- Page 1 2020UV-CL Camera Link Setting Manual 書 ARTCAM-2020UV-CL Camera Link Settings Manual rev.1.05 Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd...
-
Page 2: Table Of Contents
Commands Details ........................7 5.5.1. Shutter ..........................7 Settings............................8 6.1. Preparation ..........................8 6.2. Connect to Camera ........................8 6.3. Example of Serial Communication Software Settings..............9 6.4. Example of Viewer Software Settings ..................11 Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 3: Introduction
While using other devices, users could adapt settings correspondent to the devices. Table 2-2: Device and System recommended Item Recommendation Camera Link Frame Grabber Board PIXCI®EB1 (Manufactured by EPIX) Viewer Software XCAP for Windows Lite Serial Communication Software Tera Term Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 4: Camera Link Format
4. Connector Pin Assignment The connector pin assignment is as follows: Table 4-1: Connector Pin Assignment Pin No. Signal Name Pin No. Signal Name XCK- XCK+ CC0- CC0+ CC1+ CC1- CC2- CC2+ CC3+ CC3- Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 5: Communication Specifications
NG. It doesn’t matter the letters of command is in upper case or lower case. Option is omissible. (In this case, a default option will be chosen automatically.) Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 6: List Of Commands
The commands listed below shows controllable functions. For more details of each commands, please refer to “5.5 Commands Details” Table 5-3: List of Commands Function -opt Description Shutter Shutter speed settings (Option is omissible) Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 7: Commands Details
6: Line feed code Response Normal: OK⏎ Abnormal: NG⏎ Note To set the shutter speed in trigger and preview modes. ※To calculate the shutter speed, please refer to the instruction of the camera. Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 8: Settings
Please connect camera to the Camera Link frame grabber board with Camera Link cable. Before connect AC adapter to the camera, please start up the serial communication software. Command will be sent from the camera once it is connected to the power. Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 9: Example Of Serial Communication Software Settings
Please click “Setup” on menu bar, then choose “Serial Port” for communication method settings. Please refer to Table 5-1 Communication Method for details of the settings. Figure 6-4: To Set up Serial Port on Tera Term Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... - Page 10 “OK” on the dialog box. Then you can send command to control camera. Please note that camera will start up only when you send out the command. Figure 6-6: Initialization Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd...
-
Page 11: Example Of Viewer Software Settings
Figure 6-8: Welcome message Please click “PIXCI®” from XCAP menu, then choose “PIXCI®Open/Close” to open the dialog box. Please click “Open” to start the camera. Figure 6-9: To Open Camera Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd... - Page 12 Please refer to Table 3-1 to confirm the Camera Link format. Figure 6-10: Configure Settings Second, please set the resolution. Please refer to Table 3-2 to confirm the resolution of each model. Figure 6-11: Resolution Settings Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd...
- Page 13 The settings are finished now. The image will be displayed either by clicking “Live” in “Capture” on the sub-window, or simply by clicking “Live Icon” on the left side of the sub-window. Figure 6-13: Live Icon Rev.1.05 © 2004 – 2021 ARTRAY Co., Ltd...
