POWER VISION 4

Installation Guide for: PV4-15-01, PV4-15-02,

and PV4-15-03

Model Coverage:

2014-2020 Harley-Davidson Touring Models

2011-2020 Harley-Davidson Softail Models

2012-2017 Harley-Davidson Dyna Models

2014-2022 Harley-Davidson Sportster Models

2015-2021 Harley-Davidson Street Models

2017-2023 Harley-Davidson Touring Models

2018-2023 Harley-Davidson Softail Models

PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

98200143.04

Need help?

Do you have a question about the POWER VISION 4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dynojet POWER VISION 4

Page 1 POWER VISION 4 Installation Guide for: PV4-15-01, PV4-15-02, and PV4-15-03 Model Coverage: 2014-2020 Harley-Davidson Touring Models 2011-2020 Harley-Davidson Softail Models 2012-2017 Harley-Davidson Dyna Models 2014-2022 Harley-Davidson Sportster Models 2015-2021 Harley-Davidson Street Models 2017-2023 Harley-Davidson Touring Models 2018-2023 Harley-Davidson Softail Models PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION 98200143.04...
Page 2 Thank you for purchasing the Power Vision 4 (PV4) from Dynojet Research. The Power Vision 4 is the most ﬂ exible and powerful ﬂ ash tuner in the world. The Power Vision 4 uses reﬂ ash technology to change the parameters inside the stock Engine Control Module (ECM) that affects the way the engine will run.
Page 3 LOCATING THE DIAGNOSTIC CONNECTOR 2015-2021 Street 500 and 750 Models 2002-2007 Touring Models 2008-2020 Touring Models The diagnostic connector is located under The diagnostic connector is located under The diagnostic connector is located under the right hand side electrical cover. This the right hand side electrical cover.
Page 4 GETTING STARTED Download and install the Dynojet Power Vision 4 app from the Apple App or Google Play Store. Verify Bluetooth and Location are enabled. Location permission is required for the app to access the phone’s Bluetooth hardware. Log in...
Page 5 Swipe left to delete Press Yes to use the included Tune License to lock the Power Vision 4 to this vehicle and ﬂ ash the tune. Do not turn off the key switch or disconnect the Power Filter Vision 4 during the ﬂ ash.
Page 6 When you are Select your vehicle ﬁ nished editing, save the tune to the Cloud and use the Dynojet Power Vision 4 App to ﬂ ash your tune to the vehicle. Open the Dynojet Power Core software. Open C3 Tuning.
Page 7 View available tokens, redeem and purchase tokens for tune licenses, and download a license to store on your Available tokens phone for use off line. Your Power Vision 4 comes with one Purchase tokens available Tune License. Tune Licenses are transferable.
Page 8 VIEWING LIVE GAUGES Your Power Vision 4 allows you to conﬁ gure digital and circular gauges for real time monitoring. The Power Vision Press Record to must be connected to the vehicle to view live gauges. record gauges Connect the Power Vision 4 to the vehicle diagnostic port.
Page 9 VIEWING LIVE GAUGES CONTINUED Add a graph gauge. • Press the Data drop-down Press Edit to arrow to view a list of the Press the make gauge ﬁ eld to view available options for that ﬁ eld. changes available • Press the Gauge Type drop- Graph gauge options added...
Page 10 Color Range slider bar Precision use your ﬁ nger drop-down to slide the bar options from each end 10 POWER VISION 4 INSTALLATION AND USER GUIDE...
Page 11 LOGGING DATA The Power Vision 4 allows you to log data and view the log using Power Core Software. Press Lap to save the current log Press Datalog. and start a new log Press Start to begin logging data. Press Lap to save the current log and start a new log.
Page 12 Copy the device Note: For more information on the Disconnect button, info Update refer to Disconnecting from the Power Vision 4 on ﬁ rmware type page 14. Press Menu and press Device Info. Press Copy device information to save a copy of the device information to your clipboard.
Page 13 DISCONNECTING FROM THE POWER VISION 4 Manually disconnect from your Power Vision 4 and connect to another device. Press Press Menu and press Device Info. Device Info Press Disconnect. Disconnect from Power Vision 4 REPORT A PROBLEM Have questions or need additional support? Email Dynojet’s state of the art technical support team.
Page 14 Dynojet.com account using the same Have your phone “forget” the Power Vision 4. account you used to log in to the Power Vision 4 app. Clear the Bluetooth cache. Click My Account in the top, right corner of the browser.
