  • Page 1 User Manual TREK-550 Computing Box...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 Visit the Advantech web site at www.advantech.com/support for the latest information about the product. Contact the distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
  • Page 4 Document Feedback T o assist us in making improvements to this manual, we would welcome comments and constructive criticism. Send all such in writing to: support@advantech.com Packing List Before setting up, check that the items listed below are included, in good condition. If any item does not accord with the table, please contact your dealer immediately.
  • Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 6 Anweisung des Herstellers. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 T eil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Bedienungsanleitungen wurden entsprechend IEC- 704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. TREK-550 User Manual...
  • Page 7 Maintenance: to properly maintain and clean the surfaces, use only approved products or clean with a dry applicator. CompactFlash: Turn off the power before inserting or removing CompactFlash storage cards. ropean Contact information: Advantech Europe GmbH Kolberger Straße 7 D-40599 Düsseldorf, Germany T el: 49-211-97477350 Fax: 49-211-97477300...
  • Page 8 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 9: Table Of Contents

    Contents Contents ix Chapter General Information ......1 Introduction ....................2 General Specifications ................2 1.2.1 General ..................2 1.2.2 Standard PC Functions..............3 1.2.3 PCI Bus Ethernet Interface ............3 1.2.4 Touchscreen ................. 3 1.2.5 Environment.................. 4 LCD Specifications..................4 Table 1.1: LCD Specifications .............
  • Page 10 Chapter Jumper Settings and Connectors ... 19 Setting Jumpers and Switches..............20 4.1.1 Locating Jumpers and Switches ..........20 Table 4.1: Jumpers & LEDS on the Motherboard ..... 20 4.1.2 Locating Jumpers and LEDs on the Motherboard ...... 21 Figure 4.1 Locating Jumpers / LEDs .........

  • Page 11: General Information

    Chapter General Information This chapter gives background information on the TREK-550 Computing Box. Sections include: ! Introduction ! General Specifications ! Dimensions...

  • Page 12: Introduction

    Introduction The TREK-550 is a dedicated box computer for industrial, transport trucks, buses and taxis. TREK-550 combined with variety of I/O connectors can be connected to devices like OBD-II or TPMS (Tire Pressure Monitoring System). Dual display/dual audio interfaces supporting different resolutions can deliver different applications to different displays;...

  • Page 13: General Specifications

    General Specifications Key features Supports Win CE 6.0, XPE, XP and Linux Automotive grade working temperature range (-30° C to 70° C) Rich I/O including CAN, LAN, RS-232, RS-485, J1708, isolation 4DI/4DO, Line out, Mic in, USB, and Video-in Built-in communication modules, including GSM/GPRS/HSDPA/CDMA, WLAN GPS with AGPS and dead reckoning technology (Gyro &...

  • Page 14: Standard Pc Functions

    1.2.2 Standard PC Functions CPU: Intel Atom Z510PT 1.1Ghz/ Z520PT 1.3Ghz Chipset: Integrated in LE82US15EE BIOS: Award 256 KB Flash BIOS, ACPI 2.0 Compliant. System chipset:. System memory: One 200-pin SODIMM sockets, accepts up to 2 GB DDR667 Solid state disk: Supports one 50-pin socket for Compact-Flash type I/II (True PATA mode).

  • Page 15: Environment

    1.2.5 Environment High/low temperature: -30 ~ 70° C Relative humidity: 10 ~ 95% @ 40° C (non-condensing) Shock: 30 G peak acceleration (11 msec duration) Certifications: CE, FCC, CCC, Emark, CB. Vibration: 5 ~ 500 Hz SAE J1455 4.9.4.2, MIL-STD-810F 514.5 Dimensions Figure 1.1 TREK-550 dimensions TREK-550 User Manual...

  • Page 16: System Setup

    Chapter Syst System Setup This chapter details system setup on TREK-550. Sections include: ! A Quick Tour of the computer box ! Installation Procedures ! Running the BIOS Setup Program...
  • Page 17 A Quick Tour of the TREK-550 Computing box. Before starting to set up the Computing Box, take a moment to become familiar with the locations and purposes of the controls, drives, connectors and ports, which are illustrated in the figures below.

  • Page 18: Installation Procedures

    Unit: mm Figure 2.4. Bottom view of TREK-550 Unit: mm Figure 2.5. Top view of TREK-550 Installation Procedures 2.2.1 Connecting the Power Cord Connect the three pin waterproof power cord to the DC inlet of the Computing Box. On the open-wire end, one pin is reserved for positive voltage and is marked, "+";...
  • Page 19 Chassis Ground Ground Ground (Reserved) (Reserved) (Reserved) Power Input (6~36 VDC) Power Input (6~36 VDC) Acc Ignition Input Ground (Reserved) Power Button Input Mating power cable Advantech p/n : 1700018306 A Cable 2*6P-3.0/fuse 180cm TREK Manufacturer p/n: Best Technology Enterprise 900-1200-180R...

