User Manual
TPC-B520L
Computing Box Module with
Intel® Core™ i3 Processor N-series
製造商: 研華股份有限公司
地址:
台北市內湖區瑞光路26巷20弄1 F
電話:
02-27927818

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPC-B520L Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech TPC-B520L Series

Summary of Contents for Advantech TPC-B520L Series

  • Page 1 User Manual TPC-B520L Computing Box Module with Intel® Core™ i3 Processor N-series 製造商: 研華股份有限公司 地址: 台北市內湖區瑞光路26巷20弄1 F 電話: 02-27927818...
  • Page 2 The documentation and the software included with this product are copyrighted 2023 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.

  • Page 3: Product Warranty (2 Years)

    Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.

  • Page 4: Technical Support And Assistance

    此為甲類資訊技術設備，於居住環境中使用時，可能會造成射頻干擾，在此種情況 下，使用者會被要求採取某些適當的對策。 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 5: Safety Instructions

    Safety Instructions Read these safety instructions carefully. Lisez attentivement ces consignes de sécurité. Keep this User Manual for later reference. Conservez ce manuel d'utilisation pour référence ultérieure. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning.
  • Page 6 AVIS DE NON-RESPONSABILITÉ : Ces instructions sont fournies conformément à la norme CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude des déclarations contenues dans le présent document. 19. This product is not intended for use by children (this product is not a toy).
  • Page 7 earthing connection. Le cordon d'alimentation de l'équipement doit être connecté à une prise de courant avec connexion à la terre. TPC-B520L User Manual...
  • Page 8 安全指示 23. 請仔細閱讀此安全操作說明。 24. 請妥善保存此用戶手冊供日後參考。 25. 用濕抹布清洗設備前，請從插座拔下電源線。請不要使用液體或去汙噴霧劑清洗設 備。 26. 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。 27. 請不要在潮濕環境中使用設備。 28. 請在安裝前確保設備放置在可靠的平面上，意外跌落可能會導致設備損壞。 29. 設備外殼的開口是用於空氣對流，從而防止設備過熱。請不要覆蓋這些開口。 30. 當您連接設備到電源插座上前，請確認電源插座的電壓是否符合要求。 31. 請將電源線佈置在人們不易絆到的位置，並不要在電源線上覆蓋任何雜物。 32. 請注意設備上的所有警告和注意標示。 33. 如果長時間不使用設備，請將其同電源插座斷開，避免設備被超標的電壓波動損壞。 34. 請不要讓任何液體流入通風口，以免引起火災或者短路。 35. 請不要自行打開設備。為了確保您的安全，請由經過認證的工程師來打開設備。 36. 如遇下列情況，請由專業人員來維修： ◼ 電源線或者插頭損壞； ◼ 設備內部有液體流入； ◼ 設備曾暴露在過於潮濕的環境中使用； ◼ 設備無法正常工作，或您無法通過用戶手冊來使其正常工作； ◼ 設備跌落或者損壞； ◼...

  • Page 9: Table Of Contents

    Content Chapter 1 General Information ......1 Introduction ....................2 Specifications ..................2 1.2.1 General ..................2 1.2.2 System Hardware ..............2 1.2.3 Certification and Environment ..........3 1.2.4 Power ..................3 External I/O ....................4 LCD & Touch Specification ..............5 Table 1.1: Specifications ............
  • Page 10 Expansion Module Installation ............... 21 2.5.1 Expansion Cover Removal ............ 21 2.5.2 Installation of 2.5" SATA SSD ..........22 2.5.3 Installation of Speaker Module ..........23 2.5.4 Installation of iDoor Module ........... 24 2.5.5 Installation of Remote Button ..........25 Chapter 3 BIOS Setup ........
  • Page 11 Table A.9: RTC Battery Connector (BAT1) ......52 A.3.6 Internal RS-232/422/485 Connector (COM2) ......52 Table A.10: Internal COM Port Connector (COM2) ....52 A.3.7 COM1 RS-232/422/485 Connector (COM1) ......53 Table A.11: COM1 RS-232/422/485 Connector (COM1) ..53 A.3.8 Speaker Connector (SPK1) ...........

  • Page 13: General Information

    Chapter General Information TPC-B520L User Manual...

