  • Page 1 IMPORTANT Operation Manual...
  • Page 2 Disc it for Tickets (Twin Version) Manual WE ARE HERE TO ASSIST For parts and service Have Questions? Contact us! UNIS SERVICE CENTER Tel: 972-241-4263 Email: service@unispartsandservice.com When contacting Service, you will need the following information and the name of your authorized distributor.

  • Page 3: Table Of Contents

    Disc it for Tickets (Twin Version) Manual CONTENT IMPORTANT SAFETY INSTRUCTIONS ............... 3 1. SPECIFICATIONS ....................5 2. CONTENTS OF THE ACCESSORY KIT ..............7 3. PART NAME ......................8 4. SET UP & INSTALLATION ..................9 5. HOW TO PLAY ...................... 20 6.

  • Page 4: Important Safety Instructions

    Disc it for Tickets (Twin Version) Manual Thank you for purchasing Disc it for Tickets GMP (Twin Version). We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. It is intended for the owner and/or personnel in charge of product operation.
  • Page 5 Disc it for Tickets (Twin Version) Manual Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage. This product is an indoor game machine. Do not install outdoors. Avoid installing in the following places to prevent fire, electric shock, injury and/or machine malfunctioning: ...

  • Page 6: Specifications

    Disc it for Tickets (Twin Version) Manual 1. SPECIFICATIONS Rated power supply: AC110V 50/60Hz; AC220V 50/60Hz Min. Power consumption: 300W Max. Power consumption: 400W Dimension: W79.4×D102.7×H120.2in W2017 ×D2609 ×H3055 mm Weight：Approximately 1543lb/700kg Model No: C-583 Part No: D162 NOTICE: After turning off the game, please wait at least 1 minute before restarting again.
  • Page 7 Disc it for Tickets (Twin Version) Manual This machine will be divided into two parts during transportation. Control panel: W39.46×D23.74×H45.54 in W1002 ×D603 ×H1157 mm Back cabinet: W39.37×D31.50×H80.00 in W1000 ×D800 ×H2030 mm Note: Game specifications are subject to change without notice. 11/15/2019...

  • Page 8: Contents Of The Accessory Kit

    Disc it for Tickets (Twin Version) Manual 2. CONTENTS OF THE ACCESSORY KIT Open the package and make sure all the items are included: 1. Following accessories Part No. Code No. Name SPEC Picture Qty 1 D162-411-000 41001000012 Red disc 2 D162-412-000 41001000013 Blue disc 3 D162-802-000 25300171002...

  • Page 9: Part Name

    Disc it for Tickets (Twin Version) Manual 3. PART NAME Key Components Marquee Assembly Monitor Disc Exit Ticket Dispenser Coin Mechanism 11/15/2019...

  • Page 10: Set Up & Installation

    Disc it for Tickets (Twin Version) Manual 4. SET UP & INSTALLATION NOTICE We do not recommend using power tools as they may cause damage. This product is an indoor game machine. Do not install outdoors.  Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid. ...
  • Page 11 Disc it for Tickets (Twin Version) Manual 4.3 Play Zone This machine requires space for playing and for maintenance as shown below. Leave space around the game upon installation: Service area: 20 in Service area Play area NOTICE Your unit must be leveled to operate properly. 11/15/2019...
  • Page 12 Disc it for Tickets (Twin Version) Manual Before processing with assembly assure you have the following tools. Name Picture Phillips screwdriver Allen wrench 4.4 Machine Installation Step 1 Turn the Bottom lane assembly down indicated by arrow. Utilize Phillips screwdriver to tighten 8 screw sets to fix Bottom lane assembly to Control panel.
  • Page 13 Disc it for Tickets (Twin Version) Manual Step 2 Utilize Phillips screwdriver to tighten 4 screw sets to fix Bottom lane assembly to Main cabinet. Main cabinet Cross recessed pan Name head screw Spec. M4X12 Step 3 Utilize Phillips screwdriver to loosen screws and turn Upper lane assembly down.Place front side of Upper lane assembly to the slot on the Control panel.
  • Page 14 Disc it for Tickets (Twin Version) Manual Step 4 Place axle on the slot as shown below. Step 5 Utilize Phillips screwdriver to tighten 2 screw sets to fix Upper lane assembly to Main cabinet. Screw hole Cross recessed pan Name head screw set Spec.
  • Page 15 Disc it for Tickets (Twin Version) Manual Step 7 Utilize Phillips screwdriver to tighten 3 screws to fix Side board to Bottom lane assembly. Plug the connector. The same installation on the other side. Side board Cross recessed Name pan head screw Spec.
  • Page 16 Disc it for Tickets (Twin Version) Manual Step 10 Place Front cover on the Upper lane assembly and utilize Phillips screwdriver to tighten 6 screws. Front cover Cross recessed Name pan head screw Spec. M4X12 Step 11 Place Scoreboard decal on the right side of Control panel as shown below, follow Step 12 to place the Control panel plastic to cover it.
  • Page 17 Disc it for Tickets (Twin Version) Manual Step 13 Utilize Phillips screwdriver to tighten 10 screws to fix Net to the Main cabinet. The same installation on the other side. Main cabinet Cross recessed Name pan head screw Spec. M4X12 Step 14 Utilize Phillips screwdriver to tighten 4 screws to Marquee fixing plate to Net.
  • Page 18 Disc it for Tickets (Twin Version) Manual Step 15 Utilize Phillips screwdriver to tighten 2 screws to Top Net to the Main cabinet. Note: Top net hinge side should be placed in top side. Top net Cross recessed pan Name head screw set Spec.
  • Page 19 Disc it for Tickets (Twin Version) Manual 4.5 Machine Connection Step 1 Place Machine connective plate on the back of two machines as shown below. Utilize Phillips screwdriver to tighten 4 screws to fix it. Machine connective plate Cross recessed pan Name head screw set Spec.
  • Page 20 Disc it for Tickets (Twin Version) Manual Step 3 Place Top marquee on the Bottom marquee. Utilize Phillips screwdriver to tighten 4 screws to fix Top marquee to Bottom marquee. Top marquee Cross recessed pan Name head screw set Spec. M6X12 Bottom marquee 11/15/2019...

