INSTRUCTION MANUAL SKU#272-0618 CLASSIC OUTDOOR BENCH
CAUTION: Read all instructions before assembly. Failure to do so may result in faulty assembly and potential injury.
SPECIAL WARNINGS: Assemble on a soft, non-abrasive surface, such as carpet or cardboard to avoid damaging the item.
Noted: Identify all parts packed in carton against the parts list. Remove all the protective material carefully and DO NOT use
a knife to prevent scratching the surfaces. USE ONLY ON LEVEL SURFACES. INSPECT VISUALLY BEFORE EACH USE AND
ENSURE ALL HARDWARE IS PROPERLY TIGHTENED.
CUSTOMER SERVICE: For questions, assistance or repair parts, please call toll free at: 1-800-505-8305 (M-F
8:00am-8:00pm) or visit us on the web www.americancustomerservice.com 24 hours a day.
For missing parts, please call toll free
customer service number for further
assistance.
REF.
PARTS NAME
A
Right Leg
B
Left Leg
C
Back
D
Seat Slat
E
Side Brace
F
Seat Brace
G
M6*30mm Screw
H
M6*20mm Screw
I
M6*12mm Washer
J
M6*16mm Washer
K
M6 Nut
L
M5*15 Screw
M
Plastic Cap
PARTS LIST
PART#
53DU-A
53DU-B
53DU-C
53DU-D
53DU-E
53DU-F
53DU-G
53DU-H
53DU-I
53DU-J
53DU-K
53DU-L
53DU-M
QTY
1
1
1
5
2
1
14
2
14
2
16
7
4