  • Page 14: Introduction

    Introduction The TPC-B520L series is a computing box module equipped with 13th Generation Intel Core processor. ◼ Powered by Alder Lake-N Core™ i3-N305 octo-core processor Single DDR5 memory slot supports up to 16GB ◼ Support expansion via three M.2 slots (NVMe, Wi-Fi, 5G) ◼...

  • Page 15: Certification And Environment

    2 x USB 3.2 Gen 1 4 x USB 2.0 2 x RS-232/422/485 (Optional) 2 x 4Ω speaker for audio out 1.2.3 Certification and Environment Certification ◼ BSMI ◼ ◼ ◼ FCC Class A ◼ CB/UL IP66-rated front panel ◼ Environment ◼...

  • Page 16: External I/O

    External I/O The arrangement of I/O ports is shown below. A. Default sku for iDoor installation F. 2.5GbE LAN ports (optional 2.5" SSD / 2 x speakers) G. 2 x USB 3.2 B. iDoor slot H. 2 x USB 2.0 C.

  • Page 17: Lcd & Touch Specification

    LCD & Touch Specification Table 1.1: Specifications Part Number for FPM-D12T- FPM-D15T- FPM-D17T- FPM-D19T- Cost Effective Version Display Size 12" 15" 17" 19" XGA TFT LED XGA TFT LED SXGA TFT SXGA TFT Display Type LED LCD LED LCD Aspect Ratio Max.
  • Page 18 Table 1.2: Specifications Part Number for FPM-D15W- FPM-D18W- FPM-D21W- FPM-D24W- Cost Effective Version Display Size 15.6" 18" 21.5" 23.8" FHD TFT LED FHD TFT LED FHD TFT LED FHD TFT LED Display Type Aspect Ratio 16:9 Max. Resolution 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080...
  • Page 19 Table 1.3: Specifications Part Number for FPM-D12T- FPM-D15T- FPM-D15W- FPM-D21W- Cost Effective Version Display Size 12" 15.6" 15.6" 21.5" XGA TFT LED FHD TFT LED FHD TFT LED FHD TFT LED Display Type Aspect Ratio 16:9 Max. Resolution 1024 x 768 1024 x 768 1920 x 1080 1920 x 1080...

  • Page 20: Dimensions

    Dimensions TPC-B520L Computing Box ◼ Dimensions (W x H x D): 269 x 202.9 x 50 mm (10.59 x 7.99 x 1.96 inch) TPC-B520L User Manual...
  • Page 21 FPM Display Module TPC-B520L User Manual...

  • Page 22: Led Indicators On Optional Fpm-Display

    LED Indicators on Optional FPM-Display Indicator Default Status (ErP Enable) Status 2 (ErP Disable) Green Normal Powered-On State Normal Powered-On State Orange Sleep (S3) / Hibernate (S4) Sleep (S3) / Hibernate (S4) / Shutdown(S5) No Light Shutdown(S5)/Power Off Power Off TPC-B520L User Manual...

  • Page 23: System Setup

    Chapter System Setup TPC-B520L User Manual...

  • Page 24: Transport And Unpacking

    Transport and Unpacking 2.1.1 Transport When accepting a delivery, please check the packaging for visible transport dam- age and check the delivery for completeness by comparing it with your order. If you notice any shipping damage or inconsistencies between the contents and your order, please inform the responsible delivery service immediately.
  • Page 25 Figure 2.2 Memory Module Installation Install the M.2 SSD: Unscrew and remove the M.2 SSD slot cover. Insert the M.2 SSD into the slot. Secure it in place using the M3x4L screw. If your M.2 SSD comes with a heatsink, please remove it be- Warning! fore installation.
  • Page 26 Figure 2.4 M.2 SSD Installation Attach the TPC computing box module to the FPM display module via the board-to-board connector. Use the five screws of 1930000881 to secure the computing box with the display module. Figure 2.5 Attaching the TPC to the FPM Display Connect the power connector to the 24 VDC power lines of a power adapter or in-house power source.

