Page 1 AXON High Intensity Approach & ICAO Runway Threshold Inset Lights, 12-Inch ICAO Appr O Approach Centerline/Cr oach Centerline/Crossbar; ICA ossbar; ICAO Appr O Approach Sider oach Siderow; ICAO Runwa O Runway Thr y Threshold and End; ICA eshold and End; ICAO Runwa O Runway Thr y Threshold eshold...
Page 3: Disclaimer / Standard Warranty
Material Handling Precautions and Storage precautions that must be followed. ADB SAFEGATE reserves the right to examine goods upon which a claim is made. Said goods must be presented in the same condition as when the defect therein was discovered. ADB SAFEGATE furthers reserves the right to require the return of such goods to establish any claim.
Page 4 Use this equipment only as described in the manual. ADB SAFEGATE cannot be held responsible for injuries or damages resulting from non-standard, unintended uses of its equipment. The equipment is designed and intended only for the purpose described in the manual. Uses not described in the manual are considered unintended uses and may result in serious personal injury, death or property damage.
Page 5: Table Of Contents
6.1 ICAO Approach Centerline / Crossbar, Approach Siderow ....................62 6.2 ICAO Runway Threshold, END, Threshold/End........................63 6.3 ICAO Runway Threshold Wingbar............................64 7.0 Spare Parts ............................65 7.1 ICAO Approach Centerline/Crossbar, Approach Siderow ...................... 66 UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 6 9.0 POWER TABLE........................... 75 10.0 CABLE LOSS ............................ 77 A.0 SUPPORT ............................79 A.1 ADB SAFEGATE Website ................................79 A.2 Recycling....................................80 A.2.1 Local Authority Recycling .............................. 80 A.2.2 ADB SAFEGATE Recycling............................... 80 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 7 Figure 45: Ground Washer and Bolt..............................49 Figure 46: SJO Secondary Cable................................. 50 Figure 47: Insert Tool................................... 50 Figure 48: Locking/Releasing Secondary Wires ..........................51 Figure 49: Wire Tie and Nylon Hex Nut ............................... 51 UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 8 Figure 62: Star Pattern..................................59 List of Tables Table 1: Maintenance tasks................................. 26 Table 2: Expected service life (only critical areas defined) ........................ 29 Table 3: Interoperability matrix — 12 inch ............................73 viii Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 9: Safety
1.0 Safety Introduction to Safety This section contains general safety instructions for installing and using ADB SAFEGATE equipment. Some safety instructions may not apply to the equipment in this manual. Task- and equipment-specific warnings are included in other sections of this manual where appropriate.
Page 10: Introduction To Safety
• Using this equipment in ways other than described in this manual may result in personal injury, death or property and equipment damage. Use this equipment only as described in this manual. Failure to follow this instruction can result in serious injury or equipment damage Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 11: Material Handling Precautions: Fasteners
Note To minimize the risk of errors, the ADB SAFEGATE Sales Representative will have information on which gasket goes with which base. This information is also provided in the product Data sheets, the User Manuals and the Spare Part Lists.
Page 12: Operation Safety
• ALLOW ONLY QUALIFIED PERSONNEL TO MAKE REPAIRS. REPAIR OR REPLACE THE MALFUNCTIONING COMPONENT ACCORDING TO INSTRUCTIONS PROVIDED IN ITS MANUAL. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN DEATH OR EQUIPMENT DAMAGE Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 13: Material Handling Precautions: Fasteners
Note To minimize the risk of errors, the ADB SAFEGATE Sales Representative will have information on which gasket goes with which base. This information is also provided in the product Data sheets, the User Manuals and the Spare Part Lists.
