your bike’s tires. Tire spindle must make contact with the tire in the specified range as shown below. If the tire contact is not within the specified range, adjust the position of the tire spindle, and/ or wheel block. HR7060-V1.
  • Page 13 MOUNTING PRECAUTIONS AND SUGGESTIONS Wheel arms must not be in contact with fenders or racks Bike must not extend beyond side view mirrors Wheel arms must be located within the specified range for secure and safe mounting of bikes. HR7060-V1.
  • Page 14 BOTH WHEELS BRAKE NOT CENTERED ADJUST TIRE SPINDLE LOCATION FOR RE-POSITION FRONT NOT OK BOTH WHEELS WHEELBLOCK NOT CENTERED Possible handlebar to seat interference: Lower height of seat, or change front wheel block loca- tion and adjust tire spindle positions. HR7060-V1.
  • Page 15 Maintain pres- sure on the button while pulling the arms down. ACCESSING YOUR CARGO AREA Pull the handle on the mainframe (A). Lean the bike rack down until it reaches the bottom notch. HR7060-V1.

  • Page 16: Warranty

    (at its option) a defective part without charge for labor or parts. Hollywood Racks may elect (at its option) to issue a refund equal to the purchase price paid for the prod- uct.

  • Page 17: Optional Accessories

    • 5” wide aluminum ramp helps and emergency light funtions load heavier bikes. Telescopes Due to variances in vehicles electrical systems, this product is not compatible up to 54” in length. with all vehicles. Please check our website at Hollywoodracks.com for more information. HR7060-V1.
