GPIO
NETLIGHT 52
STATUS 66
W_DISABLE# 18
AP_READY 19
GPIO31 16
GPIO6 25
GPIO7 26
GPIO12 64
GPIO13 65
GPIO50 66
GPIO57 83
GPIO58 84
GPIO52 85
GPIO36 86
GPIO40 87
GPIO41 88
GPIO20 93
RF interface
ANT_GNSS 49
ANT_MAIN 60
Other interface
BOOT_CFG 6
ADC1 2
ADC0 24
PS_HOLD 94
www.simcom.com
LED control output as network status
DO
indication.
Operating status output.
High level: Power on and firmware
DO
ready
Low level: Power off
DI Airplane mode control
Application processor sleep state
DI
detection
General purpose input/output, With
IO
interrupt function
General purpose input/output, Without
IO
interrupt function.
General purpose input/output, Without
IO
interrupt function.
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
General purpose input/output, With
IO
interrupt function
AI GNSS antenna soldering pad
AIO MAIN antenna soldering pad
If it needs to enter into forced USB
download mode, it must be pulling up
DI,PD this pin to VDD_EXT before press the
PWRKEY. If it needs to boot up
normally, please keep this pin open
Analog-digital converter input.
AI
voltage range:0V～1.875V.
Analog-digital converter input.
AI
voltage range:0V～1.875V.
Power supply hold control input. This
DI
signal's main purpose is to tell the
SIM7075G User Manual V1.00
If unused, keep them
open.
50Ω impedance
50Ω impedance
Reserve a test points
for it. Keep it open.DO
NOT PULL UP DURING
NORMAL POWER UP!
ADC0 and ADC1
cannot be used
Simultaneously, if
unused, keep them
open.
C =10 pF
max