Page 15: About This Manual
International Electrotechnical Committee ILCMS Individual Light Control and Monitoring System Light Emitting Diode NATO North Atlantic Treaty Organization STAC Service Technique de l'Aviation Civile (France) STANAG Standardization Agreement (NATO) UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 17: Introduction
Figure 1: 12-Inch Fixtur 12-Inch Fixture e Note EQ light fixtures are not fail-open light fixtures. The monitoring as well as the control functionality is handled by the ILCMS system. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 18: Product Information
▪ Reduced bottom pan profile allowing for very shallow base can installation ▪ LED pulse width modulated (PWM) at 400 Hz optimizing LED performance and eliminating perceptible flicker to a moving human observer throughout the range of brightness steps Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 19 Brief 67 Category C2 is defined as a 1.2/50 μS – 8/20 μS combination wave, with a peak voltage of 10,000 V and a peak current of 5,000 A UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 20: Dimensions And Weight
The weight and measurement [A] of the high intensity approach light fixtures. Version Weight Dimension ICAO AC-AS / RT / RW 6.8 kg / 304 mm / 12 in 15 lb Figure 2: 12-Inch Fixtur 12-Inch Fixtures Exploded View es Exploded View Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 21: Installation
4.0 Installation Install the inset light fixture in a base provided by ADB SAFEGATE. Note If the inset light fixture is to be installed on another type of base or adapter ring not provided by ADB SAFEGATE, contact ADB SAFEGATE. CAUTION Use of incorrect combination of gaskets, bolts and nuts can cause severe damage to the product and create multiple safety risks.
Page 22: Safety Considerations
FAILURE TO FOLLOW THESE SAFETY PROCEDURES CAN RESULT IN PERSONAL INJURY OR DEATH. ▪ ALLOW ONLY QUALIFIED PERSONNEL TO INSTALL ADB SAFEGATE AND AUXILIARY EQUIPMENT. USE ONLY APPROVED EQUIPMENT. USING UNAPPROVED EQUIPMENT IN AN APPROVED SYSTEM MAY VOID FAA APPROVALS. OBSERVE AND FOLLOW THE SAFETY INSTRUCTIONS IN THIS DOCUMENT AND ALL OTHER RELATED DOCUMENTATION.
Page 23: Inspect On Delivery
PID/SN and position of the light fixture in, for example, a site documentation table. The information is required for remote activation and administration of control and monitoring functionality from a substation. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 24: Verify Input Requirements And Equipment Needed
▪ Air compressor with high pressure nozzle - Optional to assure mounting surface is free of debris. ▪ One brush or cloth. Note Provided that the base intended to receive the light fixture has been properly installed, no other specific tool is required. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 25: Installation Overview
The 12-inch light fixture is installed in a 12-inch base. The bases are interconnected by means of conduits protecting the cables. The series transformer is installed under the light or in a separate pit. See data sheet A.05.120 or DS–2012 for more information on base cans. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 26: Typical L-868 Assembly
Failure to use properly installed anti-vibration lock washers will cause mounting bolts to become loose. The cams (or steps) of each half of the lock washer must face each other. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 27: Interoperability
The grounding point is indicated by a grounding symbol that is located on the bottom side. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 28: Testing The Light Fixture For Leaks (Water-Tightness)
▪ Flat head screwdriver ▪ Pressure test fitting tool to be used (pt no.44A6104/A) for watertight testing 1. Remove the pressure release screw and discard. Figure 7: Pr Pressur essure Release Scr e Release Screw Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 29 Pressure test fitting stud 3. Attach the shop airline to the lock hose plug sleeve. 4. Pressurize to 20 psi (130 kPa). 5. Submerge the pressure test fitting into a water tank. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 30: Toe-In
Assembly that toes the light beam to the right at a defined angle. Toed Left Assembly that toes the light beam to the left at a defined angle. Figure 9: T T oe-In oe-In Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 31 Straight or Toe-in ± 2 Mechanical ICAO Approach Siderow (AS) Straight or Toe-in ± 2 Mechanical ICAO Runway End (RE) Straight ICAO Runway Wingbar (RW) Straight or Toe-in ± 2 Mechanical UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 32: Light Emission Directions
The color of the emitted light is indicated with a painted dot on the top cover in front of the prism. Figure 10: Light Emissions Dir Light Emissions Direction ection Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 33: Maintenance
When a light fixture has been removed from its base, the base must either be fitted with a cover or a spare light fixture must be put in its place to avoid a trip and/or fall hazard. It is recommended that only authorized personnel disassemble fittings with prior agreement from ADB SAFEGATE. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 34: Basic Maintenance Program
Any issues found during maintenance tasks should be corrected accordingly and properly documented. A proper asset management system such as ADB Safegate's ALIS can help to store/document data and can provide valuable information on local presiding conditions for preventive maintenance planning. This can then be used to minimize the need for reactive maintenance.
