(GMP Version)
IMPORTANT
NOTE: Some portions of assembly may require additional assistance.
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DINO STORM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UNIS DINO STORM

Summary of Contents for UNIS DINO STORM

  • Page 1 (GMP Version) IMPORTANT NOTE: Some portions of assembly may require additional assistance. Operation Manual...
  • Page 2 Dino Storm GMP Manual WE ARE HERE TO ASSIST For parts and service Have Questions? Contact us! UNIS SERVICE CENTER Tel: 972-241-4263 Email: service@unispartsandservice.com www.unispartsandservice.com When contacting Service, you will need the following information and the name of your authorized distributor.

  • Page 3: Table Of Contents

    Dino Storm GMP Manual CONTENT IMPORTANT SAFETY INSTRUCTIONS ................ 3 1. SPECIFICATIONS ...................... 5 2. CONTENTS OF THE ACCESSORY KIT ..............6 3. PART NAME ......................7 4. SET UP & INSTALLATION ..................8 5. HOW TO PLAY ......................13 6. GAME OPTION ......................18 7.

  • Page 4: Important Safety Instructions

    Dino Storm GMP Manual Thank you for purchasing Dino Storm GMP. We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. It is intended for the owner and/or personnel in charge of product operation.
  • Page 5 Dino Storm GMP Manual Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage. This product is an indoor game machine. Do not install outdoors. Avoid installing in the following places to prevent fire, electric shock, injury and/or machine malfunctioning: ...

  • Page 6: Specifications

    Dino Storm GMP Manual 1. SPECIFICATIONS Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz; Min. Power consumption: 450W Max. Power consumption: 1800W Dimension: H87.93×W46.47×D90.73 in H2233.6×W1180.4 ×D2304.6 mm Model No: C-825 Part No.: D182 NOTICE : After turning off the game, please wait at least 1 minute before restarting again.

  • Page 7: Contents Of The Accessory Kit

    Dino Storm GMP Manual 2. CONTENTS OF THE ACCESSORY KIT Open the package and make sure all the items are included: 1. Following accessories Part No. Code No. Name Picture D182-0601-00 2.53.00171002 171A key D182-0602-00 2.53.00172002 171B key Power cord D182-0603-00 2.33.01.070001...

  • Page 8: Part Name

    Dino Storm GMP Manual 3. PART NAME Key Components Marquee Assembly Display Coin Mechanism dispenser Seat Feet pedal Motion platform 24/12/2024...

  • Page 9: Set Up & Installation

    Dino Storm GMP Manual 4. SET UP & INSTALLATION NOTICE We do not recommend using power tools as they may cause damage. This product is an indoor game machine. Do not install outdoors.  Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
  • Page 10 Dino Storm GMP Manual 4.3 Play Zone This machine requires space for playing and for maintenance as shown below. Leave space around the game upon installation: Service area: 20 in Service area Play area NOTICE Your unit must be leveled to operate properly.

  • Page 11: Machine Installation

    Dino Storm GMP Manual 4.4 Machine Installation Step 1 Lift the Marquee up. Utilize screws to secure. Marquee assembly Marquee assembly Step 2 Locate wiring box. Loosen screws to remove cover plate. Align wiring box to the monitor cabinet. Lead the Monitor connector and air pipe to the wiring box and connect.
  • Page 12 Dino Storm GMP Manual Step 3 Align Seat assy with the Wiring box. Lead the Seat assy. connectors and air pipe to the wiring box and connect. Utilize screws to secure Wiring box and monitor cabinet. Secure cover plate back.
  • Page 13 Dino Storm GMP Manual 4.5 Card Reader Installation Safety Notice Take precaution to assure that all wiring voltages are confirmed prior to installation of card reader. All warranties are void if not properly installed resulting in logic board damage. Important: This game is pre-wired to AAMA standards. It is highly recommended to utilize this wiring for Card reader installation.