  • Page 21: How To Play

    Disc it for Tickets (Twin Version) Manual 5. HOW TO PLAY 5.1 Insert coins to play. 5.2 Select mode. 5.3 Throw the disc to hit the score board, sight, diamond, missile to get score. Reach the required score in limited time can enter next round. 5.4 Ranking List shows the player’s ranking, challenge round and score.

  • Page 22: Game Option

    Disc it for Tickets (Twin Version) Manual 6. GAME OPTION 6.1 Adjustment button instruction Open the coin door and there is a meter panel. Press Settings button to enter the setting menu. 6.2 Setting menu 6.2.1 Main menu 6.2.2 Basic Setting Basic Setting Free Play OFF/ON...
  • Page 23 Disc it for Tickets (Twin Version) Manual 6.2.4 Input Test 1P Coin OFF_ON Back 6.2.5 Output Test Control Panel Red Light Screen Red Light Control Panel Green Light Screen Green Light Control Panel Blue Light Screen Blue Light Out of Ticket Light Left Side Red Light Coin Counter Drive Left Side Green Light...
  • Page 24 Disc it for Tickets (Twin Version) Manual 6.2.9 Daily Record Date Weekday Run Time Coins Payout Tickets Pay out Clear Back 6.2.10 About This Game Press the Test Button to Go Back Main board Monitor Monitor Resolution Version 11/15/2019...

  • Page 25: Troubleshooting

    Contact with UNIS Service. Turn on power SW again. If appeared Circuit protector make power SW again and again, machine has Power off in off state. anomaly. Please contact with UNIS Service. The connector is loose. Check connector. Card reader not working Card reader fault.
  • Page 26 Disc it for Tickets (Twin Version) Manual If you see following error signs showing on the display, please try the recommended action. Display Possible Cause Recommended action Check and reconnect the The connection part of the loose ports of the PC or IO IO board and PC are loose.
  • Page 27 Disc it for Tickets (Twin Version) Manual 7.2 System Recovery Operation (NOTE: Do not disconnect power during this process.) 1. Turn off the game. Remove the recovery stick from the machine. (Note: This process may take up to 60 minutes) Insert the recovery stick into the port at the back of the computer.

  • Page 28: Maintenance & Inspection

    Disc it for Tickets (Twin Version) Manual 8. MAINTENANCE & INSPECTION 8.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Test game before operation each day. 2. Conduct monthly routine checks of game components to ensure good working condition.

