2002 GSX1300R Hayabusa
PCIII/PCIIIr
P a r t s L i s t
1
Power Commander
1
CD-ROM
1
Installation Guide
312-210
152-23000
I312-211
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dynojet Power Commander 3r
Summary of Contents for Dynojet Power Commander 3r
- Page 1 If you do not have a CD-Rom drive and would like to receive the program and the alternate maps for your model on a 3 1/2” floppy disc, please fax this form to Dynojet at 1-702-399-1431 or call 1-800-992-4993 Bike Model...
- Page 2 This page intentionally left blank Installation Instructions for 2002 GSX1300R Hayabusa These instructions cover the installation for the PCIII and the PCIIIr with ignition. The ignition MUST be turned off before installation!! PLEASE READ ALL THE DIRECTIONS BEFORE STARTING INSTALLATION 1 Remove the main seat and the passenger seat.
- Page 3 Plug the connectors from the PCIII in-line of the stock This page intentionally left blank wiring harness (Fig. B). Fig.B Stock connectors PCIII connectors View from L.H side Route the PCIII wiring along the inside of the frame towards the battery. Attach the ground wire from the PCIII to the negative side of the battery (Fig.
- Page 4 Install the PCIII in the rear section of the trunk using This page intentionally left blank the supplied velcro (Fig. D). Make sure to clean both surfaces with alcohol first. Fig. D NOTE: FOR PCIIIr ONLY. If you are installing the PCIIIr with ignition adjustment locate the black connector from the generator cover (Fig.
-
Page 5: Trouble Shooting
Trouble Shooting Fig.E If you feel that you are having any problems at all with the Power Unplug the black Commander III, disconnect it from your motorcycle. This will allow connector with the the motorcycle to run directly off of the stock ECU. blue and green wires The lights don’t come on when I turn the ignition switch on. - Page 6 If you do not have the Power Adaptor follow the instructions 10 Make sure all the wires are routed properly. below. 11 Bolt down the fuel tank. 1. Switch the emergency kill switch to the run position. NOTE: When lowering the fuel tank make sure the fuel 2.
