- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S LVSXUP LVS1UP ConnexSys™ Portrait Video Wall Mounting System Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description...
-
Page 2: Important Safety Instructions
150 lbs LVSXUP (68.0 kg) Chief®, ConnexSys™, RapidDraw™, and PowerZone™ are trademarks of Milestone AV Technologies. All rights reserved. The video wall system ships either with rails IMPORTANT ! : (LVS1UP) or without (LVSXUP). If you’re installing a video wall of LVSXUP mounts you will need to provide the strut channel for mounting to the wall. -
Page 3: Table Of Contents
Installation Instructions LVS1UP / LVSXUP TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ........2 TABLE OF CONTENTS ...............3 LEGEND ..................4 DIMENSIONS ................5 TOOLS REQUIRED FOR INSTALLATION .........6 PARTS ..................6 LET’S GET STARTED! Measurements You’ll Need ....7 MOUNTING PATTERN OFFSET CALCULATION ......8 STRUT CHANNEL REQUIREMENTS (LVSXUP) .......8 CURVED VIDEO WALLS ON FLAT WALL ........9 Calculating Wall Radius ............9 ALLOWING SPACE FOR MOUNT ADJUSTABILITY....9... -
Page 4: Legend
LVS1UP / LVSXUP Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación... -
Page 5: Dimensions
Installation Instructions LVS1UP / LVSXUP DIMENSIONS LVS1UP 15.75 400.0 4.09 M A X DISPLA Y BA C K TILT 103.9 PA TTERN W IDTH MIN DEPTH 1.00 25.4 HEIG HT A DJUST 31.50 800.0 M A X DISPLA Y PA TTERN HEIG HT 32.50 825.4 DIMENSIONS:... -
Page 6: Tools Required For Installation
LVS1UP / LVSXUP Installation Instructions TOOLS REQUIRED FOR INSTALLATION 7/16" 1/2" 3/8" nut driver 7/16" 7/32" 7/16" 1/2" 1/8" x 6" 1/2" 3/8" (included) 3/8" PARTS Display Hardware Kit Concrete and Wood Stud Walls (Letters correspond to letters on bag) Install Hardware Kit K (4) A (4) -
Page 7: Let's Get Started! Measurements You'll Need
Installation Instructions LVS1UP / LVSXUP LET’S GET STARTED! Table 1: Measurements You’ll Need Description Measurement Number of displays in each row Number of displays in each column Width of individual display Height of individual display Total width - (A) x (C) Floor to bottom of display (bottom row) OR Ceiling to top of display (top row) 1/2 height of display... -
Page 8: Mounting Pattern Offset Calculation
LVS1UP / LVSXUP Installation Instructions MOUNTING PATTERN OFFSET CALCULATION NOTE: An offset measurement (H) is required if the centerline of the display does not match the centerline of the display mounting pattern. 1. If display mounting pattern is BELOW display centerline: Center line of 8-3/4"... -
Page 9: Curved Video Walls On Flat Wall
Installation Instructions LVS1UP / LVSXUP CURVED VIDEO WALLS ON FLAT WALL • 5.5° is the maximum angle a mount can make from vertical; • Two or more mounts placed side-by-side can create a maximum angle of 11° (on a flat wall); •... -
Page 10: Attaching Strut Channel Or Rail
LVS1UP / LVSXUP Installation Instructions 11. Measure up from attached rails the distance (D) and mark ATTACHING STRUT CHANNEL OR RAIL for next row of rails (V). (See Figure 1) and (See Figure 7) IMPORTANT ! : Reference measurements noted on page 7. -
Page 11: Hanging Lvs1Up/Lvsxup Mount On Rail/Strut Channel
Installation Instructions LVS1UP / LVSXUP HANGING LVS1UP/LVSXUP MOUNT ON RAIL/ wall STRUT CHANNEL side Preparing Strut Channel (LVSXUP only) view On the top rail, slide one inner stop clamp (S) into end of strut channel section. (See Figure 8) Fasten outer stop clamp (R) to inner stop clamp (S) using one 1/4-20 x 1/2"... -
Page 12: Installing Interface Brackets
LVS1UP / LVSXUP Installation Instructions Make sure diamond on interface brackets is even with INSTALLING INTERFACE BRACKETS center of display. (See Figure 12) Place displays face down on a soft, non-abrasive surface. Use selected screws (A-C or F-H), washers (D, if using screws A, B or C) and spacers (E), if necessary, to connect interface brackets (X) to back of display. -
Page 13: Adjustments
Installation Instructions LVS1UP / LVSXUP ADJUSTMENTS NOTE: The following steps are also referenced on the next page (See Figure 18) and the PowerZone Adjustment guide (Z). Place the level against the front of the display and use knob (#1 in Figure 18) to straighten the tilt. (See Figure 14) Figure 16 Slide latch mechanism until tab sits flush against the interface bracket. - Page 14 Installation Instructions LVS1UP / LVSXUP Figure 18...
-
Page 15: Completing The Installation
Installation Instructions LVS1UP / LVSXUP COMPLETING THE INSTALLATION SERVICE Cable Management Clips Extending and Retracting Mount Place cable clip (Q) into rail/strut channel and turn 90° in The mounts may be extended and retracted only in a service either direction until cable clip is vertical. (See Figure 19) situation. -
Page 16: Rapiddraw Display Release
LVS1UP / LVSXUP Installation Instructions RapidDraw Display Release FASTENER INSTALLATION METHODS The RapidDraw pull cord and display release allows easy IMPORTANT ! : (See Table 4) for appropriate hardware service access to any specific display in the video wall. and pilot hole sizes for various wall types. Each mount ships with the pull cord installed. -
Page 17: Plywood-Backed Steel Stud
LVS1UP / LVSXUP Installation Instructions Plywood-Backed Steel Stud Use one #14 x 1-1/2" hex-head washer slot head screw (N) and one 1/4" washer (M) through strut channel or rail. (See Figure 25) If back side of wall is unfinished, drywall must be installed to a minimum of one stud left and right of the stud(s) being used to install the mount. - Page 18 LVS1UP / LVSXUP Installation Instructions...
- Page 19 Installation Instructions LVS1UP / LVSXUP...
- Page 20 A Franklinstraat 14, 6003 DK Weert, Netherlands Europe P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies Asia Pacific 18-24 Shan Mei Street...