  • Page 14: How To Play

    Dino Storm GMP Manual 5. HOW TO PLAY 5.1 Insert coins/tap/swipe card to play. 5.2 Select Game motion. 5.3 Select Character. 24/12/2024...
  • Page 15 Dino Storm GMP Manual 5.4 Select map. 5.5 Game start. Move the left oar to turn right. Move the right oar to turn left. Move both oars to accelerate. 5.6 Picking up gems on the surface of the water will earn you a certain number of points and a brief acceleration.
  • Page 16 Dino Storm GMP Manual 5.7 When you hit a dinosaur or hit a mechanism, the kayak will be knocked away or stunned and slowed down. Hitting other players also slows down. 5.8 If you come across a stream of water spewed out by a large triceratops, you will be briefly obscured from view.
  • Page 17 Dino Storm GMP Manual 5.9 Ride a rocket, shark or pterodactyl for a period of time by hitting the acceleration props on the water. 5.10 The kayak hits a rising jet of water and gets swept up into the air.
  • Page 18 Dino Storm GMP Manual 5.11 Catch by the octopuses. Step on the pedal quickly to break free. 5.12 Entering a large eddy area, kayak speeds will be greatly reduced, Row the oars quickly to escape the eddy. 5.13 Ranking list will shows after game finish.

  • Page 19: Game Option

    Dino Storm GMP Manual 6. GAME OPTION 6.1 Adjustment button instruction Open the coin door and there is a meter panel. Press Settings button to enter into the setting menu. Settings Test Reset 6.2 Setting menu 6.2.1 Main menu Options...
  • Page 20 Dino Storm GMP Manual 6.2.2.1 Input Test Options Current Status Coin OFF_ON Stop button OFF_ON Pedal switch 1 OFF_ON Pedal switch 2 OFF_ON Pedal switch 3 OFF_ON Pedal switch 4 OFF_ON Floor switch 1 OFF_ON Floor switch 2 OFF_ON Floor switch 3...
  • Page 21 Dino Storm GMP Manual 6.2.2.4 Air Spring Test Options LF leaning RF leaning LB leaning RB leaning Back 6.2.3 Basic Setting Options Adjustment Value Freeplay mode ON / OFF Insert Coin Only/ Tap Card Only/ Insert Card Only/ Insert Bills Only/...
  • Page 22 Dino Storm GMP Manual 6.2.4 Ticket Settings Options Adjustment Value Ticket Out ON/ OFF Ticket Owed mode Store ticket in memory/ Call Attendant Fixed tickets 1-999/ OFF Half ticket ON/ OFF Tickets for first place 0-999 Tickets for second place...
  • Page 23 Dino Storm GMP Manual 6.2.7 Revenue Record Options Monthly Revenue Annual Revenue Total Revenue Back 6.2.7.1 Monthly Revenue Date Coins Test coins Game plays Tickets Boot time Game time Back 6.2.7.2 Annual Revenue Month Coins Test coins Game plays Tickets Boot time Game time Back 6.2.7.3 Total Revenue...

  • Page 24: Troubleshootings

    Dino Storm GMP Manual 7. TROUBLESHOOTINGS 7.1 Common Problem Please confirm that all connectors fit tightly. Symptom Possible Cause Recommended action Frame assembly connector is Game will not Check connector. loose. start Frame assembly fault Contact with UNIS Service. Turn on power SW again. If appeared...
  • Page 25 Dino Storm GMP Manual If you see following error signs showing on the display, please try the recommended action. Display Possible Cause Recommended action Encryption device connection failed Encryption device Please call the service connection failed department for assistance. Loose connection of the...
  • Page 26 Dino Storm GMP Manual 7.2 System Recovery Operation (NOTE: Do not disconnect power during this process.) 1. Turn off the game. Remove recovery stick from the machine. (Note: This process may take up to 60 minutes) Insert the recovery stick into the port at the back of the computer.

  • Page 27: Maintenance & Inspection

    Dino Storm GMP Manual 8. MAINTENANCE & INSPECTION 8.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Test game before operation each day. 2. Conduct monthly routine checks of game components to ensure good working condition.

