- Page 1 16 Port Managed USB 3.2 Gen 1 Hub w/15KV ESD Surge Protection Model Number: CG-16PU3MGD Installation Guide Coolgear, Inc. Version: 1.0 Date: 05/06/2024...
- Page 2 First Release 1. Introduction Thank you for purchasing Coolgear’s 16 Port Managed USB 3.2 Gen 1 Hub.Thank you for purchasing this Super-speed 16-port USB3.2 Gen 1 hub. It provides an ideal solution to expand 16 USB3.2 Gen 1 ports from 2 selectable USB3.2 Gen 1 host ports. It provides a wide range self power source (+12~24VDC from the 2-pin Terminal Blocks or DC Jack) to supply enough power on USB3.2 Gen 1 buses.
-
Page 3: Connector Layout
5.5 x 2.1mm (0.22 x 0.08 inch) DC Jack Plug and a 2-pin Terminal Blocks, the input voltage can be in the range from +12V to 24V DC. Please note that don’t connect power on both connectors simultaneously. Need help? Visit: coolgear.com/support... -
Page 4: Hardware Installation
However, please note the rocker switch should be set at the correct position in this case. Connect the USB devices to the downstream ports of this hub. Mount your hub on the wall, DIN RAIL or 19-inch Rack if required. DIN RAIL Mount: 19-inch Rack Mount: Need help? Visit: coolgear.com/support... - Page 5 Double click Universal Serial Bus Controller Double click Generic USB Hub, the message will show that this device is working properly. The Hub supports managing utilities called USB Hub Administrator for major recent Windows (XP and above), Mac OS and Linux: Need help? Visit: coolgear.com/support...
- Page 6 ● Click on the numeric (indicate the Port number) button to turn On/Off the USB port ● You can save the current port states by clicking the Save Port States button To use the console utility CUSBC to control the USB devices, please run Command Prompt as follows: Need help? Visit: coolgear.com/support...
- Page 7 Use a paper clip or similar object to press and hold the Restore Factory Settings button, while still holding the button power on the hub. Release the Restore Factory Settings button. Your hub resets to its factory default settings: All ports are On ● The password: pass ● Need help? Visit: coolgear.com/support...
-
Page 8: Environmental Specifications
Within Every Great Machine For over 20 years our rugged, off-the-shelf USB hubs, chargers, and serial products are ready to go for your next project. Based in the US, Coolgear has successfully engineered and deployed millions of connectivity solutions into industrial, medical, automotive, commercial, and aerospace industries. - Page 9 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
