4. Material
This section shows the CTT instruments and their accessories.
Item Part number
1 CTTx5
2 CTTx2
3 CTT-VX2
CTT-VX5
4
CTT-VX5-35S
CTT-VH1
CTT-VH1-50
5
CTT-VH1-35s
CTT-VH1-50s
6 CTT-BURDEN
7 NDB-GND-P
C T T S e r i e s
Description
Five tap current transformer tester.
Configured for either 120V or 240V
(cannot be changed).
Two tap current transformer tester.
Configured for either 120V or 240V
(cannot be changed).
Two tap secondary lead.
For CTTx2 only.
Standard secondary lead 6m (20ft)
Shielded secondary lead 10.6m (35ft)
For CTTx5 only.
Standard VH1 cable 10.6m (35ft)
Standard VH1 cable 15.2m (50ft)
Shielded VH1 cable 10.6m (35ft)
Shielded VH1 cable 15.2m (50ft)
Burden test lead 5.5m (18ft)
Ground cable 4.5m (15ft)
- U s e r M a n u a l
Illustration
