- Page 1 7-Port Managed USB3.2 Gen 1 Metal Hub w/DIN RAIL Mounting Kit Model Number: CG-7PU3MGD Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/03/2024...
-
Page 2: Table Of Contents
First Release 1. Introduction Thank you for purchasing Coolgear’s 7-Port Managed USB3.2 Gen 1 Metal Hub. The Super-speed Hub is supplied with managing software utilities which can turn on/off the bus power of each downstream device or even reset the entire hub by user or application programs. -
Page 3: Connector Layout
This can be accomplished by touching a bare metal chassis rail after you have turned off the power. Apply DC power (range from +7V to 48V) to the 2-pin Screw-Lock Terminal Block Connector. Need help? Visit: coolgear.com/support... -
Page 4: Usb Hub Administrator Utilities Installation
6. Install the USB Hub Administrator Utilities as described in the following chapter 4. USB Hub Administrator Utilities Installation The Hub supports managing utilities called USB Hub Administrator for major recent Windows (XP and above) and Linux: Need help? Visit: coolgear.com/support... - Page 5 ● Click the item on the list to select the Hub to control ● Click on the numeric (indicate the Port number) button to turn On/Off the USB port ● You can save the current port states by clicking the Save Port States button Need help? Visit: coolgear.com/support...
-
Page 6: Restore To Factory Settings
On the side of your hub, locate the hole of the Restore Factory Settings button Use a paper clip or similar object to press and hold the Restore Factory Settings button, while still holding the button power on the hub. Release the Restore Factory Settings button. Need help? Visit: coolgear.com/support... -
Page 7: Environmental Specifications
Within Every Great Machine For over 20 years our rugged, off-the-shelf USB hubs, chargers, and serial products are ready to go for your next project. Based in the US, Coolgear has successfully engineered and deployed millions of connectivity solutions into industrial, medical, automotive, commercial, and aerospace industries. - Page 8 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
