May 7, 2025
Ver1.02
USB3.0 CMOS 250M Pixels CAMERA
ARTCAM-8020-USB3
INSTRUCTION BOOKLET
ARTRAY CO., LTD.
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARTCAM-8020-USB3 and is the answer not in the manual?

Questions and answers

Summary of Contents for ARTRAY ARTCAM-8020-USB3

  • Page 1 May 7, 2025 Ver1.02 USB3.0 CMOS 250M Pixels CAMERA ARTCAM-8020-USB3 INSTRUCTION BOOKLET ARTRAY CO., LTD. - 1 -...
  • Page 2: Table Of Contents

    Region of Interest (ROI) ......................- 14 - 6.3. Spectral sensitivity characteristics (reference value) ................ - 15 - 6.3.1. ARTCAM-8020-USB3-OP (color model) ................... - 15 - 6.3.2. ARTCAM-8020-BW-USB3-OP (monochrome model) ............... - 15 - System Requirements ..........................- 16 - 7.1.
  • Page 3: Attention

    1. Attention ■About this manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4.
  • Page 4 ■For Safe Use Warning ●Under the following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fire and electric shock. If the product is defective, please contact us for repair or replacement. For your safety, please do not disassemble, modify or repair the camera yourself. Please stop using the product and turn off the power immediately if: ・The camera emits smoke, becomes abnormally hot, or produces unusual smells or sounds.
  • Page 5 For more details, please refer to the following link: Hardware Warranty: http://www.artray.us/download/artray_warranty.pdf ●We do not guarantee that the functions of this product or the descriptions on this manual are suitable for the customer's intended use or marketability.
  • Page 6: Introduction

    2. Introduction This manual elaborates the product specifications of the color camera ARTCAM-8020-USB3, as well as the monochrome camera ARTCAM-8020-BW-USB3 equipped with CMOS sensor and USB3.0 output. 3. Features ⚫ High Resolution It is possible to capture approximately 250 million pixels (19,568 × 12,588 pixels), which is about 30 times the resolution of 4K.
  • Page 7: Connections

    5. Connections 5.1. How to Connect a Camera (an example) - 7 -...
  • Page 8: Specification

    6. Specification 6.1. Specifications Items ARTCAM-8020-USB3 ARTCAM-8020-BW-USB3 CANON RGB Sensor CANON Monochrome Sensor Model LI8020SAC LI8020SAM Active Pixels 19,568(W) × 12,588(H) Effective Pixel 19,568(W) × 12,588(H) 1.5[μm] × 1.5[μm] Pixel Size 29.35[mm] × 18.88[mm] Active Image Size (APS-H size equivalent) Spectral Range 350~850nm (QE>10%)
  • Page 9: Functions Of Camera

    6.2. Functions of camera 6.2.1. Shutter Speed The exposure time (electronic shutter speed) of the camera can be set. The exposure time can be calculated by the following formula: Exposure time = the setting value of the shutter speed * 100μsec (Setting range: 1~26000) The formula for calculating the 1-line time is as follows, which is common to all pixel output (19,568 x 12,588) and ROI setting.
  • Page 10: Dimensional Outline

    6.2.2. Dimensional Outline ・M58 mount Type ※The dimension might be changed. - 10 -...
  • Page 11 ・F-mount Type (optional) ※The dimension might be changed. - 11 -...
  • Page 12 ・Sensor exposed type without lens mount (with camera case) ※The dimension might be changed. - 12 -...
  • Page 13: Sensor Package Information

    6.2.3. Sensor Package Information 6.2.4. Position Relationship Diagram between the sensor package and the light receiving surface H=1.5[um] * 19,568 =29.352[mm] V=1.5[um] * 12,588 =18.882[mm] - 13 -...
  • Page 14: Region Of Interest (Roi)

    6.2.5. Region of Interest (ROI) This function can reduce unnecessary data and improve the frame rate by cutting out any area within the effective pixels. It is possible to cut out any area by setting the “origination” and “effective pixels”. For "origination", please set the effective position of both "horizontal origination"...
  • Page 15: Spectral Sensitivity Characteristics (Reference Value)

    6.3. Spectral sensitivity characteristics (reference value) 6.3.1. ARTCAM-8020-USB3-OP (color model) ARTCAM-8020-BW-USB3-OP ( 6.3.2. monochrome model) - 15 -...
  • Page 16: System Requirements

    One potential cause of the issue could be insufficient regulation of the power lines, which can result in a mismatch in data signal strength. * For inquiries regarding the recommended extension cable, please contact our sales department. (TEL: +81-3389-5488) ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel: +81-3-3389-5488 Fax: +81-3-3389-5486 Email: sales@artray.us...
