RELIANCE Approach Flash System

Elevated and Inset

User Manual

UM-4006, Rev. 2.4, 2025/01/22

Table of Contents

Troubleshooting

Need help?

Do you have a question about the RELIANCE and is the answer not in the manual?

Questions and answers

Summary of Contents for ADB Safegate RELIANCE

Page 1 RELIANCE Approach Flash System Elevated and Inset User Manual UM-4006, Rev. 2.4, 2025/01/22...
Page 3: Disclaimer / Standard Warranty
Material Handling Precautions and Storage precautions that must be followed. ADB SAFEGATE reserves the right to examine goods upon which a claim is made. Said goods must be presented in the same condition as when the defect therein was discovered. ADB SAFEGATE furthers reserves the right to require the return of such goods to establish any claim.
Page 4 Details and values given in this manual are average values and have been compiled with care. They are not binding, however, and the author disclaims any liability for damages or detriments suffered as a result of reliance on the information given herein or the use of products, processes or equipment to which this manual refers.
Page 5: Table Of Contents
7.2 Optional CAN-Bus interface ....................................40 7.3 Optional serial RS485 interfaces ..................................40 7.4 Optional MODBUS / TCP or PROFIBUS DP interface ..........................40 7.5 External trigger ........................................41 UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 6 13.1 Control unit MCU800D-SFL in the standard housing ..........................67 13.2 Isolating unit PDU800D-SFL .................................... 67 A.0 INTEROPERABILITY ................................69 B.0 SUPPORT ....................................71 B.1 ADB SAFEGATE Website ....................................... 72 B.2 Recycling ............................................ 73 B.2.1 Local Authority Recycling ..................................73 B.2.2 ADB SAFEGATE Recycling ..................................73 Copyright ©...
Page 7 Figure 25: Troubleshooting tree 1: Power supply and control system ....................... 56 Figure 26: Troubleshooting tree 2: Data transmission .............................. 57 Figure 27: SFL System Component Layout ..................................59 UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 9 Table 10: SFL control ..........................................46 Table 11: SFL status ..........................................46 Table 12: Copper cable values for copper conductors at 20°C ..........................60 Table 13: SFL/TIL (IL868D) ........................................69 UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 11: Safety Instructions
1.1 Safety Introduction to Safety This section contains general safety instructions for installing and using ADB SAFEGATE equipment. Some safety instructions may not apply to the equipment in this manual. Task- and equipment-specific warnings are included in other sections of this manual where appropriate.
Page 12: Introduction To Safety
RELIANCE Approach Flash System Safety instructions Qualified Personnel Important Information The term qualified personnel is defined here as individuals who thoroughly understand the equipment and its safe operation, maintenance and repair. Qualified personnel are physically capable of performing the required tasks, familiar with all relevant safety rules and regulations and have been trained to safely install, operate, maintain and repair the equipment.
Page 13: Intended Use
Note To minimize the risk of errors, the ADB SAFEGATE Sales Representative will have information on which gasket goes with which base. This information is also provided in the product Data sheets, the User Manuals and the Spare Part Lists.
Page 14: Operation Safety
RELIANCE Approach Flash System Safety instructions CAUTION Use of incorrect combination of gaskets, bolts and nuts can create severe damages to the product installation and create multiple safety risks. To obtain a safe and watertight installation the O-ring and retaining bolt stated in the document must be used.
Page 15: Material Handling Precautions, Esd
• Allow only qualified personnel to perform maintenance, troubleshooting, and repair tasks. • Only persons who are properly trained and familiar with ADB SAFEGATE equipment are permitted to service this equipment. • An open airfield current circuit is capable of generating >5000 Vac and may appear OFF to a meter.
Page 17: Introduction
2.0 Introduction The RELIANCE Approach Flash System, referred to as SFL, serves as a sequential approach flash lighting system and threshold identification lighting system at airports. It meets all the requirements of ICAO Annex 14 and the requirements for military lighting systems in compliance with STANAG 3316 and the “Manual for Lighting Systems”.
