KYOWA EDX-2000A Simplified Instruction Manual

Memory recorder/analyzer
Hide thumbs Also See for EDX-2000A:

Advertisement

IM-A-571b June '04
MEMORY RECORDER/ANALYZER
EDX-2000A
Simplified Instruction Manual
For details, refer to the
Instruction Manual in
the attached CD-R.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDX-2000A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KYOWA EDX-2000A

  • Page 1 IM-A-571b June ‘04 MEMORY RECORDER/ANALYZER EDX-2000A Simplified Instruction Manual For details, refer to the Instruction Manual in the attached CD-R.
  • Page 2: Table Of Contents

    Contents 1. CONTROLS AND INDICATORS .............................1 1-1 FRONT......................................1 1-2 REAR......................................3 2. CONNECTING SENSORS..............................4 3. MAIN MENU ..................................6 4. MENU TREE OF EDX-2000A............................7 5. SIMPLIFIED OPERATIONS FROM POWER ON TO MEASUREMENT ..............8...
  • Page 3: Controls And Indicators

    Once you turn OFF the POWER switch, do not operate the POWER switch again until the power is shut OFF. Failure to observe these precautions may destroy the internal hard disk and cause the EDX-2000A not to start up once again.
  • Page 4 ● When mounting the EDX-2000A on the vehicle, always set it on the car seat and securely fix it a band and the like. Do not directly mount it on the vehicle chassis. Or unexpected vibration or impact may be applied to...
  • Page 5: Rear

    OFF. Once the POWER switch is turned OFF, do not operate the POWER switch again until the power is automatically shut OFF. Failure to observe these precautions may destroy the internal hard disk and cause the EDX-2000A not to start up once again. 10) GND terminal Always ground the GND terminal of the EDX-2000A.
  • Page 6: Connecting Sensors

    2. CONNECTING SENSORS This section explains how to connect sensors to the CDV-40A strain/voltage measurement card (hereinafter referred to as the CDV-40A). Use dedicated input cables (optional) for connecting sensors to the CDV-40A. The applicable input cables are shown in the following table.
  • Page 7 [2] When applying input voltage End of input cable BNC cable Input conversion adapter: FV-1A (Optional) -Input -Bridge excitation voltage +Input ACOM ID signal+ Input conversion adapter: FV-1A (Optional) ACOM and FG are common potentials.
  • Page 8: Main Menu

    3. MAIN MENU Power ON the EDX-2000A and the main menu appears. The main menu has 6 menu items, <Measurement>, <Conditions>, <ReproduceData>, <Analysis>, <Environment>, and <File Manage>. Select the required menu and move to the operating screen of the selected function. When the selected function is terminated, it returns to the main menu screen once again.
  • Page 9: Menu Tree Of Edx-2000A

    4. MENU TREE OF EDX-2000A Measurement Mode Environment Data Folder Sampling Prmtr Folder Auto-Range Data File Type Balance Overwrite Chk CAL ON/OFF Time Data File Option Unit BAL Standard Conditions Channel Cond Beep Meas Cond Over Beep Simlt Mode Volume...
  • Page 10: Simplified Operations From Power On To Measurement

    5. SIMPLIFIED OPERATIONS FROM POWER ON TO MEASURE- MENT This Chapter describes simplified operations of the EDX-2000A. By connecting a strain gage or strain gage transducer, the EDX-2000A is designed to set various channel and measuring conditions, conduct measurement, and record the measured data.
  • Page 11 Select menu items in due order. Set high pass filter. Set high pass filter. → 2) Conditions 0) OFF → 1) Channel Cond 1) 0.2 Hz 2) 1 Hz → 4) Hipass Filter When using high pass filter (input AC coupling), select 0.2 or 1 Hz and press [ENTER] key.
  • Page 12 Select menu items in due order. Set CAL range. Set CAL range. → 2) Conditions 0) 100 % 1) 50 % → 1) Channel Cond 2) SHUNT → 8) CAL Range Set calibration range of the target channel. Select the appropriate item and press [ENTER] key to determine the setting.
  • Page 13 Select menu items in due order. Select measuring mode. Select measuring mode → 2) Conditions Set the appropriate measuring mode such as manual mode, 0) Manual → 2) Meas Cond trigger mode, etc. for 1) Manual measurement of recorded data. (Set the →...
  • Page 14 Then, the above menu appears to allow you to confirm the recorded data of all channels. Change the load and repeat operations in the above item 18. To start the measurement with no-load state, operate the EDX-2000A from item 17.
