Black V-Base Studio TV Stand
Instruction Manual
SKU: STAND-TV70B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv70b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-TV70B
Summary of Contents for Vivo STAND-TV70B
- Page 1 Black V-Base Studio TV Stand Instruction Manual SKU: STAND-TV70B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv70b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 88lbs Failure to do so may result in serious injury. (40kg) Pliers Phillips Tape Screwdriver Measure ASSEMBLY STEPS STEP 1 Slide the feet (C) onto the base of the leg (A). Insert M8x12 bolts (J) into the bottom holes of the feet, and M6x15 bolts (K) through the base into the rear holes of the feet. - Page 4 STEP 3 Remove the screw from the lower VESA bracket (E) to separate into parts E1 and E2, and open the clamp. STEP 4 OPTION A: Flat Back TV Position VESA brackets horizontally on the back of the TV, making sure the upper bracket (D) is on top and the lower bracket (E2) is below.
- Page 5 STEP 5 Slide the TV with VESA brackets (D, E2) onto the pole (B). Close the clamp on the lower VESA bracket over the pole and secure with previously removed screw (E1). STEP 6 Route cables through the cables holes in the leg (A). Install cable covers (L) to the cables holes, using pliers to break out sections for x2 or x3 cables if needed.
- Page 6 STEP 7 OPTION A: Wood Wall Installation Using security cable clamps (I) as guides, mark drilling locations on the wall. Use of a stud finder is recommended. Drill holes at least 1.6” (40mm) deep using a 1/8” (3.5mm) drill bit. Mount clamps to the wall using 1-1/4” screws (P). Thread steel cable (G) through the security clips on the TV and center holes in the cable clamps as shown, then tighten clamps using the 2mm Allen wrench (M).
- Page 7 STEP 7 (Continued) OPTION B: Concrete/Brick Wall Installation Using security cable clamps (I) as guides, mark drilling locations on the wall. Drill holes at least 1.6” (40mm) deep using a 9/32” (7mm) drill bit. Insert anchors (Q) into the holes and mount clamps to the wall using 1-1/4” screws (P). Thread steel cable (G) through the security clips on the TV and center holes in the cable clamps as shown, then tighten clamps using the 2mm Allen wrench (M).
- Page 8 - 92% within < 3hr : < 15 M www.vivo-us.com AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
