5
5a
6
6.5 Baking
In order to get better yield, the module need to bake before SMT.
If the packaging is in perfect condition, the module which dateofproduction is within six months has no
use for baking. If the dateofproduction is more thansix months, the module must be baking.
If the packaging had been opened or damaged, the module must be baking.
Table 40: Baking conditions
conditions
Baking temperature
Baking time
NOTE
IPC / JEDEC J-STD-033standard must be followed for production and storage.
www.simcom.com
48 hours at ≦30℃/60% RH
24 hours at ≦30℃/60% RH
Mandatory bake before use. After bake, it must be reflowed within the
time limit specified on the label.
parameters
120℃
8 hours
SIM7075G User Manual V1.00
61 / 74