  • Page 27: Driver Installation

    With administrator-level privileges, run the installer for the Advantech watchdog driver. Below is an example of the Advantech watchdog driver setup. To stop the setup process at any time, click the “Cancel” button on the pop-up screen. The setup program will stop the procedure automatically.
  • Page 28 Wait until the Advantech Watchdog Driver Setup Wizard has completed the instal- lation. Click the Install button to continue the installation of the Advantech watchdog driver software. TPC-B520L User Manual...

  • Page 29: Cabinet Installation And Earth Grounding Setup

    Click the Restart or Close button on the Advantech Watchdog Driver Setup Wiz- ard pop-up screen to complete the setup. Cabinet Installation and Earth Grounding Setup Follow these steps to set up the TPC-B520L system, ensuring that the Ground pin of the TPC-B520L system is properly connected to the earth ground. This...

  • Page 30: System Wiring

    2.3.2 System Wiring Ground the cabinet to earth. Ensure proper grounding for all cabinets. Connect the power supply ground to the cabinet. Connect the TPC-B520L system's ground pin to the cabinet. If necessary, connect I/O to the controller. Connect the power supply's V+ and V- to the TPC-B520L system. Proceed step by step through steps 1 to 6, then power on the TPC-B520L system.

  • Page 31: Panel Mounting

    The TPC is an industrial grade product, designed to prevent external interference and the possibility of electric shock. To complete the isolation design, we need to consider the following: The Ethernet is isolated, a LAN connection will not impact the isolation de- sign.
  • Page 32 Figure 2.10 Panel Mounting (1) Retrieve the clamps and long screws from the accessory pack. Hook the clamp into the holes around the four sides of the bezel. Figure 2.11 Panel Mounting (2) Fasten the screws with a torque of 2 kgf-cm. These screws will push the mounting panel, ensuring a secure and stable unit.0.

  • Page 33: Expansion Module Installation

    Expansion Module Installation 2.5.1 Expansion Cover Removal To install SATA SSD or expansion modules, the expansion cover of the system must be removed. It is attached with 4 screws, as illustrated below. After removing all screws, carefully lift the rear bracket and set it aside, taking care not to cause any damage to the system or the cover in the process.

  • Page 34: Installation Of 2.5" Sata Ssd

    2.5.2 Installation of 2.5" SATA SSD Secure the SSD onto the bracket using four M3x4L screws. Remove the expansion cover and flip it over. Install the SSD and its bracket onto the expansion cover removed in the previous step. Attach the cover to the chassis using the previously removed screw. NOTE! A SATA expansion kit (98R1B520000) is required for 2.5"...

  • Page 35: Installation Of Speaker Module

    2.5.3 Installation of Speaker Module Remove the expansion cover. Retrieve the cover plate from the speaker kit. Install the speakers onto the cover. NOTE! A speaker expansion kit (98R1B520001) is required for speaker installation. Attach the cover to the chassis using the previously removed screw. TPC-B520L User Manual...

  • Page 36: Installation Of Idoor Module

    2.5.4 Installation of iDoor Module Remove the expansion cover. Remove the blank slot cover for iDoor. Insert an iDoor module. Tighten the two screws to secure the module in place. Install the iDoor M.2 module and plug in the cable to the connector on the iDoor M.2 module.

  • Page 37: Installation Of Remote Button

    2.5.5 Installation of Remote Button Locate the remote button connector on the rear panel. Take the remote button kit and insert it into the connector. Use a screwdriver to tighten the two side screws on the remote button kit. NOTE! A remote button kit (98R1B520002) is required for remote button in- stallation.

  • Page 38: Chapter 3 Bios Setup

    Chapter BIOS Setup TPC-B520L User Manual...

  • Page 39: Bios Setup

    BIOS supports your CPU. If there is no num- ber assigned to the patch code, contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that the CPU status is valid.

  • Page 40: Main Setup

    3.2.1 Main Setup Upon entering the BIOS Setup Utility, users will be on the Main setup screen. At any point during the configuration, users can return to the Main setup screen by selecting the Main tab. There are two Main setup options, which are described in this section.

  • Page 41: Advanced Bios Features Setup

    3.2.2 Advanced BIOS Features Setup Select the Advanced tab from theTPC-B520L setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as ACPI Settings and hit <enter> to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 42 3.2.2.1 CPU Configuration ◼ Intel (VMX) Virtualization Technology When this item is disabled, Virtual Machine Extensions function will be no longer supported. ◼ Active Efficient-cores This item allows users to configure Efficient-cores quantity。 TPC-B520L User Manual...

