7 Port Managed USB 3.2 Gen 1 Hub w/
15KV
ESD Surge Protection
Model No.
CG-7PU3MGD
1. Introduction
Thank you for purchasing this 7-port Managed USB3.2 Gen 1 hub. The
Super-speed Hub is supplied with managing software utilities which can turn
on/off the bus power of each downstream device or even reset the entire hub by
user or application programs. It enables the success of your critical USB
applications instantly and improve your investment returns.
Features:
✓ Compliant with USB Specification 3.2 Gen 1
✓ Metal Case, DIN Rail and wall mountable
✓ Software Manageable Bus power for each Port
✓ Supports software utilities for Windows (XP and newer), Linux
✓ Provides 7 Downstream USB3.2 Gen 1 Facing Ports (see Note 1)
✓ Provides 7 LEDs Indicating each bus power states
✓ Supports 5Gbps (Super-speed), 480Mbps (High speed), 12Mbps (Full-speed)
and 1.5Mbps (Low-speed) Speed
✓ Supports 15KV ESD Level 4 Protection for Each Port
✓ Supports +7~48V DC Wide Range Input Power
✓ Supports USB Battery Charging v1.2 : CDP, DCP modes
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG-7PU3MGD and is the answer not in the manual?

Questions and answers

Related Manuals for CoolGear CG-7PU3MGD

Summary of Contents for CoolGear CG-7PU3MGD

  • Page 1 7 Port Managed USB 3.2 Gen 1 Hub w/ 15KV ESD Surge Protection Model No. CG-7PU3MGD 1. Introduction Thank you for purchasing this 7-port Managed USB3.2 Gen 1 hub. The Super-speed Hub is supplied with managing software utilities which can turn on/off the bus power of each downstream device or even reset the entire hub by user or application programs.

  • Page 2: Connector Layout

    7-Port Managed USB3.2 Gen 1 Metal Hub with DIN RAIL Mounting Kit 2. Connector Layout Screw-Lock Terminal Port On/Off State LED Indicators Power LED Blocks (this is Port 1) DC-Jack Upstream Port Connector USB-A Downstream Ports USB-A Downstream Facing Port Connectors: There are 7 USB-A screw-lock connectors for standard USB3.2 Gen 1 and legacy USB2.0/1.1 devices.

  • Page 3: Hardware Installation

    7-Port USB3.2 Gen 1 Managed Metal Hub with DIN RAIL Mounting Kit blocks is used to connect wide range power source to self-power the hub, the voltage can be in the range from +7V to 48V DC. 3. Hardware Installation Use static electricity discharge precautions.
  • Page 4 7-Port Managed USB3.2 Gen 1 Metal Hub with DIN RAIL Mounting Kit Connecting USB Host cable: The host cable can be a standard B-to-A or B-to-C USB3.2 Gen 1 cable (depends on the host port’s connector type). Please connect the type-A (or Type-C) end connector of the cable to your USB host port, then connect the type-B end connector to this hub.
  • Page 5 7-Port USB3.2 Gen 1 Managed Metal Hub with DIN RAIL Mounting Kit The Hub supports managing utilities called USB Hub Administrator for major recent Windows (XP and above) and Linux: The above folders include the software for different platforms. If you are installing it on Windows, please find the executable setup program in Windows folder, double-click it: Please follow the on-screen instructions of the setup...
  • Page 6 7-Port Managed USB3.2 Gen 1 Metal Hub with DIN RAIL Mounting Kit ⚫ Click Auto Search to find all Managed USB Hubs ⚫ Click the item on the list to select the Hub to control ⚫ Click on the numeric (indicate the Port number) button to turn On/Off the USB port ⚫...

  • Page 7: Restore To Factory Settings

    7-Port USB3.2 Gen 1 Managed Metal Hub with DIN RAIL Mounting Kit To see all CUSBC commands, type: CUSBC /? To query all Hubs connected: CUSBC /Q 5. Restore to Factory Settings To perform a factory reset: Verify that your hub’s Power LED is off.
  • Page 8 7-Port Managed USB3.2 Gen 1 Metal Hub with DIN RAIL Mounting Kit On the side of your hub, locate the hole of the Restore Factory Settings button: Restore Factory Settings button Use a paper clip or similar object to press and hold the Restore Factory Settings button, while still holding the button power on the hub.

  • Page 9: Environmental Specifications

    7-Port USB3.2 Gen 1 Managed Metal Hub with DIN RAIL Mounting Kit 6. Environmental Specifications Operating temp.: 0 to 55C (32 to 131F) Operating humidity: 5 to 95% RH Dimensions (LxWxH): 163 x 55.0x 31.2 mm (6.41 x 2.16 x 1.22 in)