Page 18: System Architecture
Introduction 2.2 System architecture In the RELIANCE Approach Flash System, referred to as the SFL, instead of the traditional gaseous-discharge technology, lights with modern light-emitting diodes (LEDs) are used as the light source. The white high-performance LEDs generate the light flash using an extremely short light pulse with very high peak brightness.
Page 19 Approach Flash System, referred to as SFL, consists of a control unit, main chain (SFL - light 1..30), threshold identification (TIL - light 31..32) and power distribution units (1..32). The RELIANCE SFL system enables following static (installation) or dynamic (configuration settings) system configurations: •...
Page 20 RELIANCE Approach Flash System Introduction Communication interface service computer Communication interface flash lights 2-wire power line Environmental temperature -25 to +45 °C Relative humidity, not condensed 10 to 90% International Protection class IP 43 Altitude over NN (operation) -100 to +2,500 m...
Page 21 Single Inset Cold/W - Phoenix Connector Notes Supply of required electric and installation parts ( joint, T-joint, cabling) is not part of ADB SAFEGATE delivery but responsibility of the installer. For more details refer to manual. Refer to manual. 300 Ohm termination resistor of data lines delivered with MCU.
Page 22 RELIANCE Approach Flash System Introduction Transformer, Connection, and Mounting Ordering Information Ordering Code Part Description P864 PDU800D-SFL SELV Isolating Unit P1006 OLP800D-SFL Optional Overvoltage Protection A5326 OLP Accessory Optional Remote Monitoring for Data Line Overvoltage Protection P1029 JBX800D-SFL T Connection Box - JBX800D 300.241...
Page 24 RELIANCE Approach Flash System Functional description To safeguard data transmission, the two data lines in the cable joint at the end of the cable at Light Position 1 are connected to a terminating resistor. Copyright © ADB Safegate, All Rights Reserved...
Page 25: Operator Control At The Control Unit
If this is the case, instructions will be found in the project documents. Here, descriptions are given for the functions in the standard version. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 26: Internal Service Local Control And Status Displays
RELIANCE Approach Flash System Operator control at the control unit The control panel illustrated here is merely an example. The shape and configuration of the operator controls and displays may differ. Elements Functions The monitor lamp indicates that the control unit is ready for operation.
Page 27: Figure 3: Control Unit
The service mode local control system isolates the flash lighting system from the remote control. Figure 3: Control unit For the service local control mode, see Figure 4, outside the cover of the control module, five buttons and a rotary switch are provided. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 28: Functions Of The Configuration Buttons
RELIANCE Approach Flash System Operator control at the control unit For monitoring the flash lighting system, the control module has nine LED displays under the transparent cover. Figure 4: Service, operator control and display elements at the control module 4.2.1 Functions of the configuration buttons The buttons serve for dynamic modification of the system’s configuration.
Page 29: Led Displays
4.3 Easy-to-use operator control at the control unit To provide an expanded local control capability for the LED flash lighting system, an optional easy-to-use operator control feature can be connected to the control unit. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 31: Installation
5.0 Installation The RELIANCE Approach Flash System, referred to as SFL, is installed as an extended approach centerline in front of the runway. The length is usually 900 m, with an interval of 30 m between the lights. The length and individual spacing may vary, and can be found in the project drawings.
Page 32: Table 1: System Components
RELIANCE Approach Flash System Installation Table 1: System Components Pos. Quantity Designation Type Remark Control unit MCU800D-SFL Supply and monitoring unit of the system 32 (23) Isolating unit PDU800D-SFL Safer isolation of the light incl. overvoltage protection. Overvoltage protection unit...
Page 33: Table 2: Cable Components
Note maximum length of 25 m. X n.2 Connection between master and slave H07RN-F 7G1.5 Superfluous conductors and protective conductors are not inset flashing lights used! Note maximum length of 3 m. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 34: Figure 7: Cable Layout And System Detail - Elevated Lights
RELIANCE Approach Flash System Installation Figure 7: Cable Layout and System Detail – Elevated lights r tective Separat on upply Voltage Leve af ty Extra Low Voltag Level r tective Separat on afety xtra Lo oltage Level upply Voltage Leve R emote max.