  • Page 28: Overall Construction

    Dino Storm GMP Manual 9.OVERALL CONSTRUCTION 9.1 General Assembly Part No. Code No. Name Version Qty D182-0001-00 202.4.2428.046 Platform connect plate 2 V1.1 D182-0003-00 202.4.2428.048 Platform connect plate 1 V1.1 D182-0002-00 202.4.2428.047 Front&Rear connect plate 1 V1.1 D182-0004-00 202.4.2428.049 Front&Rear connect plate 2 V1.1...
  • Page 29 Dino Storm GMP Manual 9.2 Monitor Assembly Part No. Code No. Name Version Qty D182-0157-00 202.4.2428.069 Monitor frame bracket V1.1 D182-0158-00 202.4.2428.070 Monitor fixing plate V1.1 D182-0159-00 202.4.2428.071 Monitor plate V1.1 D182-0160-00 206.4.2428.045 Monitor glass V1.1 D182-0161-00 202.4.2428.101 Monitor side fixing plate V1.1...
  • Page 30 Dino Storm GMP Manual 9.3 Air Compressor Assembly Part No. Code No. Name Version Qty D182-0140-00 203.4.2428.023 Air compressor base board V1.1 D182-0141-00 202.4.2429.008 Air compressor bracket V1.1 D182-0142-00 202.4.2429.009 Air compressor fixing plate 2 V1.1 D182-0143-00 202.4.2429.010 Air compressor fixing plate 1 V1.1...
  • Page 31 Dino Storm GMP Manual 9.4 Monitor Cabinet 24/12/2024...
  • Page 32 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0153-00 202.4.2428.061 Water storage box V1.1 D182-0155-00 206.4.2428.023 Foam V1.1 D182-0154-00 202.4.2428.062 Water storage plate V1.1 D182-0164-00 202.4.2428.055 Monitor back cover plate V1.1 D182-0165-00 202.4.2428.056 PC bracket V1.1 D182-0166-00 202.4.2428.057...
  • Page 33 Dino Storm GMP Manual 9.5 Monitor Cabinet Wooden Case 24/12/2024...
  • Page 34 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0102-00 203.4.2428.002 Side board V1.1 D182-0103-00 203.4.2428.003 Back door board V1.1 D182-0104-00 203.4.2428.004 L side board V1.1 D182-0105-00 203.4.2428.005 Power board V1.1 D182-0106-00 203.4.2428.006 Base bottom board V1.1 D182-0107-00 203.4.2428.007 Front bottom board V1.1...
  • Page 35 Dino Storm GMP Manual 9.6 Motion Platform 24/12/2024...
  • Page 36 Dino Storm GMP Manual Part No. Code No. Name Version Qty 1 D182-0301-00 299.4.2428.001 Base bracket V1.1 2 D182-0302-00 202.4.2428.015 Upper bracket V1.1 3 D182-0303-00 202.4.2428.108 Air spring pad plate V1.1 4 D182-0304-00 202.4.2428.014 Oar tube bracket V1.1 5 D182-0335-00 203.4.2428.034 Platform board V1.1...
  • Page 37 Dino Storm GMP Manual 9.7 Seat Assembly Part No. Code No. Name Version Qty D182-0342-00 206.4.2428.015 Seat rotomoulding V1.1 D182-0343-00 202.4.2428.032 Seat support bracket V1.1 D182-0344-00 202.4.2428.033 Seat strengthen plate 1 V1.1 D182-0345-00 202.4.2428.034 Seat strengthen plate 2 V1.1 D182-0346-00 202.4.2428.035 Seat base plate V1.1...
  • Page 38 Dino Storm GMP Manual 9.8 Foot Pedal Assembly Part No. Code No. Name Version Qty D182-0352-00 202.4.2428.084 Foot pedal bracket V1.1 D182-0353-00 202.4.2428.085 Foot pedal cover plate V1.1 D182-0354-00 202.4.2428.086 Sensor fixing plate V1.1 D182-0355-00 202.4.2428.013 Spring V1.1 D182-0356-00 202.4.2428.087 Foot pedal base plate V1.1...
  • Page 39 Dino Storm GMP Manual 9.9 Marquee Part No. Code No. Name Version Qty D182-0501-00 203.4.2428.036 Marquee base board V1.1 D182-0502-00 202.4.2428.093 Marquee fixing plate 1 V1.1 D182-0503-00 202.4.2428.092 Marquee fixing plate 2 V1.1 D182-0505-00 206.4.2428.033 LOGO marquee V1.1 9.10 Coin Frame Part No.
  • Page 40 Dino Storm GMP Manual 9.11 Air Jet Part No. Code No. Name Version Qty D182-0177-00 202.4.2428.078 Air jet bracket V1.1 D182-0178-00 202.4.2428.079 Air jet blank plate V1.1 D182-0179-00 202.4.2428.080 Air jet cover plate V1.1 D182-0180-00 202.4.2428.096 Air jet plate V1.1 D182-0181-00 2.51.01.19.0011...
  • Page 41 Dino Storm GMP Manual 9.13 Boat Header Assembly Part No. Code No. Name Version Qty D182-0135-00 206.4.2428.006 Boat header rotomoulding V1.1 D182-0136-00 202.4.2428.018 Boat light pressing plate V1.1 D182-0137-00 206.4.2407.017 Speaker light plastic V1.1 D182-0138-00 202.4.2407.046 Speaker cover plate V1.1 9.14 Boat Tail Assembly...
  • Page 42 Dino Storm GMP Manual 9.15 Solenoid Assembly Part No. Code No. Name Version Qty D182-0401-00 202.4.2428.066 Solenoid bracket V1.1 D182-0402-00 202.4.2428.067 Solenoid bracket cover plate V1.1 D182-0403-00 202.4.2428.068 Solenoid mounting plate V1.1 D182-0404-00 2.51.01.12.0040 Solenoid V1.1 D182-0377-00 2.51.01.11.0130 10mm pipe(1/4'') V1.1...