  • Page 21: Running The Bios Setup Program

    Running the BIOS Setup Program In most cases, the computer will have been properly set up and configured by the dealer or SI prior to delivery. However, it may still be necessary to adjust some of the computer's BIOS (Basic Input-Output System) setup programs to change the system configuration data, like the current date and time, or the specific type of hard drive currently installed.

  • Page 22: Installing The Drivers

    Chapter 5 to 10 of this manual. Note! The drivers and utilities used for the TREK-550 are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities.

  • Page 23: Chapter 4 Jumper Settings And Connectors

    Chapter Jumper Settings and Connectors This chapter explains how to set up the Computing Box hardware, including instructions on setting jumpers and connect- ing peripherals, and how to set switches and read indicators. Be sure to read all the safety pre- cautions before beginning the installation procedure.

  • Page 24: Setting Jumpers And Switches

    Setting Jumpers and Switches It is possible to configure the Computing Box to match the needs of the application by resetting the jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip, often protected by a plastic cover that slides over the pins to connect them.
  • Page 25 4.1.1 Locations of the Jumpers and Connector Figure 4.1 Locations of jumpers and connectors on top side the motherboard. SODIMM1 CN16 Figure 4.2 Locations of jumpers and connectors on bottom side of the motherboard. TREK-550 User Manual...
  • Page 26 The figures below show the locations of the jumpers and connectors on daughter board used in TREK-550. CN11 CN12 CN13 CN14 CN15 Figure 4.4 Locations of jumpers and connectors on bottom side of the daughter board. 4.1.2 Jumpers Table 4.1: Jumpers on motherboard Location Function input voltage selection...
  • Page 27 4.1.3 Connectors On-board connectors link the Computing Box to external devices such as hard disk drives. The table below lists the function of each connector. Table 4.1: Connectors on motherboard Location Function RESET USB connector CF connector CN10 LAN connector CN11 USB connector CN12...

  • Page 28: Jumper Settings

    Jumper Settings 4.3.1 CMOS Clear for External RTC (JP2) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Set the jumper back to “Normal Operation” before turning on the power supply! Table 4.3: Clear CMOS / External RTC (JP1) Normal Operation (Default) Clear CMOS 4.3.2...
  • Page 29 4.3.5 DI/GPS Function Selection (SW2) If the GPS module with Dead Reckoning function is used, the digital inputs 3/4 will be used as inputs of GPS module. DIP switch (SW2) is used to select the function on DI 3/4 (Digital Input 3/4). Table 4.7: Pin 9 of COM8 Function Selection (J3) Digital Input GPS (for Dead-Reckoning)

  • Page 30: Com Port Interface

    And the other four serial ports are done by a USB serial converter, and need driver support to work. In Advantech provided WES (Windows Embedded Standard) and Win CE 6.0 OS, the four USB-to-Serial serial ports are fixed from COM8 to COM11).

  • Page 31: Chapter 5 Pin Assignments

    Chapter Pin Assignments This appendix explains pin assignments on the TREK-550. Sections include: ! Internal Speaker Connector ! COM1, 2 ! GPIO / CAN BUS connector (CN31) ! Inverter / Touch / USB connector (CN18) ! Power Inlet...
  • Page 32 5.1 Front Side Connectors 5.2 Rear Side Connectors 5.3 Power Connector (12/ 24V; 6 ~ 36V) Molex Manufacturer part no. 0430451200 Power Connector Signal Signal Chassis Ground Ground Ground (Reserved) (Reserved) (Reserved) Power Input (6~36 VDC) Power Input (6~36 VDC) Acc Ignition Input Ground (Reserved)
  • Page 33 5.4 Smart Display Connector Smart Display Connector Signal Signal Backlight Enable output Panel Power Enable output LVDS Ground Reset Button Input LVDS Clock + LVDS Clock - LVDS Ground LVDS Ground LVDS Data2 + LVDS Data2 - RS232 TXD1 RS232 RXD1 LVDS Data1 + LVDS Data1 - LVDS Ground...
  • Page 34 RS-232 Connector RS-232 / RS-485 / J1708 Connector Signal Signal RS-232 DCD RS-232 RXD RS-232 TXD RS-232 DTR RS-232 Ground RS-232 DSR RS-232 RTS RS-232 CTS RS-232 RI / +5V / +V12 RS-232 / RS-485 / J1708 Connector RS-232 / RS-485 / J1708 Connector Signal Signal RS-232 RTS9...
  • Page 35 DI / DO Connector DI / DO Connector Signal Signal Isolated Dry Contact Input 1 Isolated Dry Contact Input 2 Isolated Dry Contact Input 3 Isolated Dry Contact Input 4 Isolation Ground Isolated Relay Driver Output 1 Isolated Relay Driver Output 2 Isolated Relay Driver Output 3 Isolated Relay Driver Output 4 CAN / Video-In Connector...
  • Page 36 LED indicator TREK-550 User Manual...
  • Page 37 Chapter Software demo application setup This appendix explains the software demo application for TREK-550. Sections include: ! Introduction ! How to set up demo application...
  • Page 38 For news updates, visit our website: www.advantech.com 6.1.1 Execute J1939 demo program This section explains how to install the Advantech demo program in Windows XP Pro / Embedded. 1. Execute the test program called “IMC_Demo” Figure 6. 1 2. Click J1939: customer may connect directly to the truck; we use a simulator board below to explain how J1939 protocol can be executed.
  • Page 39 Figure 6.2 J1939 truck simulator Figure 6.3 Figure 6.4 TREK-550 User Manual www.advantech.com...
  • Page 40 2. Execute PCAN-View USB Set Baud rate 250kBit/s Select [Extended] OK Transmit ID(Hex) key in number Data key in any number [Period] key in 100ms Click [Extended Frame] OK. See below figure 6. Figure 6. 11 Figure 6. 12 TREK-550 User Manual www.advantech.com...
  • Page 41 [Write Data] to write to Console PC. As for Filter Message, it can filter out the message you don’t need, and keep the message you need. See below Figure 6. Figure 6. 14 TREK-550 User Manual www.advantech.com...

