Easel Studio TV Stand with RGB Light
Instruction Manual
SKU: STAND-TV70C,D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv70c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo Easel Studio STAND-TV70C
Summary of Contents for Vivo Easel Studio STAND-TV70C
- Page 1 Easel Studio TV Stand with RGB Light Instruction Manual SKU: STAND-TV70C,D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv70c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Assembly Steps
DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting hardware for brick and concrete walls. If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303. ASSEMBLY STEPS STEP 1 Screw Legs (B) into the Base (A). - Page 4 STEP 3 Remove Screws (E1) from the Lower VESA Bracket (E) using a Phillips screwdriver and open the clamps. STEP 4 OPTION A: Flat Back TV Position Upper VESA Bracket (D) over top holes on TV and secure with Screws (M-A or M-B), M8 Washers (M-E), M5 Washers (M-I) and Security Clips (J).
- Page 5 STEP 5 Slide the TV onto assembled stand. Close the clamps on the Lower VESA Bracket (E) over the poles and secure with the previously removed Screws (E1). Peel backing from the Cable Clips (F) and install clips on the rear legs. For STAND-TV70D: Secure clips by threading ST4.2x12mm Screws (S-A) directly into the wood legs.
- Page 6 STEP 6 (Continued) To connect to an external RGB controller, remove the screw on the underside of the Base (A) holding the left side cover, then remove the cover. Remove the security tape from the RGB connector, then disconnect and pull out the cable. Connect the cable to the external RGB controller.
- Page 7 STEP 7 (Continued) Thread Security Cable (I) through Security Clips (J) on TV and center holes in cable clamps as shown, then tighten clamps using the 2mm Allen wrench (T-B). OPTION B: Concrete/Brick Wall Using Security Cable Clamps (K) as guides, mark drilling locations on wall at the same height as the upper VESA bracket, spaced 400mm - 650mm (16”...
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