Page 35: Recommended Maintenance Program For Optimal Service Life
▪ Green – Areas outside Red and Amber areas NOTICE A reliable means of recording the location history of fittings (i.e. ADB Safegate ALIS) is recommended to ensure that the maximum duration in critical red areas of the runway is not exceeded.
Page 36: Recommendation
▪ We recommend that inspection intervals are halved for aging units that have reached more than 75 % of their expected lifetime. ▪ We recommend that AGL in critical areas are rotated. ▪ To achieve a proper location rotation and individual asset, data needs to be recorded. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 37 Contact to your local sales representative if you have any questions or would require some assistance to go through local conditions and see how we can help establish a well-defined maintenance planning to optimize the expected service life of your investment. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 38: Cleaning Procedure For The Prisms Of An Inset Light Fixture
Protocol for Introducing New Chemical Solutions ▪ Verify the chemical's intended use on similar materials and products, adhering to ADB Safegate's recommendations. ▪ Conduct initial tests on a few units to ensure there is no damage to the light fixture or gaskets before applying the chemical to a larger installation.
Page 39 ▪ After cleaning, thoroughly dry each prism with a soft, lint-free cloth to prevent water spots and ensure clear illumination. By following these detailed instructions, you can maintain the integrity and performance of the inset light fixtures at the airfield, ensuring safety and visibility are upheld. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 40: Workshop Maintenance
1. Put the soft cloth on a sturdy surface and place the light fixture on the cloth with the top cover facing down. The soft cloth is to protect the top cover from scratches 2. Remove the 4 fixation screws. Make sure to dispose of the old screws. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 41: Disconnect The Bottom Pan From The Top Cover
Make sure to dispose of the old bottom pan. Connect the Bottom Pan to the Top Cover. Close the Light Fixture. 5.4.4 Replace the Wire Harnesses Open the Light Fixture UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 42 Approach Centerline, Approach Siderow, Runway Wingbar, Figure 16: Thr Three Prisms (Unidir ee Prisms (Unidirectional) ectional) SP.EW00114-000-01 (2 pcs per light) Connect the Bottom Pan to the Top Cover Close the Light Fixture. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 43: Replace The Light Engine Assembly
5. Attach the new light engine using 3 M4x8 new screws per light engine assembly in the sequence displayed in the pattern below at 22 inch-pound (2.5 Nm). Figure 18: Scr Screw Sequence ew Sequence Connect the Bottom Pan to the Top Cover Close the Light Fixture. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 44: Replace The Prism And Its Gasket
3. Remove the 3 M4x8 screws per prism bracket and remove the prism bracket from the top cover. Make sure to dispose of the old screws and prism bracket. Figure 19: (Un)Installation of Prism Br (Un)Installation of Prism Brack acket et Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 45 Make sure to dispose of the old prisms and gaskets. 6. Install the new prism into the new prism gasket and clean fingerprints with a clean rag or a wipe. Figure 21: Prism Gask Prism Gasket et UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 46 Press the pointy part of the tool into the corner of the top cover as shown below and hinge down. Figure 22: Alignment T Alignment Tool b. Make sure the prism protection plate is properly aligned under the prism bracket and not visible. Figure 23: Pr Proper Alignment oper Alignment Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 47: Replace The Secondary Cable - Style-6 Cord Set
▪ Small flat-head screwdriver or insert tool (part no: 236-332) Figure 26: Inser Insert T t Tool Open the Light Fixture Disconnect the Bottom Pan from the Top Cover UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 48 Figure 27: Locking/Releasing Secondar Locking/Releasing Secondary Wir y Wires es 4. Cut the wire tie and remove the nylon hex nut. Figure 28: Wir Wire Tie and Nylon Hex Nut e Tie and Nylon Hex Nut Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 49 7. Remove the old cable gland gaskets and replace with new cable gland gaskets. Make sure to dispose of the old cable gland gaskets. Figure 30: Cable Gland Gask Cable Gland Gasket et UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 50 10. Pull approximately 100 mm (~4 inches) of the new secondary wires through the new cord-set retainer disc plate. Make sure the wires are on the inside (the converter side) of the bottom pan. Figure 32: Installation of Secondar Installation of Secondary Cable y Cable Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 51 Gently release the downward pressure from screwdriver (or insert tool) and remove it from the opening to lock the wire in place. d. Repeat steps a-c for the other wire. Connect the Bottom Pan to the Top Cover Close the Light Fixture UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 52: Replace The Secondary Cable - French 3-Pin Cord Set
