- Page 1 Jan 27, 2022 Ver0.92 USB2.0 I n G a A s NIR CAMERA ARTCAM-991SWIR-WOM INSTRUCTION BOOKLET ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
Contents Attention ..............................- 3 - Introduction .............................. - 6 - Main Features ............................- 6 - The Product .............................. - 6 - Connect the Camera ..........................- 7 - 5.1. How to Connect a Camera ......................- 7 - Specifications ............................ -
Page 3: Attention
1. Attention ■ About this manual 1．Before using the camera, please read this manual thoroughly. 2．Please keep this manual reachable and always refer to the contents when needed. 3．Please contact us if the manual is lost or damaged. We will provide a replacement. 4．We cannot guarantee the safety of improper uses of the camera. - Page 4 ■ For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・...
- Page 5 For more details, please refer to the sites below: Hardware Warranty: http: //www.artray.us/download/artray_warranty.pdf ■ Dispose To dispose this product, please return the camera to us. If you decide to dispose the camera without returning it us, please follow related regulations and have the camera disposed as an industrial waste.
-
Page 6: Introduction
The InGaAs sensor can detect radiation invisible to human eyes and CCD/CMOS cameras in the wavelength range between 400 nm to 1700 nm bond. ●High Resolution, High Frame Rate ARTCAM-991SWIR-WOM uses a higher resolution sensor of 640 x 512 pixel and delivers image at 131 fps. ●USB2.0 Interface This camera adopts USB2.0 interface, so the data can be delivered to PC directly. -
Page 7: Connect The Camera
5. Connect the Camera 5.1. How to Connect a Camera Please connect the camera and the PC by using the attached USB2.0 cable. Camera’s power is supplied from USB Bus Power. - 7 -... -
Page 8: Specifications
6. Specifications 6.1. Specification MODEL ARTCAM-991SWIR-WOM Sensor Type VGA I n G a A s Image Sensor Sensor Model SONY IMX991-AABJ-C Actual Pixel Array 656(W) x 520(H) Effective Pixel Array 640(W) x 512(H) Pixel Pitch 5[μm] × 5[μm] 3.2[mm] x 2.56[mm] Image Size (Diagonal length: 4.1[mm], 1/4”) -
Page 9: Analog / Digital Gain Settings
6.1.1. Analog / Digital Gain Settings ARTCAM-991SWIR-WOM is compatible with analog and digital gain. Setting value of gain on software can be set from 0 ~ 420, and the gain will change from 0.0dB ~ 42.0dB accordingly. G a i n can be calculated by the following formula: G a i n[dB] = value / 10.0[dB]... -
Page 10: Dimensional Outline
6.1.2. Dimensional Outline Drawing of the base without a tripod mount ※The dimension might be changed. 6.1.3. Sensor Package Information - 10 -... -
Page 11: Sensor Position And The Light Receiving Surface
Sensor Position and the Light Receiving Surface 6.1.4. H = 5[um] * 640 = 3200 [um] V = 5[um] * 512 = 2560 [um] 6.1.5. Field of Vision: Lens versus Sensor（For Reference Only） ※ The ratios of sensor size (diagonal) to lens size in the above illustrations are as follows: 1/2 inch = φ8mm, 2/3 inch = φ11mm, 1 inch = 15.8mm. -
Page 12: Spectral Sensitivity Characteristics
6.2. Spectral Sensitivity Characteristics - 12 -... -
Page 13: System Requirements
What may cause the problem is that the regulation of the power lines becomes not enough, and so causes impudence mismatch on data signals. *For the recommended extension cable, please contact our sales department. (TEL: +81-3389-5488) ARTRAY Co., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan TEL: +81-3-3389-5488 FAX: +81-3-3389-5486 Email: sales@artray.us...
