- Page 1 7 Port Managed USB 3.2 Gen 1 Hub w/ 15KV ESD Surge Protection Model Number: CG-7MGDU31HB Installation Guide Coolgear, Inc. Version: 1.0 Date: 06/20/2024...
-
Page 2: Table Of Contents
First Release 1. Introduction Thank you for purchasing Coolgear’s 7 Port Managed USB 3.2 Gen 1 Hub. The Super-speed Hub is supplied with managing software utilities which can turn on/off the bus power of each downstream device or even reset the entire hub by user or application programs. -
Page 3: Connector Layout
4. Self Power Input Connectors: The DC-Jack or 2-pin (one pin is for the positive voltage and the other pin is GND) terminal blocks is used to connect wide range power source to self-power the hub, the voltage can be in the range from +7V to 24V DC. Need help? Visit: coolgear.com/support... -
Page 4: Hardware Installation
USB hub is plug-and-play, you don’t have to turn off your host computer when installing the hub. 2. Connect the USB devices to the downstream ports of this hub. 3. Mount your hub on the wall or DIN RAIL if required. Need help? Visit: coolgear.com/support... -
Page 5: Usb Hub Administrator Utilities Installation
Click the item on the list to select the Hub to control ● Click on the numeric (indicate the Port number) button to turn On/Off the USB ● port You can save the current port states by clicking the Save Port States button ● Need help? Visit: coolgear.com/support... -
Page 6: Restore To Factory Settings
Use a paper clip or similar object to press and hold the Restore Factory Settings button, while still holding the button power on the hub. Release the Restore Factory Settings button. Your hub resets to its factory default settings: All ports are On ● The password: pass ● Need help? Visit: coolgear.com/support... -
Page 7: Environmental Specifications
Within Every Great Machine For over 20 years our rugged, off-the-shelf USB hubs, chargers, and serial products are ready to go for your next project. Based in the US, Coolgear has successfully engineered and deployed millions of connectivity solutions into industrial, medical, automotive, commercial, and aerospace industries. - Page 8 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