  • Page 43: Power & Performance

    3.2.2.2 Power & Performance TPC-B520L User Manual...
  • Page 44 3.2.2.3 PCH-FW Configuration ◼ Firmware Update Configuration This item allows users to configure the management engine technology pa- rameters. TPC-B520L User Manual...

  • Page 45: Acpi Settings

    3.2.2.4 ACPI Settings ◼ Enable ACPI Auto Configuration This item allows users to enable or disable “ACPI Auto Configuration”. ◼ Enable Hibernation This item allows users to enable or disable System ability to hibernate (OS/S4 sleep state). This option may be not effective with some OS. ◼...
  • Page 46 3.2.2.5 NCT6126D Super I/O Configuration ◼ Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). ◼ Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). 3.2.2.6 Hardware Monitor Configuration TPC-B520L User Manual...

  • Page 47: Trusted Computing

    3.2.2.7 Trusted Computing ◼ TPM Device Selection This item allows users to select TPM device: fTPM or dTPM. fTPM: Enables fTPM. dTPM: Disables fTPM and enable dTPM. Warning! fTPM/dTPM will be disabled and all data saved on it will be lost. Avertissement! fTPM/dTPM sera désactivé...
  • Page 48 ◼ Physical Presence Spec Version This item allows users to enable support for PPI spec version 1.2 or 1.3. Note: Some HCK tests may not support version 1.3. ◼ Device Select TPM 1.2: select this to restrict support to TPM 1.2 devices. TPM 2.0: select this to restrict support to TPM 2.0 devices Auto: select this to support both;...

  • Page 49: Usb Configuration

    3.2.2.9 USB Configuration ◼ Legacy USB Support Enables Legacy USB support. The AUTO option disables legacy support if no USB devices are connected. The DISABLE option will keep USB devices available only for EFI applications. ◼ XHCI Hand-off This is a workaround of 0 Secs without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.
  • Page 50 3.2.2.10 Network Stack Configuration ◼ Network Stack This item allows users to enable or disable the UEFI network stack. TPC-B520L User Manual...

  • Page 51: Nvme Configuration

    3.2.2.11 NVMe Configuration TPC-B520L User Manual...

  • Page 52: Chipset Configuration

    3.2.3 Chipset Configuration 3.2.3.1 System Agent (SA) Configuration ◼ Memory Configuration This submenu allows users to view the memory parameters. ◼ DMI/OPI Configuration This submenu allows users to set DMI/OPI configuration parameters ◼ VT-d This item allows users to enable or disable VT-d capability TPC-B520L User Manual...
  • Page 53 3.2.3.2 PCH-IO Configuration ◼ PCI Express Configuration This submenu allows users to set the PCI Express settings. ◼ SATA Configuration This submenu allows users to set the SATA device settings. ◼ Security Configuration This submenu allows users to set the security configuration settings. ◼...

  • Page 54: Security

    3.2.4 Security Administrator Password ◼ Set Administrator Password ◼ Secure Boot This item allows users to access a submenu to configure secure boot set- tings. TPC-B520L User Manual...

  • Page 55: Boot

    3.2.5 Boot ◼ Setup Prompt Timeout This item allows users to set the number of seconds to wait for setup activa- tion key. 65535 (oxFFFF) means indefinite waiting. Bootup NumLock State ◼ This item allows users to select the keyboard NumLock state. ◼...

  • Page 56: Save & Exit

    3.2.6 Save & Exit ◼ Save Charges and Exit This item allows you to exit system setup after saving the changes. ◼ Discard Changes and Exit This item allows you to exit system setup without saving any changes. ◼ Save Changes and Reset This item allows you to reset the system after saving the changes.

  • Page 57: Appendix A Connectors

    Appendix Connectors TPC-B520L User Manual...

  • Page 58: Jumper And Connector Location

    Jumper and Connector Location A.1.1 Board Layout Figure A.1 Board Layout - Top View Figure A.2 Board Layout - Bottom View Table A.1: Board Placement Place Function JCMOS1 Clear CMOS jumper PSON1 AT/ATX jumper JP22,JP38 5G module jumper DCIN1 Power input connector TPC-B520L User Manual...

