Hollywood Racks HR150 Quick Start Manual

Tow ball rack – 2 bike capacity

Advertisement

Model HR150 Tow Ball Rack – 2 Bike Capacity
Fig. 3
1. Unfold rack – but DO NOT clamp open
2. Rotate bike support arms forward (Fig. 1)
3. Mount bike carrier on tow ball so that the tow
ball is INSIDE of safety ring. (Fig. 2)
4. Push down on center handle until it snaps into
place. Insert pin through safety handle (Fig. 3)
5. Swing safety ring onto latch, hold in place while
tightening the knob (Fig. 4)
Fig. 1
Caution:
Drive slowly when on rough or dirt roads
Always recheck tightness of knobs and straps
Maximum weight on rack is 35 Kg
For use on 50 mm tow balls ONLY
Fig. 4
Fig. 2
