This product
The fabric canopy top should never be left on during periods
of heavy or extended rain, snow/sleet or any other inclement
weather occurrence where high winds or wind
gusts can occur.
If
left on,
damage to the gazebo and surroundings can occur.
If you have questions or concerns, do not return to the store.
Please call
the toll-free number 833-807-3550 for assistance.
CAUTION
is NOT a permanent structure.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Backyard Creations 272-1175
Summary of Contents for Backyard Creations 272-1175
- Page 1 CAUTION This product is NOT a permanent structure. The fabric canopy top should never be left on during periods of heavy or extended rain, snow/sleet or any other inclement weather occurrence where high winds or wind gusts can occur. left on, damage to the gazebo and surroundings can occur.
- Page 2 Hanging Hooks for Flowers Double Roof for Better & Plants Ventilation ASSEMBLY INSTRUCTIONS Short side 10ft Long side 13ft SKU# 272-1175 ITEM# 184DGZ1-PU-25 MFG# LGCD0809A Durable Construction with Hanging Hooks for Flowers & Plants Inside Center Hanging Ring Double Roof for Better Ventilation...
-
Page 3: Safety Information
For your convenience, we have created this detailed printed assembly manual, and we have also added a new assembly video on our product page on the Menard’s website. Simply go to and search for Menards SKU 272-1175 (this is the NEW 13’x10’ Roof ®... -
Page 4: Parts List
PARTS LIST PART ILLUSTRATION DESCRIPTION QUANTITY Corner Post 4PCS Short Beam 2PCS Short Beam 2PCS Long Beam 2PCS Long Beam 2PCS 4PCS Short Corner Roof Tube Long Corner Roof Tube 4PCS 2PCS Middle Roof Tube 2PCS Middle Roof Tube Roof Hub 4PCS Post Base Bracket... - Page 5 STEP 1: CORNER POST AND PEDESTAL ASSEMBLY ① ③ ② 4PCS 4PCS M6mmX16mm 4PCS 12PCS For this and all subsequent steps, refer to the image below the page for how the assemblies should look like when done. 1) Attach Bracket K to the top of Corner Post A with Bolt #3. DO NOT FULLY TIGHTEN (PART K, #3 BOLT) UNTIL AFTER THE ROOF ASSEMBLY STEP IS COMPLETED ON PAGE 7.
-
Page 6: Step 2: Beam Assembly
STEP 2: BEAM ASSEMBLY 2PCS 2PCS 2PCS 2PCS M6mmX60mm 4PCS N+N1 1) Insert Short Beam B into Short Beam C. 2) Use Bolt/Nut#1 to secure Short Beam C and Short Beam B to form a complete short beam. 3) Repeat above procedures 1) and 2) to assemble the other short beam. 4) Insert Long Beam D into Long Beam E. - Page 7 STEP 3: MAIN UPPER FRAME ASSEMBLY 2PCS 2PCS M6mmX16mm 16PCS 1) Please have a free standing ladder ready for ease of assembly. 2) Use 2 Bolts #3 to attach the B side of the assembled Short Beams to the outside right Corner Post A and 2 Bolts #3 to attach the C side of the assembled Short Beams to the outside left Corner Post A.
-
Page 8: Step 4: Roof Assembly
STEP 4: ROOF ASSEMBLY 4PCS 4PCS M6mmX35mm 4PCS 1) Connect Short Corner Roof Tube F1 and Long Corner Roof Tube F2 to from one complete corner roof tube. Repeat this to form four complete corner roof tubes. 2) Please have a freestanding ladder ready at the center of the canopy gazebo. Hold the Roof Hub I in the air, letting receivers (H) face the long side of the gazebo while 3）... - Page 9 STEP 5: ROOF ASSEMBLY M6X16mm 4PCS 2PCS 2PCS 1) Snap in two Middle Roof Tubes G to the receivers (G) of the Roof Hub I. 2) Snap in two Middle Roof Tubes H to the remaining two receivers (H) of the Roof Hub I. 3) Secure the Middle Roof Tubes G to the Beams B using Bolts #3.
- Page 10 STEP 6: TOP CANOPY ASSEMBLY Fig. 6.2 Fig. 6.1 1. Gently place Main Canopy L2 over roof frame. Pull the canopy down to each corner until all Corner Roof Tubes fit well into the corner pockets on Canopy. (Fig. 6.1) Use the pockets in the middle of each side to cover each middle roof tube.
- Page 11 l) From the Tie Backs on the Mosquito Netting M, find the long side and short side of each panel. Attach the mosquito netting up from the inside of the garden house with hook and loop straps according M 4PCS to the long side and short side of frame.
-
Page 12: Customer Service
STEP 8: ANCHORING AND ACCESSORIES 8PCS 4PCS 4PCS 1) Carefully adjust the position of the canopy gazebo and make sure four posts are standing completely upright on level ground. Hammer two Post Anchors O through the holes on each post base into the ground.