Page 35: Figure 8: Cable Layout And System Detail - Inset Lights (Single And Double)
Figure 8: Cable Layout and System Detail – Inset Lights (Single and Double) P o r tective Separation af ty Extra Low Voltage evel upply Voltage Leve P o r tective Separation af ty Extra Low Voltage evel upply Voltage Leve UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 36: Special Connecting Cables For Inset Flashing Lights
RELIANCE Approach Flash System Installation 5.2 Special connecting cables for inset flashing lights Inset flashing lights can also be provided with special cables and special plug connectors, to suit the specific project concerned. The assignments and types involved can be found in the project documentation. Special programming adapters may be required for the special plug connectors.
Page 37: Figure 9: Olp Unit
Figure 9: OLP Unit Figure 10: OLP Unit Surge Protection Devices LINE SURGE PROTECTION DATA LINE SURGE PROTECTION DEVICE WITH INDICATOR DEVICE WITH INDICATOR A3534 A5325 UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 38: Figure 11: Olp Unit With Optional Data Line Monitoring Accessory
RELIANCE Approach Flash System Installation Figure 11: OLP Unit with Optional Data Line Monitoring Accessory DATA LINE REMOTE MONITORING ACCESSORY WITH INDICATOR A5326 The supply cables (2.5 mm² to 10 mm²) are connected to the overvoltage protection unit as follows: Terminal X1.
Page 39: Terminating Resistor
5.6.1 Addressing of elevated flashing lights In the case of an elevated flashing light, the setting for the address is accessible behind a screw union in the rear wall of the housing. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 40: Addressing And Parameterization Of The Inset Light Using The Parameterizing Adapter Psd800D-Sfl
RELIANCE Approach Flash System Installation The Position Number (Address) is set at the two rotary switches as a two-digit decimal number (01, 02, … 32). Addresses above 32 may trigger the special functions described in the text below. Figure 13: Elevated flashing lights, rear, addressing...
Page 41: Figure 14: Connecting The Inset Light To The Parameterizing Adapter
Deenergized Flashing Inset Light of a Pair of Flashing Inset Lights Connected to an Active Power Line Figure 15: Parameterizing adapter for the settings of an inset flashing light UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 42: Figure 16: Connections Of The Parameterizing Adapter For The Inset Light, The Service Computer And Of The Alternative Auxiliary Voltage Supply Via Usb Or Dc Input Receptacle
RELIANCE Approach Flash System Installation Figure 16: Connections of the parameterizing adapter for the inset light, the service computer and of the alternative auxiliary voltage supply via USB or DC input receptacle Figure 17: Adapter cable for the single light and the double lights (via H-connector) After the service computer has been connected, the main menu for monitoring and parameterizing the flashing light will be displayed automatically in the lucDMC service software.
Page 43: Figure 19: Window For Setting The Light's Parameters
For extended monitoring of the light, the internal counters can be displayed in the Internal counters (expert mode) tab. These data in Expert mode do not necessarily correspond to physical variables. They enable the service personnel to perform an extended analysis of the system and device functions. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 44: Figure 20: Menu - Internal Counters (Expert Mode)
RELIANCE Approach Flash System Installation Figure 20: Menu – Internal counters (expert mode) Copyright © ADB Safegate, All Rights Reserved...
Page 45: Color Coding Of The Cables And Contact Assignments Of The Light Connecting Cables
PE must not be used or green-yellow connected 6.3 4-Pole FAA Connector Pin Configuration for Elevated Light Figure 21: 4-Pole FAA Connector Pin Configuration Receptacle Plug Color White Black Brown UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 47: Remote Control
The interface can accordingly be operated using potential-isolated contacts or equivalent digital interfaces without additional external voltage sources. For integration of the flash lighting system into the ADB SAFEGATE remote control system, 2 redundant CAN-Bus interfaces are provided. For serial integration of the SFL into a different remote control system, additional communication modules (GCI) are available as an optional extra, with the following redundant serial interfaces: •...
Page 48: Parallel Interface
RELIANCE Approach Flash System Remote control 7.1 Parallel interface 7.1.1 Inputs of the parallel control interface In the control unit, the inputs and outputs of the communication module are connected to two-tier terminals for linking up the parallel interface. The upper level (a) provides the control voltage for the lower input level. This means the control system can be implemented using potential-isolated contacts or equivalent digital interfaces without an external control voltage source.