  • Page 42: Rtc

    Figure 6.6 Figure 6. 7 Figure 6. 8 2. RTC Alarm Setting: You may also set Alarm time; you may wake up the system by the time you have set. Please refer to below figure 6. TREK-550 User Manual www.advantech.com...

  • Page 43: Power Management

    Figure 6.9 Power Management 6.3.1 Power management Mechanism Normal Power Management Flow ON_DELAY OFF_EVENT_DELAY HARD_OFF_DELAY Ignition ON Ignition OFF System OFF System ON Send Power Button Signal www.advantech.com...
  • Page 44 This parameter is fixed with a value of 60 seconds. After T The system stays off. LOW_DELAY is ranged from 1 to 3600 seconds. LOW_HARD_ DELAY is fixed with a value of 60 seconds. www.advantech.com...
  • Page 45 Then Click OK button and you will see the main page as below. 6.3.3 Power Management Parameter settings The parameters for power management on TREK-550 could be set by Demo program (see the image below) or SDK/API. TREK-550 User Manual www.advantech.com...
  • Page 46 Figure 6.9 On delay On Delay – it means after 2 seconds from receiving of ignition ON signal, EC controller will send a power-on event to make system start booting process. Figure 6.9 Low delay www.advantech.com...
  • Page 47 Figure 6.9 check 12 or 24 battery Check the ignition signal and see if it’s ON or OFF. C. Read current status The buttons which indicates by red squares can READ the current status of the system. TREK-550 User Manual www.advantech.com...
  • Page 48 Figure 6.9 Read the value D. Set the value www.advantech.com...
  • Page 49 The buttons which indicates by blue squares can SET the value you want to the system. Figure 6.9 Set value Execute “Power management test”, the Battery Voltage Level has 12V and 24V, you may set from 0~65 levels, press “Get” to know the value you set. www.advantech.com...

  • Page 50: Gpio

    1. Execute I/O Test, connect GPIO loopback, click Pin0 Set, the end which Read the signal, the bulb will be light up, like wise to Pin1~Pin3. Next pick Digital output to execute the same procedure. See figure 6. Figure 6.15 www.advantech.com...

  • Page 51: Video

    CAM2, choose Channel 1 on [Switch to], then panel will show the image which camera1 has taken, it will recover to the same status after 10 sec, then change to Channel 2, Panel will show what appears on camera2, and come back to the same status after 10 sec. www.advantech.com...

  • Page 52: Dead Reckoning

    Therefore, customer can decide how to set the sensitivity value when to trigger G-sensor to send signal to CPU and to back end server through WWAN module. G-sensor is located on the motherboard inside the TREK-550. Please refer the link (http://www.analog.com/static/imported-files/data_sheets/ADXL345.pdf) for the G-sensor datasheet. TREK-550 User Manual www.advantech.com...
  • Page 53 Appendix TREK-303 This appendix explains the TREK-303 detailed information. www.advantech.com...
  • Page 54 70° / 70°/ 60°/ 60° Viewing Angle (R/L/B/T) Note! The Brightness control is adjusted by the auto light sensor in the front panel as default; it is also defined by button on the front panel by manual. The color LCD display www.advantech.com...
  • Page 55 TREK-303 Specification TREK-303 demo SW application program Figure 6. 17 www.advantech.com...
  • Page 56 5. Hotkey: You may set the hotkey LED light brightness, the value is from 0 ~100. 6. Key Status: When you press Hot key, the status will change from 0 to 1. 7. Key function Definition: You may set the parameter to connect the application program of the hot key. www.advantech.com...
  • Page 58 TREK Dipol bo Antenna Comb K-550 A2/30 3 User 4 4 4 TREK...
  • Page 59 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2010 www.advantech.com...
