LTE-FDD B19
LTE-FDD B20
LTE-FDD B25
LTE-FDD B26
LTE-FDD B28
LTE-FDD B31
LTE-FDD B66
LTE-FDD B71
5.5 ESD Notes
SIM7075G is sensitive to ESD in the process of storage, transporting, and assembling. WhenSIM7075G is
mounted on the users' mother board, the ESD components should be placed beside the connectors which
human body may touch, such as SIM card holder, audio jacks, switches, keys, etc. The following table
showsSIM7075G ESD measurement performance without any external ESD component.
Table 37: The ESD performance measurement table (Temperature: 25℃, Humidity: 45%.)
Part
VBAT,GND
Antenna port
Other PADs
www.simcom.com
@21dbm Typical: 147mA
@10dbm Typical: 80mA
@0dbm Typical: 53mA
@21dbm Typical: 147mA
@10dbm Typical: 81mA
@0dbm Typical: 52mA
@21dbm Typical: 140mA
@10dbm Typical: 87mA
@0dbm Typical: 54mA
@21dbm Typical: 147mA
@10dbm Typical: 81mA
@0dbm Typical: 53mA
@21dbm Typical: 143mA
@10dbm Typical: 81mA
@0dbm Typical: 53mA
@26dbm Typical: 302mA
@17dbm Typical: 185mA
@8dbm Typical:120mA
@21dbm Typical: 141mA
@10dbm Typical: 87mA
@0dbm Typical: 53mA
@21dbm Typical: 133mA
@10dbm Typical: 76mA
@0dbm Typical: 64mA
Contact discharge
+/-6K
+/-5K
+/-1K
SIM7075G User Manual V1.00
Air discharge
+/-12K
+/-10K
+/-3K