  • Page 59: Jumper Settings And Descriptions

    DCOUT1 iDoor power connector USB2C1 USB 2.0 connector USB3C1 USB 3.0 connector LAN12 LAN RJ45 connectors Type-C connector TYPEC1 DisplayPort connector COM1 RS-232/422/485 connector COM1 Internal COM2 RS-232/422/485 connector COM2 Internal USB connector USB2H1 Remote button connector REMOTE1 Remote button connector REMOTE2 RTC battery connector BAT1...

  • Page 60: At/Atx Select (Pson1)

    A.2.1 AT/ATX Select (PSON1) Table A.3: AT/ATX Select Description This jumper is used to select power on mode Default (1-2) (1-2) AT (Default) (2-3) (1-2) AT power (2-3) ATX power A.2.2 5G Module Mode Select (JP22,JP38) Table A.4: 5G Module Mode Select Description This switch is used to select 5G module mode Default...

  • Page 61: Connector Pin Definition

    Connector Pin Definition A.3.1 Remote Button Connector (REMOTE1) Table A.5:Remote Button Connector (REMOTE1) Signal ATX_PWRBTN# A.3.2 Remote Button Connector (REMOTE2) Table A.6: Remote Button Connector (REMOTE2) Signal ATX_PWRBTN# TPC-B520L User Manual...

  • Page 62: Internal Usb Connector (Usb2H1)

    A.3.3 Internal USB Connector (USB2H1) Table A.6: Internal USB Connector (USB2H1) Signal TPC-B520L User Manual...

  • Page 63: Sata Power Connector (Satapwr1)

    A.3.4 SATA Power Connector (SATAPWR1) Table A.7: SATA Power Connector (SATAPWR1) Signal +V12 A.3.5 iDoor Power Connector (DCOUT1) Table A.8: iDoor Power Connector (DCOUT1) Signal DCIN DCIN TPC-B520L User Manual...

  • Page 64: Rtc Battery Connector (Bat1)

    A.3.6 RTC Battery Connector (BAT1) Table A.9: RTC Battery Connector (BAT1) Signal +VBAT A.3.7 Internal RS-232/422/485 Connector (COM2) Table A.10: Internal COM Port Connector (COM2) Signal DCD# DTR# RTS# CTS# TPC-B520L User Manual...

  • Page 65: Com1 Rs-232/422/485 Connector (Com1)

    A.3.8 COM1 RS-232/422/485 Connector (COM1) Table A.11: COM1 RS-232/422/485 Connector (COM1) RS232 RS422 RS485 Data- Data+ A.3.9 Speaker Connector (SPK1) Table A.12: Speaker Connector (SPK1) Signal TPC-B520L User Manual...

  • Page 66: Power Input Connector (Dcin1)

    A.3.10 Power Input Connector (DCIN1) Table A.13: Power Input Connector (DCIN1) Signal Power In V+ Power In V- (GND) GND_EARTH A.3.11 M.2 M-Key Connector (M2M1) Table A.14: M.2 M-Key Connector (M2M1) Signal Signal 3.3V 3.3V 3.3V SUSCLK PEDET(NC-PCIe/GND-SATA) PEWAKE0# REFCLKp CLKREQ0# REFCLKn PERST0#...

  • Page 67: M.2 E-Key Connector (M2E1)

    PETn2 3.3V PERp2 3.3V PERn2 3.3V 3.3V PETp3 PETn3 PERp3 3.3V PERn3 3.3V A.3.12 M.2 E-Key Connector (M2E1) Table A.15: M.2 E-Key Connector (M2E1) Signal Signal 3.3V 3.3V W_DISABLE1# W_DISABLE2# PEWAKE0# PERST0# CLKREQ0# SUSCLK REFCLKn REFCLKp PERn0 TPC-B520L User Manual...

  • Page 68: M.2 B-Key Connector (M2B1)

    PERp0 PETn0 PETp0 3.3V USB_D- 3.3V USB_D+ A.3.13 M.2 B-Key Connector (M2B1) Table A.16: M.2 B-Key Connector (M2B1) Signal Signal 3.3V CONFIG_2 3.3V 3.3V CONFIG_1 RESET# PEWAKE0# REFCLKp TPC-B520L User Manual...

