Summary of Contents for Backyard Creations 272-0833
- Page 2 Assembly Parts List Cross Bar Right Arm Connecting Bar Left Arm Back Table Right Leg Support Front Table Left Leg Support Suspension Bar Chair Seat Chair Back Table top Glider Bar Hardware List M6 Hex Wrench 15mm Screw M6 Wrench 25mm Screw M6 Bolt Cover 30mm Screw...
- Page 3 • Place 1(C)&1(D) with Part(H) between them as shown • Use 4 Bolt(O), 4 Washer(S) to assemble as shown • Place Bolt Cover(X) after tightening with Tool(V) • Repeat this step for next set of (C), (D) , & (H) •...
- Page 4 • Attach Chair Seat(E) & Chair Back(F) to Arm Frame( A/B), using bolt(P), Washer(S) • Tighten bolts using tool(V) • Place Bolt Cover(X) as shown • Repeat this step for other side • Attach Assembled Chair to the Glider Bar(G), using Bolt(R), Washer(S), Plastic Washer(U) and Nut(T) •...
- Page 5 • Attach Part J to Parts M as shown, DO NOT fasten with bolts at this point • Attach Parts M/J to Legs C/D, using bolt(Q) and Washer(S) • Tighten bolts using tool(V) • Place Bolt Cover(X) as shown...
- Page 6 • Attach Part(K) & (L) to Part(N) using Bolt(O) and Washer(S) • Hand tighten only at this time, place Bolt Cover(X) as shown • Attach table assembly to the top of the frame as shown using Bolt(Q), Washer(S) and tighten ALL bolts at this time •...