Page 49: Signal Outputs Of The Parallel Control Interface
LF2 FAULT STATUS ON: LF2 threshold not reached Out +24 V DC OFF: ALARM; the configured signaling threshold LF2 of the faulty flashing lights in the main chain has been reached. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 50: Optional Can-Bus Interface
7.2 Optional CAN-Bus interface The CAN-Bus is used only for connection to the ADB SAFEGATE remote control system. Consult the project drawings to see whether the interface has been activated and has been wired to the output terminal area of the control unit.
Page 51: External Trigger
The chain is triggered with the end of the entire network half-wave following the trigger pulse. The time-lag in the chain sequence thus lies between 10 and 20 ms. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 53: Service Software Package Lucdmc
Please consult the explanations and help functions integrated into the software package. Note For training courses on how to work with the service software and the RELIANCE Flash Lighting System, please get in touch with ADB SAFEGATE Service. 8.4 Connection For connecting up the service capability, the service computer is connected to the control module’s service plug connector.
Page 54: Footer Status Line
RELIANCE Approach Flash System Service software package lucDMC Table 6: General functions available in the header menu (Continued) Display of the protocols saved and the log files of the lucDMC service software package. General settings of the lucDMC software package.
Page 55: Sfl Operator Control
Indicates that the fault signaling threshold LF2 of the chain has been reached (excluding TILs) ○ TIL A defective threshold identification light TIL, (Pos. 31 or 32) has been detected, and both threshold identification lights have been positively switched off. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 56: Table 8: Sfl Device Settings
RELIANCE Approach Flash System Service software package lucDMC Table 8: SFL device settings Display of the internal light pulse configuration. standard the chain contains lights with the standard brightness or the optional high-performance lights are being operated at the standard brightness in order to extend their useful lifetime.
Page 57: Internal Counter (Expert Mode)
The flashing light is malfunctioning. One of the above-listed errors is ongoing. 8.7.2 Internal counter (expert mode) On this page, the number of detailed signals from the lights is displayed. These data are used by ADB SAFEGATE Service to analyze the system.
Page 58: Internal Status (Expert Mode)
RELIANCE Approach Flash System Service software package lucDMC 8.7.3 Internal status (expert mode) On this page, all control and monitoring messages and internal measured values are displayed. These data are used by ADB SAFEGATE Service for analyzing the system. Any values stated do not necessarily correspond to physical variables, but are internal scaled data intended for analyzing the system’s behavior.
Page 59 These data are used by ADB SAFEGATE Service for analyzing the system. Any values stated do not necessarily correspond to physical variables, but are internal scaled data intended for analyzing the system’s behavior. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved...
Page 60: Sfl Settings
RELIANCE Approach Flash System Service software package lucDMC 8.8 SFL settings 8.8.1 General settings In the general system settings, the basic configuration and any operating modes of the systems are specified. Copyright © ADB Safegate, All Rights Reserved...
Page 61 LEDs and the power section of the light. Thanks to the lower thermal loading, this operating mode is also recommended for use in zones with high ambient temperatures. High: The maximum possible nominal brightness of the high-performance flashing lights is configured UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 62: Factory Settings And System Restart
Settings – serial interface on the communication module (GCI) The additional maintenance interface on the communication module is set up here. The interface is intended only for use by the ADB SAFEGATE service personnel. The settings should not be altered. Setting – failure signal It is here that the second signaling threshold (LF2) is specified for the chain's light failure threshold without TILs.
Page 63: Maintenance
If a light has been replaced or detached from its mounting, the same alignment of the light must be restored. The new light must be coded with the address of the light replaced. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 65: Troubleshooting
