- Page 1 September 20, 2024 Ver1.00 USB3.0 I n G a A s NIR CAMERA ARTCAM-992SWIR INSTRUCTION BOOKLET ARTRAY CO., LTD. - 1 -...
- Page 2 Contents Attention ............................... - 3 - Introduction............................- 6 - Main Features ............................- 6 - The Product ............................- 6 - Connect the Camera ..........................- 7 - 5.1. How to Connect a Camera ......................- 7 - Specifications ............................- 8 - 6.1.
- Page 3 1. Attention ■ About this manual 1．Before using the camera, please read this manual thoroughly. 2．Please keep this manual reachable and always refer to the contents when needed. 3．Please contact us if the manual is lost or damaged. We will provide a replacement. 4．We cannot guarantee the safety of improper uses of the camera.
- Page 4 ■ For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・...
- Page 5 For more details, please refer to the sites below: Hardware Warranty: http://www.artray.us/download/artray_warranty.pdf ■ Dispose To dispose this product, please return the camera to us. If you decide to dispose the camera without returning it us, please follow related regulations and have the camera disposed as an industrial waste.
- Page 6 The InGaAs sensor can detect radiation invisible to human eyes and CCD/CMOS cameras in the wavelength range between 400 nm to 1700 nm bond. ●High Resolution ARTCAM-992SWIR uses a high resolution sensor of 2560 x 2048 pixels and delivers images at up to 67 fps. ●USB3.0 Interface This camera adopts USB3.0 interface, so the data can be delivered to PC directly.
- Page 7 5. Connect the Camera 5.1. How to Connect a Camera - 7 -...
- Page 8 6. Specifications 6.1. Specification MODEL ARTCAM-992SWIR Sensor Type 5.24MP I n G a A s Image Sensor Sensor Model SONY IMX992-AABJ-C Actual Pixel Array 2592(W)×2056(H) Effective Pixel Array 2560(W)×2048(H) Pixel Pitch 3.45[μm]×3.45[μm] Image Size 8.8[mm]×7.1[mm] Spectral Range 400nm~1700nm Shutter type...
- Page 9 6.1.1. Analog / Digital Gain Settings ARTCAM-992SWIR-TEC is compatible with analog and digital gain. Setting value of gain on software can be set from 0 ~ 420, and the gain will change from 0.0dB ~ 42.0dB accordingly. G a i n can be calculated by the following formula: G a i n[dB] = value / 10.0[dB]...
- Page 10 6.1.2. Dimensional Outline Standard specifications Drawing of the base without a tripod mount External trigger specification (optional) ※The dimension might be changed. - 10 -...
- Page 11 External Trigger with FAN specification (optional) ※The dimension might be changed. - 11 -...
- Page 12 6.1.3. Sensor Package Information - 12 -...
- Page 13 6.1.4. Sensor Position and the Light Receiving Surface H = 3.45[um] * 2560 = 8832 [um] V = 3.45[um] * 2048 = 7065.6 [um] 6.1.5. Field of Vision: Lens versus Sensor（For Reference Only） ※ The ratios of sensor size (diagonal) to lens size in the above illustrations are as follows: 1/2 inch = φ8mm, 2/3 inch = φ11mm, 1 inch = 15.8mm.
- Page 14 6.2. Spectral Sensitivity Characteristics 6.3. External Trigger Function (Optional) This camera has an external trigger electronic circuit, which is insulated by a photocoupler, and thus enables synchronized shooting by the input signal received from the external circuit. SMA female connector ※Conversion connector: SMA male-BNC female is included - 14 -...
- Page 15 6.4. Trigger Timing (Optional) 6.4.1. ITR Mode items Required time Effective trigger input pulse >10μsec. From the rise of the external trigger input to the fall of the trigger signal passed to the sensor <1μsec. (Delay due to the photocoupler) From the fall of the trigger signal passed to the Max 0.13μs sensor to the start of exposure...
- Page 16 6.4.2. IWR Mode - 16 -...
- Page 17 Item Required time Trigger input pulse (Positive logic) >1msec. Approx. 6.8μsec (Delay due to the photocoupler and actual measured delay due to chattering elimination process Delay until internal trigger signal is in FPGA） issued ※Delay due to the photocoupler depends on the voltage of input trigger as well Max.
- Page 18 What may cause the problem is that the regulation of the power lines becomes not enough, and so causes impudence mismatch on data signals. *For the recommended extension cable, please contact our sales department. (TEL: +81-3389-5488) ARTRAY Co., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan TEL: +81-3-3389-5488 FAX: +81-3-3389-5486 Email: sales@artray.us...