Gently release the downward pressure from screwdriver (or insert tool) and remove the screwdriver (or insert tool), d. Repeat steps a-c for the other wire. Figure 36: Locking/Releasing Secondar Locking/Releasing Secondary Wir y Wires es Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 53 5. Flip the bottom pan (converter side down) and remove the bolt and the cord-set retainer disc. Make sure to dispose of the old bolt and cord-set retainer disc Figure 38: Bolt and Cor Bolt and Cord-set Retainer Disc d-set Retainer Disc UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 54 8. Remove the old cable gland gaskets and install the new cable gland gaskets. Make sure to dispose of the old cable gland gaskets. Figure 40: Cable Gland Gask Cable Gland Gasket et Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 55 11. Pull approximately 100 mm (~4 inches) of the new secondary wires through the new cord-set retainer disc plate. Make sure the wires are on the inside (the converter side) of the bottom pan. Figure 42: Installation of Secondar Installation of Secondary Cable y Cable UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 56 13. Flip the bottom pan and tighten the new cord-set retainer bolt at 22 in-lbs (2.5 Nm). Figure 44: Cor Cord-set Retainer Bolt d-set Retainer Bolt 14. Connect the ground wire of the cord-set to the bottom pan using the bolt and the washer. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 57 Gently release the downward pressure from screwdriver (or insert tool) and remove it from the opening to lock the wire in place. d. Repeat steps a-c for the other wire. Connect the Bottom Pan to the Top Cover Close the Light Fixture. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 58: Replace The Secondary Cable - Sjo Cord Set
▪ Screwdriver or variable-speed torque drill driver with T20 Torx bit ▪ Small flat-head screwdriver or insert tool (part no: 236-332) Figure 47: Inser Insert T t Tool Open the Light Fixture Disconnect the Bottom Pan from the Top Cover. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 59 Wires es 4. Cut the wire tie and remove the nylon hex nut. Figure 49: Wir Wire Tie and Nylon Hex Nut e Tie and Nylon Hex Nut UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 60 Make sure to dispose of the old cable clamp, bolt, washer and lock washer. Figure 51: Cable Clamp, Bolt, W Cable Clamp, Bolt, Washer and Lock W asher and Lock Washer asher 7. Remove the secondary cable Make sure to dispose of the old secondary cable. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 61 Cable) 10. Insert the wires of the new secondary cable through the loosened gland gaskets, feed them through the bottom pan and flip the bottom pan (converter side up). UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 62 12. Place a new nylon hex nut around the two wires and secure them tightly with a wire tie at a position of 65 mm (2½ inches) from the end of the wires. Figure 55: Securing Wir Securing Wire Tie and Nylon Hex Nut e Tie and Nylon Hex Nut Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 63: Reset The Fail-Open Converter
▪ Converters with 1 connector have 2 fuse resistors ▪ Converters with 2 connectors have 4 fuse resistors Open the Light Fixture Disconnect the Bottom Pan from the Top Cover. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 64 Make sure to dispose of the old fuse resistor 5. Install the new fuse resistors by placing the legs in the corresponding sockets. Connect the Bottom Pan to the Top Cover Close the Light Fixture. 8. Perform a functional test. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 65: Replace The Top Cover Assembly
Tools to be used: ▪ Flat-head screwdriver ▪ Screwdriver or variable-speed torque drill driver with a T30 Torx bit. NOTICE Do not use an Impact driver. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 66: Close The Light Fixture
5.4.13 Close the Light Fixture Tools and equipment to be used: ▪ Flat-head screwdriver ▪ Screwdriver or variable-speed torque drill driver with a T30 Torx bit. NOTICE Do not use an Impact driver. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 67 Re-torque using the same star pattern and torque force. Figure 62: Star P Star Pattern attern 3. Follow the water-tightness test procedure. Note Refer to Testing the Light Fixture for Leaks (Water-tightness). UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 70: Icao Approach Centerline / Crossbar, Approach Siderow
