- Page 1 16-Port USB 3.1 Gen1 Metal Hub w/15KV ESD Surge Protection and DIN Rail Mounting Kit Product Manual Coolgear, Inc. Version 1.1 September 2017 Model Number: CG-16PU31H www.coolgear.com...
- Page 2 Coolgear New Manual About this document This product manual outlines installation and features of the CG-16PU31H 16-Port USB 3.1 Gen1 Metal Hub w/15KV ESD Surge Protection and DIN Rail Mounting Kit. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
-
Page 3: Table Of Contents
CG-16PU31H – Product Manual Table of Contents 1. Introduction ......................4 Features ........................4 Connector Layout ....................5 Hardware Installation ..................... 5 Checking the Hub Installation ................. 6 Environmental Specifications ................. 7 2. Notes, Tips, Warnings, & Safety ................8 3. -
Page 4: Introduction
CG-16PU31H – Product Manual 1. Introduction Unique 16-Port USB 3.1 Gen1 hub is a compact solution with a big purpose. Its uniquely designed shell expands your USB port usage by 16 from your USB 3.1 Gen1 host port. This is a self powered hub uses a +7~24V DC 2-pin terminal block power connector from an external power adapter (sold separately). -
Page 5: Connector Layout
CG-16PU31H – Product Manual 1.2 Connector Layout Figure 1 USB 3.1 Upstream Port USB 3.0 Downstream Port Self Power Input Type-B female connector There are 16 Type-A female This 2-pin (one pin for from upstream USB 3.1 connectors for USB 3.1, positive voltage and the port. -
Page 6: Checking The Hub Installation
CG-16PU31H – Product Manual connector), The terminal block connector is to add power to ensure enough power for the 16 downstream ports. 3. Connecting USB Host cables: The host cable could be either a standard B-to- A USB 3.1 cable. Please connect the Type-A end connector of the cable to your PC’s host USB 3.1 port, then connect the type-B end connector to the... -
Page 7: Environmental Specifications
CG-16PU31H – Product Manual 1. Click Start 2. Click Control Panel 3. Click System 4. Click Device Manager button 5. Double Click Universal Serial Bus Controller 6. Double click Generic USB Hub, the message will show that this device is... -
Page 8: Notes, Tips, Warnings, & Safety
CG-16PU31H – Product Manual 2. Notes, Tips, Warnings, & Safety In some cases, you will see an error message said that the USB Hub caused the USB bus power over current limit, please ignore this message since the Note hub is hot plug and its power capacitor will cause a very short period of current. -
Page 9: Supporting References
© 2017 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
