Akuvox R20A Quick Manual

1. On-wall installa�on
Without embedded box on the wall
With embedded box on the wall
Rain Cover Quick Guide
Use four ST�x�� crosshead screws to secure the
rain cover and wall-mounting bracket to the
wall in sequence.
Use two ST�x�� crosshead screws and two
M�x�� crosshead screws to secure the rain
cover and wall-mounting bracket to the wall
in sequence.
a. After completing the wiring and installing
the accessories on the back of the device
according to the R��A Quick Guide, insert the
four wall-mounting screws on the device into
the corresponding holes on the wall-mount-
ing bracket.
b. Press down to slide the wall-mounting
screws into the groove.
c. Use Allen wrench to tighten the device
with two M�x� hex socket screws.
Installation is done.
R20A