3. This application meets the heat rise requirements in Engineering Brief 67D, section 2.13.1, "Arctic Kit Testing Requirements" WITHOUT an arctic kit. We do not offer an arctic kit with this configuration as the additional heat would be detrimental to the life of the LEDs. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 71: Icao Runway Threshold, End, Threshold/End
6. All Style 1 corded fixtures will include a ground lug. All Style 6 or 3-pole corded fixtures will be provided with grounding screw(s). 7. Only with RN (RT meets EB67d Arctic kit requirements on its own) UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 72: Icao Runway Threshold Wingbar
1. Includes standards NATO, EASA, STAC, TP 312 and MOS 139. 2. All Style 1 corded fixtures will include a ground lug. All Style 6 or 3-pole corded fixtures will be provided without a ground lug. Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 73: Spare Parts
Spare parts are available for inset light fixtures with and without the control and monitoring functionality. For more information, see www.adbsafegate.com and the spare part lists, or contact ADB SAFEGATE for assistance. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 74: Icao Approach Centerline/Crossbar, Approach Siderow
Prism kit, approach standard, package of 2 1 or2 SP.MG00021-G00-01 Prism kit, approach reinforced, package of 2 1 or 2 SP.MG00021-S00-01 Prism gasket, approach, package of 10 1 or 2 SP.MS00032-000-01 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 75 All screws for fastening are included. Component availability or design may be subject to change due to unforeseen circumstances. This document is subject to change or new information from ADB SAFEGATE, as and when available or if required, with reservation for error or price changes.
Page 76: Icao Runway Threshold, End, Threshold/End
Monitored converter, 2-con style 1 SJO jacketed cord sets SP.AS00307-M2J EQ converter, 1-con style 6 cord set SP.AS00307-R13 EQ converter, 1-con 3-pin cord set SP.AS00307-R1F EQ converter, 1-con style 1 SJO jacketed cord set SP.AS00307-R1J Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 77 All screws for fastening are included. Component availability or design may be subject to change due to unforeseen circumstances. This document is subject to change or new information from ADB SAFEGATE, as and when available or if required, with reservation for error or price changes.
Page 78: Icao Runway Threshold And Wingbar
Prism kit, approach standard, package of 2 1 or2 SP.MG00021-G00-01 Prism kit, approach reinforced, package of 2 1 or 2 SP.MG00021-S00-01 Prism gasket, approach, package of 10 1 or 2 SP.MS00032-000-01 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 79 All screws for fastening are included. Component availability or design may be subject to change due to unforeseen circumstances. This document is subject to change or new information from ADB SAFEGATE, as and when available or if required, with reservation for error or price changes.
Page 81: Interoperability
Self-locking nut kit *Do not use Loctite ADB 12'' Eurobase Metric screw kit 12'' SP.013114/10pc 2701 or 638 12'' or washer with self- M10×22 mm SP.013115/100pc locking nut M10xH=100 UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 83: Power Table
Fixture type – 1 cord set Wattage Load Runway Threshold Wingbar 35 VA 45 W 10 VA 45 VA Values provided are for the "S" option non-monitored power only. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 84 ▪ Primary cables will result in a higher CCR load ▪ Longer secondary cables may result in a larger size isolation transformer requirement ▪ Efficiency of the isolation transformer depends on the manufacturer of the transformer Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 85: Cable Loss
For a primary cable of e.g., 100 m of 6 mm² CU-wire, 100 m × 0.12 W/m = 12 W equals the additional loss to be taken into account. UM-5057, Rev. 1.0.1, 2025/03/21 Copyright ®2025—2025 ADB Safegate, All Rights Reserved...
Page 87: Appendix A: Support
Live Technical Support – Americas If at any time you have a question or concern about your product, contact ADB SAFEGATE's US- based technical support specialists, available 24 hours a day, seven days a week, to assist you via phone.
Page 88: Recycling
A.2.1 Local Authority Recycling The disposal of ADB SAFEGATE products is to be made at an applicable collection point for the recycling of electrical and electronic equipment. The correct disposal of equipment prevents any potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling.

This manual is also suitable for:
