- Page 1 User manual PIX-B660 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………5-6 DMX Channels ……………………………………………………………………………………7-13 ……………………………………………………………………………………13 Trouble Shooting…………………………………………………………………………………14 Fixture Cleaning………………………………………………………… ………………………14 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu Menu Operation 1-492 (21 ch) DMX Address 1-462 (51 ch) 1-458 (55 ch) 1-438(75 ch) 21CH 51CH DMX Channel Mode 55CH 75CH Takes all traits to 0 Blackout when DMX signal is SETTINGS lost or interrupted. Holds all traits at last received value when Hold No DMX Status... - Page 6 6000Hz 10KHz 15KHz 20KHz 25KHz Tilt 000 - 255 Zoom 000 - 255 Dimmer 000 - 255 Main Red 000 - 255 Main Green 000 - 255 Main Blue 000 - 255 Main White 000 - 255 Line Yellow 000 - 255 Line White 000 - 255 All Test...
-
Page 7: Dmx Channels
4.DMX Channels 21CH Channel Value Function 000-255 Vertical 000-255 Vertical fine-tuning 000-255 Vertical effect 000-255 XY speed 000-255 Zoom 000-255 Total dimming 000-255 Total dimming fine-tuning Total strobe 000-007 008-015 016-131 Strobe, from slow to fast 132-139 140-181 Slow on and fast off, from slow to fast 182-189 190-231 Fast on and slow off, from slow to fast... - Page 8 51CH Channel Value Function 000-255 Vertical 1 000-255 Vertical 1 fine adjustment 000-255 Vertical 2 000-255 Vertical 2 fine adjustment 000-255 Vertical 3 000-255 Vertical 3 fine adjustment 000-255 Vertical 4 000-255 Vertical 4 fine adjustment 000-255 Vertical 5 000-255 Vertical 5 fine adjustment 000-255 Vertical 6...
- Page 9 000-255 Main light red light 4 000-255 Main light green light 4 000-255 Main light blue light 4 000-255 Main light White light 4 000-255 Main light Red light 5 000-255 Main light Green light 5 000-255 Main light Blue light 5 000-255 Main light White light 5 000-255...
- Page 10 000-255 Main light blue light 1 000-255 Main light white light 1 000-255 Main light red light 2 000-255 Main light green light 2 000-255 Main light blue light 2 000-255 Main light white light 2 000-255 Main light red light 3 000-255 Main light green light 3 000-255...
- Page 11 75CH Channel Value Function 000-255 Vertical 1 000-255 Vertical 1 fine adjustment 000-255 Vertical 2 000-255 Vertical 2 fine adjustment 000-255 Vertical 3 000-255 Vertical 3 fine adjustment 000-255 Vertical 4 000-255 Vertical 4 fine adjustment 000-255 Vertical 5 000-255 Vertical 5 fine adjustment 000-255 Vertical 6...
- Page 12 240-247 Random strobe, from slow to fast 248-255 Open light 000-255 Main light color temperature 000-255 Main light color 000-255 Main light red light 1 000-255 Main light green light 1 000-255 Main light blue light 1 000-255 Main light White light 1 000-255 Main light Red light 2 000-255...
- Page 13 000-255 Auxiliary light 10 Yellow light 000-255 Auxiliary light 10 White light 000-255 Auxiliary light 11 Yellow light 000-255 Auxiliary light 11 White light 000-255 Auxiliary light 12 Yellow light 000-255 Auxiliary light 12 White light 000-255 Special function 5.dimension...
-
Page 14: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
