INSTALLATION MANUAL
Level of Difficulty
Easy
This is the second of two manuals
required to complete this installation. The
first manual is included with your center
section. If installing a brush guard, there
will be a third manual required.
Parts List
1
Driver / left corner
1
Passenger / right corner
8
Socket cap screw, M6
8
Flat washer, M6
8
Nylock nut, M6
6
Hex bolt, M10
12
Flat washer, M10
6
Lock washer, M10
6
Nut, M10
2
LED work light (#1501250)
1
Rubber gasket
Tools Required
Ratchet
Phillips screwdriver
Socket extension
Flathead screwdriver
Socket set
Allen wrench set
Level
Box wrench set
Torque Specifications
M6 bolt
7 ft-lbs.
M8 bolt
16 ft-lbs.
M10 bolt
33 ft-lbs.
M12 bolt
58 ft-lbs.
Use above torque setting unless otherwise noted
Product Photo
Applicable to the Following Part Numbers
2081205
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Mild automotive detergent may be used to clean the product. Do not use dish detergent, abrasive
cleaners, abrasive pads, wire brushes or other similar products that may damage the finish.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
Product Registration
CURT Group stands behind our products with industry leading warranties.
At CURT Group, customer is king. We value your feedback and we use that information to make
improvements on our products. Please, take a minute and let us know how we are doing.
CORNER
WITH LEDS
2081200

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2081205 and is the answer not in the manual?

Questions and answers

Related Manuals for Aries 2081205

Summary of Contents for Aries 2081205

  • Page 1 Parts List Driver / left corner Passenger / right corner Applicable to the Following Part Numbers Socket cap screw, M6 2081205 2081200 Flat washer, M6 Nylock nut, M6 Notes and Maintenance Hex bolt, M10 Flat washer, M10 Before you begin installation, read all instructions thoroughly.
  • Page 2 Step 1 Set the corners onto a flat work surface. Insert the rubber gasket and LED light into place as shown. Secure the four LED light attachment points with an M6 socket cap screw, flat washer and nylock nut at each point. Tighten all hardware and repeat for the second corner and light.
  • Page 3 ROUND INSTALLATION MANUAL BRUSH GUARD Level of Difficulty Product Photo Easy This is the third of three manuals required to complete this installation. The first manual is included with your center section. The second manual is included with your bumper corners. Parts List Round brush guard Hex bolt, M10...

  • Page 4: Center Section

    INSTALLATION MANUAL CENTER SECTION Level of Difficulty Product Photo (center section only) Moderate This is the first of two manuals required to complete this installation. The second manual is included with your bumper corners. If installing a brush guard, there will be a third manual required.
  • Page 5 Step 1 Remove the front fascia by removing the eight plastic push fasteners from the upper edge of the lower front fascia. Using a socket, remove the two 5mm screws securing the lower edge of the plastic fascia. Step 2 From behind the factory bumper on the passenger side, disconnect the fog light wiring harness.
  • Page 6 Step 5 On the driver side, remove the plastic cover over the factory fog light. Remove the fog light and plastic housing from the factory bumper. Disconnect the wiring harness from the fog light. Remove the factory fog light from the plastic housing. Repeat this step on the passenger side.
  • Page 7 Step 6 Remove the fog light wiring harness from the factory bumper. Begin by removing the retainer clips from the eight bumper mounting studs. Remove the four bolts securing the beam to the bumper. Lift the beam from the bumper, exposing the fog light harness.
  • Page 8 Note: If installing a bumper with corners that include turn signals, refer to step 12 on the installation included with your bumper corners. Congratulations on the installation of your new ARIES TrailChaser bumper. ™ With the bumper installed, periodic inspections should be performed to ensure all mounting hardware remains tight.
