Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 Assembly Video Available Navigate to the middle of the product page to watch as our product specialists walk you through the assembly process. www.vivo-us.com/products/stand-tv120b WATCH NOW...
Returns: We offer a hassle-free 30 day return on all products. Contact customer support at 309-278-5303 or help@vivo-us.com. Please note: For items ordered in error or no longer needed, the return shipping charges will be at the buyer’s expense. Product Specific Warnings: WARNING: CHOKING HAZARD SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS.
Page 4
Package Contents A (x1) B (x1) C (x1) D (x4) E (x2) F (x2) Left Leg Right Leg Base Caster Lower Column Upper Column G (x2) H (x1) I (x1) J (x1) K (x1) L (x1) Handle Mounting Plate Media Shelf Left TV Bracket Right TV Bracket Camera Shelf...
Assembly Steps STEP 1 Attach the Left Legs (A) and Right Leg (B) to the Base (C) with M8x20mm Screws (S-C) using a 6mm Allen Wrench (T-B), as shown below. Ensure the imprinted arrows on the Legs (A,B) and Base (C) are all pointing towards the back of the assembly.
Page 6
STEP 2 Secure the Casters (D) to the legs with an M12 Wrench (T-D). LOCKING CASTERS To avoid sudden movements during the installation process, press down the Locking tab (D1) on Casters. Leveling Casters If the Caster (D) can’t touch the ground, loosen the lower nut with Wrench (T-D) as shown to adjust...
Page 7
STEP 3 Attach Lower Columns (E) to the assembled base using M8x80mm Screws (S-B) with Washers (S-A) and 6mm Allen Wrench (T-B). Assemble Upper Columns (F) to Lower Columns (E) using M8x20mm Screws (S-C) and 6mm Allen Wrench (T-B) . Then slide the Handles (G) over Upper Columns as shown below.
Page 8
STEP 4 Loosen the 8 screws shown below on Mounting Plate (H) using 5mm Allen Wrench (T-A). There is a gap between the brackets on Mounting Plate (H) and the top of the plate. This gap should be on top when installed. Slide Mounting Plate down onto Upper Columns (F) and retighten the 8 Screws.
Page 9
STEP 5 Press on Top Covers (O) into Upper Columns (F) and End Caps (N) onto Mounting Plate (H) as shown below. STEP 6 Loosen the two screws on both of the upright Then slide Media Shelf down into the groove on Lower Columns (E) and then retighten the four brackets on Media Shelf (I) using 5mm Allen Wrench (T-A).
Page 10
STEP 7 Assemble Left TV Bracket (J) and Right TV Bracket (K) to the back of the television using appropriate Screws (M-A thru M-E) with Square Washers (M-F) and Spacers (M-G, M-H ) if necessary. Too Long Too Short Flat Back TV Offset Back TV...
STEP 8 Hang the TV with Left TV Bracket (J) and Right TV Bracket (K) onto Mounting Plate (H). Secure the TV Secure the assembly by tightening the security screw on the bottom of the TV brackets using a Phillips screwdriver.
Page 12
STEP 9 Attach Camera Shelf (L) to Camera Shelf Support (M) using M5x8mm Screws (S-D) and a Phillips screwdriver. Then mount Shelf Support at the desired height on Mounting Plate (H) using M8x12mm Screws (S-E) with Spacer (S-F) and 5mm Allen Wrench (T-A), making sure the spacer goes between Camera Shelf Support (M) and Mounting Plate (H) in the bottom hole as shown below.
Page 13
STEP 10 Route cables through the provided slots in the columns and attach the Cable Covers (P) to hold them in place. Store the Allen Wrenches (T-A, T-B) in the holes in Handles (G).
Page 14
Assembly Complete Height markings represent the distance from the floor to the center of the brackets (this includes the casters).
Page 15
Securely store your PC in Clamp on & under desk and more with our clamp-on an under desk mount or keyboard tray options for and wall mount solutions. cart for easy access. all setup types. Explore Endless Workspace Solutions www.vivo-us.com...
Page 16
Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