  • Page 29: Overall Construction

    Disc it for Tickets (Twin Version) Manual 8.3 Convey Assembly Disassembly Instruction Before processing with assembly assure you have the following tools. Name Picture Phillips screwdriver Step 1 Power off the machine. Utilize Phillips screwdriver to loosen 8 screws, washers and screw holders to remove Control panel plastic and Scoreboard decal as rectangle indicated.
  • Page 30 Disc it for Tickets (Twin Version) Manual Step 4 Open the Back bottom door. Loosen 2 screws to remove Convey assembly. Convey assembly Screw 8.4 Convey Belt Adjustment Instruction Before processing with assembly assure you have the following tools. Name Picture Phillips screwdriver Spanner...
  • Page 31 Disc it for Tickets (Twin Version) Manual 8.5 Belt Adjustment Instruction Before processing with assembly assure you have the following tools. Name Picture Phillips screwdriver Spanner Step 1 Follow the 8.3 steps to remove the Convey assembly. Step 2 Utilize Spanner to loosen 4 Nuts. Turn Swing screw clockwise to tighten the belt. Turn Swing screw counterclockwise to loosen the belt.
  • Page 32 Disc it for Tickets (Twin Version) Manual 8.7 Sensor Replacement Instruction Before processing with assembly assure you have the following tools. Name Picture Phillips screwdriver Socket Step 1 Power off the machine. Utilize Phillips screwdriver to loosen 8 screws, washers and screw holders to remove Control panel plastic and Scoreboard decal.
  • Page 33 Disc it for Tickets (Twin Version) Manual 8.8 Monitor Replacement Instruction Before processing with assembly assure you have the following tools. Name Picture Phillips screwdriver Allen wrench Step 1 Power off the machine. Open Back upper door and Back bottom door. Utilize Allen wrench to loosen 8 screws to remove Back upper plate and Back middle plate.
  • Page 34 Disc it for Tickets (Twin Version) Manual Step 2 Utilize Phillips screwdriver to loosen 12 screws to remove 2 Monitor outer fixing plates. Monitor outer fixing plate. 11/15/2019...
  • Page 35 Disc it for Tickets (Twin Version) Manual Step 3 Utilize Phillips screwdriver to loosen 6 screws to remove 3 Monitor pressing plates. Utilize Phillips screwdriver to loosen 8 screws to remove 4 Monitor fixing plates. Remove Monitor. Replace with the new Monitor and install it in reversed order. Monitor fixing plate Monitor pressing plate...
  • Page 36 Disc it for Tickets (Twin Version) Manual 9. OVERALL CONSTRUCTION 9.1 Convey Assembly Part No. Code No. Name 1 D162-193-000 20211804A048 Driven sleeve 2 D162-192-000 20211804A047 Driven axle 3 D162-331-000 20106080316 Rod bearing 4 D162-188-001 20211804A043A Convey belt L side plate 5 D162-194-000 20211804A049 Washer 6 D162-330-000 20106000082...
  • Page 37 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 15 D162-196-000 20211804A051 Motor bracket 16 D162-402-000 23404000261 Motor 17 D162-187-001 20211804A042A Convey belt R side plate 18 D162-198-000 20211804A053 Al plate 19 D162-202-000 20211804A056 Hand protective plate 20 D162-200-001 20611804A017A Control panel light strip plastic1x2 21 D162-201-001 20211804A055A Control panel light strip plate 1x2 9.2 Frame Assembly...
  • Page 38 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 6 D162-203-001 20211804A027A R frame 7 D162-217-000 20211804A037 Marquee fixing plate 8 D162-207-001 20211804A031A Top net 9 D162-218-000 20211804A038 Back upper door lock cover 1x2 10 D162-401-000 25300171001 171 Lock 11 D162-216-001 20211804A036A Back upper door...
  • Page 39 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-138-000 20211804A007 Control panel bottom plate 1x2 2 D162-139-000 20611804A006 Control panel bottom plastic 1x2 3 D162-140-000 20611804A007 Control panel L bottom plastic 1x2 4 D162-135-000 20611804A004 Control panel R bottom plastic 1x2 5 D162-137-000 20211804A006 Control panel protect plate 1x2 6 D162-459-000 22301000002...
  • Page 40 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-162-000 20311804A028 Monitor support board 2 D162-161-001 20311804A027A Glass pressing board 3 D162-415-000 21202065001 65''touch screen 4 D162-176-001 20211804A020A Speaker net D162-169-000 20611804A010 Monitor R light strip plastic D162-170-000 20611804A011 Monitor L light strip plastic D162-171-000 20611804A012 Monitor bottom light strip plastic 1x2...
  • Page 41 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-121-000 20211804A002 Front cover 2 D162-120-000 20211804A001 Joint pin 3 D162-125-000 20311804A011 L side board 4 D162-124-000 20311804A010 R side board 5 D162-123-000 20211804A004 L middle side plate 1x2 6 D162-122-000 20211804A003 R middle side plate 1x2 9.6 Marquee Assembly Part No.
  • Page 42 Disc it for Tickets (Twin Version) Manual 9.7 Wooden Assembly Part No. Code No. Name 1 D162-153-000 20311804A023 Front board D162-177-000 20211804A021 Bottom lane R plate D162-178-000 20211804A022 Bottom lane L plate 3 D162-155-000 20311804A024 Bottom lane board 4 D162-150-000 20311804A020 L board 5 D162-159-000 20311804A005 Back upper door vertical plate2x2 6 D162-152-001 20311804A022A...
  • Page 43 Disc it for Tickets (Twin Version) Manual 9.8 Control Panel Wooden Case Part No. Code No. Name 1 D162-132-000 20311804A017 Front door 2 D162-130-000 20311804A015 Control panel front board 1x2 3 D162-128-000 20311804A013 Control panel L side board 1x2 4 D162-129-000 20311804A014 Control panel board 5 D162-131-000 20311804A016 Control panel back board 1x2 6 D162-127-000 20311804A012 Control panel R side board 1x2...
  • Page 44 Disc it for Tickets (Twin Version) Manual 9.9 Decals 11/15/2019...
  • Page 45 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-737-000 20511804A021 L side decal 1 2 D162-739-000 20511804A023 L side decal 2 3 D162-741-000 20511804A025 L side decal 3 4 D162-702-001 20511804B002A Bottom marquee decal 1 5 D162-720-000 20511804A005 Front cover decal 6 D162-718-000 20511804A007...
  • Page 46 Disc it for Tickets (Twin Version) Manual 11/15/2019...
  • Page 47 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-712-000 20511804A017 Counter decal 2 D162-733-000 25600000095A Service label(orange) 1x2 3 D162-728-000 25600000067A Service label(yellow) 1x2 4 D162-727-000 25600000042A Service label(green) 1x2 5 D162-726-000 25600000037 High voltage(large) 1x2 6 D162-725-000 25600000036 High voltage(small) 2x2 7 D162-706-000 20511804B006 110V nameplate(TUV) 2x2 8 D162-708-000 20511804B004...
  • Page 48 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-715-000 20511804A014 Wiring decal 2 D162-705-000 20511804B007 Following accessory decal1x2 11/15/2019...
  • Page 49 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-710-000 20511804A020 Installation instruction decal1x2 11/15/2019...
  • Page 50 Disc it for Tickets (Twin Version) Manual 9.10 Electrical Components 11/15/2019...
  • Page 51 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name D162-427-000 21602000117 Power supply D162-468-000 22140000029 Relay Fuse board(green D162-426-000 21714000148D holder) D162-433-000 21901000012 Fuse D162-434-000 21902000024 Fuse holder D162-413-000 21102000107 D162-472-000 26601090479 Mainboard D162-473-000 26601090480 Memory D162-474-000 26601090481 D162-475-000 26601090482...
  • Page 52 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name D162-419-000 23304000033 Cable D162-420-000 23304010034 Extend cable 7 D162-421-000 23303000001 Serial cable 8 D162-416-000 21107020036 Dongle 9 D162-417-000 41300000007 Recovery stick 10 D162-422-000 23305000003 Audio cable 11 D162-425-000 29790300009 Amplifier 12 D162-424-000 29790300007A U6 mainboard...
  • Page 53 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name 1 D162-478-000 26601101676 Chassis assembly of 65" monitor 1x2 2 D162-479-000 26601101677 Power board 3 D162-480-000 26601090487 Drive board 4 D162-481-000 26601090488 Key board Part No. Code No. Name 1 D162-446-000 21503000052 Sensor switch(send) 2x2 2 D162-447-000 21503000053 Sensor switch(receive) 2x2...
  • Page 54 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name D162-454-000 22003080028 5630 light(11.81in) D162-457-000 22003080035 5630 light(31.49in) D162-458-000 22003080037 5630 light(39.37in) D162-454-000 22003080028 5630 light(11.81in) D162-455-000 22003080031 5630 light(19.68in) D162-450-000 29741614004 Display D162-454-000 22003080028 5630 light(11.81in) D162-456-000 22003080034 5630 light(27.55in) D162-452-000 29741122003 Display 11/15/2019...
  • Page 55 Disc it for Tickets (Twin Version) Manual Part No. Code No. Name D162-454-000 22003080028 5630 light(11.81in) D162-456-000 22003080034 5630 light(27.55in) D162-451-000 29741112002 Display 5 D162-448-000 22002015021 BG5050RGB light strip 17.17in×4(0.45m×4) 6 D162-448-000 22002015021 BG5050RGB light strip 24.80in×4(0.63m×4) 7 D162-448-000 22002015021 BG5050RGB light strip 32.28in×4(0.82m×4) 8 D162-448-000 22002015021 BG5050RGB light strip 22.44in×4(0.57m×4) 9 D162-448-000 22002015021 BG5050RGB light strip 37.00in×2(0.94mx2) D162-463-000 22201000028 12V white light bracket...

  • Page 56: Wiring Diagram

    Disc it for Tickets (Twin Version) Manual 10. WIRING DIAGRAM Filter 11/15/2019...
  • Page 57 Disc it for Tickets (Twin Version) Manual 11/15/2019...