Please note that high-voltage tests must never be carried out on the supply cable with PDU800-SFL isolating units and overvoltage protection unit OLP800D-SFL connected. A high-voltage measuring procedure will trigger the overvoltage protection elements, and may destroy the arresters and any filters installed. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 66: Figure 25: Troubleshooting Tree 1: Power Supply And Control System
RELIANCE Approach Flash System Troubleshooting For fast detection and elimination of malfunctions, you can proceed in accordance with the trouble-shooting tree, see Figure 25 Figure 26. The optional lucDMC service software enables you, in addition, to view and analyze the detailed information.
Page 67: Figure 26: Troubleshooting Tree 2: Data Transmission
Check if data line termination Check isolating unit is defective! of effected flash light and replace if Check if supply cable or neccessary! sockets are short-circuits! Fault eliminated Call service! UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 69: System Planning
J 0.x J 0.x J 0.x J 0.x J 0.x X-n.1 Protection Unit 400 V 50/60Hz P n.2 Remote Control X 0.2 X 0.1 Local Control J n.2 J 0.x UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 70: Table 12: Copper Cable Values For Copper Conductors At 20°C
RELIANCE Approach Flash System System planning Table 12: Copper cable values for copper conductors at 20°C Cable cross-sectional area Cable length 2.5 mm² 4.0 mm² 6.0 mm² 10.0 mm² 16.0 mm² 100 m 0.7 Ω 0.4 Ω 0.3 Ω 0.2 Ω...
Page 71: Overvoltage Protection For The Supply Cable
For mast installation without a frangible coupling, an elevated light is available with a 5-pole, severable cable connector. This enables a longer connecting cable to the isolating unit to be created simply on site. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 72: Protective Measures
RELIANCE Approach Flash System System planning Inset lights are always supplied with a cast 5-pole plug connector with dimensions in accordance with FAA AC 150/5345-26 PLUG-CLASS A, TYPE II, STYLE I. The mating piece with a 5-pole receptacle with dimensions in accordance with FAA AC 150/5345-26 RECEPTACLE-CLASS A, TYPE II, STYLE 7 and a 2 m connecting cable is supplied with every inset light.
Page 73 For selective fuse protection of the flash lighting system in the low-voltage distribution panel, the fusing characteristic K of the internal fuse must be taken into due account. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 75: System Data And Functions In Overview
In order to avoid a time-delay at power-up and for continuous monitoring the system offers a readiness mode. Monitoring: • Individual-light monitoring. • Continuous monitoring in readiness mode. • Monitoring of the threshold lights with automatic switch-off in the event of an individual fault. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 76 • 24 VDC control inputs (8) and signal outputs (12) for parallel control • optionally redundant CAN-Bus interface for linking up to a ADB SAFEGATE remote control system • optionally redundant RS485 interfaces with MODBUS/RTU, RCOM or RCOM plus protocol •...
Page 77: Technical Data
142 mm x 192 mm (D x L) without cables Weight: ~ 6.5 kg Standards: Aerodrome Design Manual Part 4; Visual Aids; Fourth Edition – 2004 DIN VDE V 0161-11 (VDE V 0161-11) UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 79: Appendix A: Interoperability
M10×25 mm M10 H100 L-868 with flange O-ring D259.3×5.7 1411.20.452, Reference EB83 SP.013114/10 pc UNC Screw kit SP.013115/100 pc Notes Do not use Loctite or washer with self-locking nut. UM-4006, Rev. 2.4, 2025/01/22 Copyright ADB Safegate, All Rights Reserved ©...
Page 81: Appendix B: Support
Our experienced engineers are available for support and service at all times, 24 hour/7 days a week. They are part of a dynamic organization making sure the entire ADB SAFEGATE is committed to minimal disturbance for airport operations. ADB SAFEGATE Support Technical Support –...
Page 82: Adb Safegate Website
RELIANCE Approach Flash System SUPPORT B.1 ADB SAFEGATE Website The ADB SAFEGATE website, www.adbsafegate.com, offers information regarding our airport solutions, products, company, news, links, downloads, references, contacts and more. Copyright © ADB Safegate, All Rights Reserved...
Page 83: Recycling
B.2.1 Local Authority Recycling The disposal of ADB SAFEGATE products is to be made at an applicable collection point for the recycling of electrical and electronic equipment. The correct disposal of equipment prevents any potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling.
Page 85 Email: marketing@adbsafegate.com Fax: +46 (0)40 699 17 30 Internet: www.adbsafegate.com ADB SAFEGATE, China ADB SAFEGATE Airfield Technologies Ltd. China Unit 603, D Block, CAMIC International Convention Center, No 3, Hua Jia Di East road, ChaoYang district, Beijing 100102 P.R. China Contact: Tel.: +86 (10) 8476 0106...