  • Page 69: M.2 B-Key Connector (M2B2)

    CLKREQ0# REFCLKn PERST0# PETp0 PETn0 PERp0 PERn0 UIM_PWR USB3.1-Tx+ UIM_DATA USB3.1-Tx- UIM_CLK UIM_RESET USB3.1-Rx+ USB3.1-Rx- CONFIG_0 3.3V W_DISABLE1# USB_D- USB_D+ FULL_CARD_POW-ER_OFF# 3.3V 3.3V CONFIG_3 A.3.14 M.2 B-Key Connector (M2B2) Table A.17: M.2 B-Key Connector (M2B2) Signal Signal 3.3V 3.3V 3.3V RESET# TPC-B520L User Manual...
  • Page 70 PEWAKE0# REFCLKp CLKREQ0# REFCLKn PERST0# PETp0 PETn0 PERp0 PERn0 PETp1 PETn1 PERp1 PERn1 3.3V USB_D- FULL_CARD_POW-ER_OFF# USB_D+ 3.3V 3.3V TPC-B520L User Manual...

  • Page 71: Appendix B Driver Installation

    Appendix Driver Installation TPC-B520L User Manual...

  • Page 72: Intel Chipset Device Software Installation

    Intel Chipset Device Software Installation Follow the steps below to install the Intel Chipset Device Software: Launch <Driver Root Path>\1.Chipset-10.1.19502.8391-Public-MUP Install SetupChipset.exe Click Next. TPC-B520L User Manual...
  • Page 73 Click Accept. Click Install. Click Restart Now. TPC-B520L User Manual...

  • Page 74: Intel Management Engine Components Installation

    Intel Management Engine Components Installa- tion Follow the steps below to install the Intel Management Engine Components: Launch <Driver Root Path>\2.ME Driver_Win10(64bit)\ME Driver_Win10(64bit)\Intel_CSME_SW_2336.5.29.0_Consumer\Install- ers\Main_DCH Install SetupMe.exe Click Next. TPC-B520L User Manual...
  • Page 75 Check “I accept the terms in the License Agreement”. Click Next. Click Next. Click Finish. TPC-B520L User Manual...

  • Page 76: Intel Graphics Driver Installation

    Intel Graphics Driver Installation Follow the steps below to install the Intel Graphics Driver: Launch <Driver Root Path>\ 3.Intel Graphics Driver Production Version 101.5333 Install Installer.exe Click Begin Installation. TPC-B520L User Manual...
  • Page 77 Click I agree. Click Start. Click Finish. TPC-B520L User Manual...

  • Page 78: Intel Serial Io Driver Installation

    Intel Serial IO Driver Installation Follow the steps below to install the Intel Serial IO driver: Launch <Driver Root Path>\ 4.SerialIO_30.100.2229.4_v2_PV_ADP-N_22H2\Se- rialIO_30.100.2229.4_v2_PV_ADP-N_22H22 Install SetupSerialIO.exe Click Next. TPC-B520L User Manual...
  • Page 79 Check “I accept the terms in the License Agreement”. Click Next. Click Next. Click Next. TPC-B520L User Manual...

  • Page 80: Intel Lan Driver Installation

    Click Finish. Intel LAN Driver Installation Follow the steps below to install the Intel LAN driver: Launch <Driver Root Path>\ 5. 638910-I225-I226-NDIS-Win-x64-1.1.4.42 Select and right click e2f.inf. Click Install from the menu. After installation, the following screen appears. Click OK. TPC-B520L User Manual...

  • Page 81: Intel Gna Driver Installation

    Intel GNA Driver Installation Follow the steps below to install the Intel GNA driver: Launch <Driver Root Path>\ 6. gna-03.00.00.1457-Win11-adl-pv-10-20H2-11- 21H2-11-22H2-20220622 Select and right click gna.inf. Click Install from the menu. After installation, the following screen appears. Click OK. TPC-B520L User Manual...
  • Page 82 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024 TPC-B520L User Manual...

This manual is also suitable for:
