INSTRUCTION MANUAL: SKU # 272-0941 PORTER SWIVEL ROCKER
CAUTION: Read all instructions before assembly. Failure to do so may result in faulty assembly and potential injury.
SPECIAL WARNINGS: Assemble on a soft, non-abrasive surface, such as carpet or cardboard to avoid damaging the item.
Note: Identify all parts in carton and compare against the parts list. Remove all protective material carefully. To prevent
scratching the surfaces, do not use a knife. If any parts are missing or damaged, contact Customer Service. DO NOT attempt
to assemble.
CLEANING & CARE: Clean surfaces with a dry or damp soft cloth. Do not use abrasive cleaners.
CUSTOMER SERVICE:
- 5 PM, Excluding US Holidays) or email patioparts@gmail.com.
For missing parts, please call toll free customer
service number for further assistance.
For questions, assistance or repair parts, please call toll free at: (877) 898-3958 (Mon-Fri, 9 AM
PARTS LIST
REF.
PARTS NAME
A
SEAT AND BACK
B
RIGHT ARMREST
C
LEFT ARMREST
D
DECORATIVE TUBE
E
SUPPORT TUBE
F
STEM BRACKET
G
BASE
H
M6 WASHER
I
M8 WASHER
J
M6*15mm HEX BOLT
K
M8*15mm HEX BOLT
L
M6*25mm HEX BOLT
M
M6 HEX BOLT CAP
N
M8 HEX BOLT CAP
O
WRENCH
P
SOCKET WRENCH
QTY
1
1
1
1
1
1
1
8
2
4
2
4
8
2
1
1
Advertisement
Related Manuals for Backyard Creations PORTER 272-0941
Summary of Contents for Backyard Creations PORTER 272-0941
- Page 1 INSTRUCTION MANUAL: SKU # 272-0941 PORTER SWIVEL ROCKER CAUTION: Read all instructions before assembly. Failure to do so may result in faulty assembly and potential injury. SPECIAL WARNINGS: Assemble on a soft, non-abrasive surface, such as carpet or cardboard to avoid damaging the item. Note: Identify all parts in carton and compare against the parts list.
- Page 2 ASSEMBLY INSTRUCTIONS STEP ONE: ATTACHING RIGHT ARMREST • Make sure to place the Seat and Back (A) of the chair on a non-abrasive surface to avoid product damage. • Attach the Right Armrest (B) to the Seat and Back (A) by using M6*25mm Hex Bolts (L) and M6 Washers (H).
- Page 3 STEP THREE: ATTACHING THE LEFT ARMREST • Left Armrest (C) end hole cover the Decorative Tube (D) end. Attach the Left Armrest (C) to the frame assembled in step two by using M6*25mm Hex Bolts (L) and M6 Washers (H). •...
- Page 4 Base (G) together. BACKYARD CREATIONS® MANUFACTURER‘S WARRANTY (Limited 1-Year Warranty) This product is covered under the manufacturer’s one year limited warranty against defects in workmanship and materials. If your product fails structurally during normal use within one year of purchase, the manufacturer will repair or replace the defective unit at no charge.