  • Page 43 Dino Storm GMP Manual 9.16 Oar Assembly 24/12/2024...
  • Page 44 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0311-00 202.4.2428.041 Rotation bracket V1.1 D182-0312-00 202.4.2428.040 Rotation base bracket V1.1 D182-0314-00 206.4.2428.001 Buffer rubber V1.1 D182-0313-00 202.4.2428.042 Oar turning wheel plate V1.1 D182-0315-00 202.4.2428.043 Frame cover plate V1.1 D182-0316-00 202.4.2428.008...
  • Page 45 Dino Storm GMP Manual 9.17 Decals 24/12/2024...
  • Page 46 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0842-00 205.4.2428.014 Ticket cover decal D182-0506-00 205.4.2439.016 Oar PVC D182-0826-00 205.4.2428.006 Monitor bottom PVC decal D182-0825-00 205.4.2428.005 Front door PVC D182-0359-00 205.4.2428.001 Foot pedal plastic D182-0831-00 205.4.2428.011 Stop button decal D182-0830-00 205.4.2428.010...
  • Page 47 Dino Storm GMP Manual 24/12/2024...
  • Page 48 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0808-00 2.56.00.000036 High voltage label(s) D182-0834-00 205.4.2428.016 Fuse board instruction decal D182-0809-00 2.56.00.000037 High voltage label(l) D182-0806-00 2.56.00.000093 Dongle decal D182-0807-00 2.66.01.100283 Recovery stick decal D182-0841-00 205.4.2428.012 110V nameplate D182-0823-00 205.4.2017.115...
  • Page 49 Dino Storm GMP Manual 9.13 Electrical Components 24/12/2024...
  • Page 50 Dino Storm GMP Manual Part No. Code No. Name Version 1 D182-0505-00 206.4.2428.033 LOGO marquee 2 D182-0727-00 2.12.01049005G 49'' monitor 59.06 in 3 D182-0722-00 2.20.02.020057 2835 yellow light strip (1500mm) 4 D182-0723-00 2.23.06000022 Coin mechanism D182-0746-00 2.31.00000015 Ticket dispenser D182-0748-00 297.9.0700002...
  • Page 51 Dino Storm GMP Manual Part No. Code No. Name Version 74.8 in 1 D182-0722-00 2.20.02.020057 2835 yellow light strip (1900mm) D182-0728-00 2.26.04.000045 Micro SW(5A) 27.56 in D182-0711-00 2.20.02.015019 BG5050W white light strip (700mm) D182-0720-00 2.25.01000030 D182-0331-00 2.34.13.000002B Magnetic particle brake D182-0735-00 2.24.01.250003...
  • Page 52 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0701-00 297.9.2304001 N6 mainboard D182-0404-00 2.51.01.12.0040 Solenoid D182-0380-00 2.51.06.02.5002 Pipe(Black) D182-0381-00 2.51.06.02.5001 Pipe(Red) D182-0382-00 2.51.06.02.5004 Pipe(Blue) D182-0383-00 2.51.06.02.5005 Pipe(Yellow) D182-0150-00 2.51.06.02.5003 Pipe(clear) 24/12/2024...
  • Page 53 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0710-00 2.16.02.000117 Power supply(12V) V1.1 D182-0745-00 4.13.00000012 Recovery stick V1.1 D182-0702-00 2.17.14.000148D Fuse board V1.1 D182-0732-00 2.28.03.060021 Amplifier V1.1 D182-0725-00 2.33.05.000006 Audio cable V1.1 D182-0701-00 297.9.2304001 N6 mainboard V1.1...
  • Page 54 Dino Storm GMP Manual 24/12/2024...
  • Page 55 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0727-00 2.12.01049005G 49'' monitor D182-0703-00 2.33.01.010055 Power cord V1.1 D182-0724-00 2.33.07.000058 HDMI-DVI cable V1.1 D182-0741-00 2.11.02.000168 PC(220V) V1.1 D182-0750-00 2.11.02.000173 PC(110V) V1.1 D182-0704-00 2.33.03.000002 Serial cable V1.1 D182-0715-00 2.33.02.000014 Network cable V1.1...
  • Page 56 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0210-00 4.06.11.01.0200 Air compressor(110V) V1.1 D182-0146-00 4.06.11.01.0199 Air compressor(220V) V1.1 D182-0751-00 2.16.06.000111 Socket(110V) V1.1 D182-0752-00 2.16.06.000112 Socket box(110V) V1.1 D182-0712-00 2.16.06.040021 Socket(220V) V1.1 D182-0733-00 2.21.4.0000043 Relay V1.1 24/12/2024...
  • Page 57 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0736-00 2.26.01.000007 Door interlock(L) D182-0737-00 2.26.01.000008 Door interlock(R) Part No. Code No. Name Version Qty D182-0738-00 2.24.02.070004 Green button D182-0739-00 2.24.02.070005 Red button V1.1 D182-0740-00 2.24.02.070006 White button V1.1 D182-0716-00 2.30.00000006...
  • Page 58 Dino Storm GMP Manual Part No. Code No. Name Version Qty D182-0709-00 2.26.01.000005 Rocket SW D182-0604-00 2.19.01.000012 Fuse V1.1 D182-0713-00 2.32.01000004 Filter V1.1 D182-0714-00 2.33.02.000001 Network port V1.1 D182-0726-00 2.26.02.000091 Breaker V1.1 D182-0713-00 2.32.01000004 Filter V1.1 www.unistechnology.com 24/12/2024...

  • Page 59: Air Compressor Instruction

    Dino Storm GMP Manual 10. AIR COMPRESSOR INSTRUCTION 10.1.Introduction Our company’s oil free air compressor to use of high-quality, the big flow of oil-free piston compressor swing as a power source, can provide a stable source of oil free gas, avoid the oil patches into the human body, and can avoid terminal machines because of the non-oil pipeline caused a breakdown of oil.
  • Page 60 Dino Storm GMP Manual 10.3 Overall Construction 24/12/2024...
  • Page 61 Dino Storm GMP Manual 1 covery 17 valve 33 stator 49 nut 2 left fan 18 valve 34 bearing 6203-2Z 50 wheel 3 left crankcase 19 valve plate 35 adjustment washer 51 bolt 4 connecting rod 20 washer 36 vibration column...
  • Page 62 Dino Storm GMP Manual compressor. It should be add power stabilizer or booster, to make the use voltage up to standard voltage. 4.6 By using, the air holder of the air compressor will condense a small amount of moisture content, so must be drained regularly, generally drainage once a week. Switch off...
  • Page 63 Dino Storm GMP Manual 10.6 Malfunction Analysis And Preserve Fault characteristic Possible cause Exclude method Plug has no power Open the power. Air compressor can't Check whether the Over-current running electrical connections of the protection or motor have no abuzz...
  • Page 64 Dino Storm GMP Manual Fault characteristic Possible cause Exclude method The air of the Check each joint have compressor and steam leakage the pipeline phenomenon or not. system is (Can use suds to divulged. check.) When the compressor keep Open the cylinder running, but the pressure can’t...
  • Page 65 Dino Storm GMP Manual 10.7 Gas Circuit Elementary Diagram 24/12/2024...
