Sunsea AIoT SIMCom SIM7075G User Manual page 42

18 -108.2
19 -108.2
20 -108.2
25 -108.2
26 -108.2
28 -108.2
31 -108.2
66 -108.2
71 -108.2
NOTE
The 12/7/1/128 of the REFSENS Typical Repeated 12/ 7/1/128 means Subcarriers=12, MCS.TBS=7,
#SF/#RU=1, #Repetition=128.
4.2 LTE Antenna Design Guide
Users should connect antennas to SIM7075G antenna pads through micro-strip line or other types of RF
trace and the trace impedance must be controlled in 50Ω. SIMCom recommends that the total insertion loss
between the antenna pads and antennas should meet the following requirements:
Table 28: Trace loss
Frequency
700MHz-960MHz
1710MHz-2170MHz
2300MHz-2650MHz
To facilitate the antenna tuning and certification test, a RF connector and an antenna matching circuit
should be added. The following figure is the recommended circuit.
www.simcom.com
-114.9 -129
-115.1 -128
-114.1 -128
-114.6 -130
-114.6 -129
-115.9 -130
-114.8 -129
-114.4 -129
Loss
<0.5dB
<0.9dB
<1.2dB
SIM7075G User Manual V1.00
-114.9 -129
-115.1 -128
-114.1 -128
-114.6 -130
-114.6 -129
-115.9 -130
-114.7 -129
-114.8 -129
-114.9 -129
-115.1 -128
-114.1 -128
-114.6 -130
-114.6 -129
-115.9 -130
-114.8 -129
-114.4 -129
42 / 74
