Parker C3S063V2 F10 I11 T30 M00 Compax3 Servo Drive In Stock Qty Available: 1 Used and in Excellent Condition Open Web Page https://www.artisantg.com/65276-13 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
Page 2
Electromechanical Automation Startup of a motor without load START UP 192-120112 N2 C3 Start Up November 2006 Release R05-2 as from firmware V3.20 and Hardware CTP17 We reserve the right to make technical changes. 07.11.06 14:49 192-120112N02 C3 Start Up November 2006 The data correspond to the current status at the time of printing.
Page 3
Poole, Dorset BH17 7FJ UK Tel.: +44 (0)1202606300 Fax: +44 (0)1202 606301 E-mail: sales.digiplan@parker.com mailto:sales.digiplan@parker.com Internet: www.parker-eme.com http://www.parker-eme.com Italy: Parker Hannifin S. p. A Electromechanical Automation Via Gounod 1 I-20092 Cinisello Balsamo (MI), Italy Tel.: +39 (0)266012459 Fax: +39 (0)2660 12808 E-mail: sales.sbc@parker.com mailto:sales.sbc@parker.com...
Parker EME START UP 1. START UP Contents In this chapter you can read about: Aim of this manual ...........................4 Preparation ..............................5 Configuring Compax3..........................10 Compax3 Setup.............................14 1. START UP ....................3 Aim of this manual ................... 4 1.1.1. Task: Setting up Compax3 , moving the motor..........4 1.1.2.
START UP START UP Aim of this manual In this chapter you can read about: Task: Setting up Compax3, moving the motor..................4 Required components..........................4 Described below is the setup of a motor without load. Please note the safety instructions in the Compax3 installation manual This manual applies to the following devices: Compax3SxxxVx + supplement Compax3HxxxV4 + supplement...
Parker EME START UP Preparation In this chapter you can read about: Installation of the C3 ServoManager...................... 5 Required wiring ............................6 1.2.1. Installation of the C3 ServoManager The Compax3 ServoManager can be installed directly from the Compax3 CD. Click on the appropriate hyperlink or start the installation program "C3Mgr_Setup_V..
START UP START UP 1.2.2. Required wirings Connections of Compax3S For V2 devices (single For V2 device (three phase) phase) X1: 230VAC/240VAC X1: 230VAC/240VAC For V4 device (three phase) Pin1 = L X1: 400VAC/480VAC Pin2 = N Pin1 = L1 Pin3 = PE Pin2 = L2 Pin3 = L3...
Page 8
Apply 24VDC control voltage to X4/1 and X4/2. Apply 24VDC to enable input X4/3. Connect Compax3 to PC, Connect Compax3 X10 to PC (COM1 or COM2) via RS232 cable (Parker cable SSK1) . Connect motor to Compax3. Connect motor cable (Parker cable MOK..) to X3 (see connections of Compax3S).
Page 9
START UP START UP Power connections Hint The positions (1) and (2) are only relevant for the later operation. (1): Connection of braking resistor (2): Connection of external supply of the ventilator fan for C3H1xxV4 Controller front plate 24VDC RS232/RS485 The RS232 programming interface under the upper dummy cover is only available if the X10 jumper at the controller is fitted.
Page 10
Connect Compax3 to PC, Connect Compax3 from the programming interface via the adapter cable and the RS232 cable (Parker SSK1 cable) to PC (COM1 or COM2). Connect motor to Compax3. Connect motor cable to M1, M2, M3 (see connections of Compax3H).
START UP START UP Configuring Compax3 Call up C3 ServoManager. 1.3.1. Set interface PC - Compax3 Select the PC interface via which you established the RS232 connection (Connection via SSK01). Menu Options: Open COMPort 1.3.2. Set Compax3 device type In order to define the device type connected, go to device selection, Online device identification in the tree.
Parker EME START UP 1.3.3. Configuration sequence Select the entry "Ixx Configuration" from the tree. Click on the "Start complete configuration" button to start the configuration of Compax3. 192-120112N02 C3 Start Up November 2006 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 13
START UP START UP Select the connected motor (see on the motor type designation plate) Confirm the settings with the "Next" button. All following configuration windows contain suitable standard values. Therefore they can be acknowledged with “Next” without further entry, until you reach the summary window.
Parker EME START UP 1.3.3.1 Download configuration In the summary window you can name your configuration file and enter a comment. Activate the control square "Call up Download dialog". Start the download by clicking on the "Finish" button. Acknowledge the next window with the "disable controller and begin drive configuration"...
START UP START UP Caution! This query is only relevant if the device was energized before. Click on the "No", button to close the window. Setting up Compax3 Select the entry "Optimization" in the tree. Open the optimization window by clicking on the "Click to Open “Optimization Tool"...
START UP START UP 1.4.2. Set-Up In this chapter you can read about: Define test motion parameters ......................17 Execute test motion ..........................19 Display of the values in the oscilloscope and in the status display............. 21 Activate setup Click on the "Enter test move parameters" button in the setup window (next picture below).
Parker EME START UP 1.4.2.1 Define test motion parameters In this window you can select a test motion profile. All values entered in the „general setup settings“ and in „test motions“ are only suggestions, which can be accepted or adapted if necessary.
Page 19
START UP START UP Motion profiles You can choose between 2 test motion profiles. Select a relative test movement: Relative movement (test movement 1) Absolute movement (test movement 2) You can also choose an absolute test movement, then you must, however, define a machine zero point.
Parker EME START UP 1.4.2.2 Execute test movements <1> activating the setup mode. The function buttons are enabled. If no error is present, the green LED on the Compax3 is flashing. If this is not the case, an error is still pending on Compax3; the red LED lights Check for correct voltage supply as well as enable of the enable input on X4/3.
Page 21
START UP START UP Description of additional buttons: <5>approach machine zero. <6>Hand -, moving in negative direction. <7>Hand +, moving in positive direction. <8>Activate resp. enable motor holding brake (if available). <9>Quit, acknowledging the error after its elimination. <10>Activate additional inputs/outputs (available as an option). 192-120112N02 C3 Start Up November 2006 Artisan Technology Group - Quality Instrumentation ...
Page 22
Parker EME START UP 1.4.2.3 Display of the values in the oscilloscope and in the status display Window 1: Depiction of the status values in the oscilloscope (can be started by clicking on the "RUN" button in the oscilloscope settings)
Index START UP 2. Index Accept input • 18 Aim of this manual • 4 Components required • 4 Configuration sequence • 11 Configuring Compax3 • 10 Define test motion parameters • 17 Display of the values in the oscilloscope and in the status display •...
Page 24
Electromechanical Automation Inbetriebnahme eines leerlaufenden Motors START UP 190-120112 N2 C3 Start Up November 2006 Release R05-2 - ab Firmware V3.20 und Hardware CTP17 Technische Änderungen vorbehalten. 06.11.06 12:30 190-120112 N2 C3 Start Up November 2006 Daten entsprechen dem technischen Stand zum Zeitpunkt der Drucklegung. Artisan Technology Group - Quality Instrumentation ...
Page 25
Poole, Dorset BH17 7FJ UK Tel.: +44 (0)1202 606300 Fax: +44 (0)1202 606301 E-mail: sales.digiplan@parker.com mailto:sales.digiplan@parker.com Internet: www.parker-eme.com http://www.parker-eme.com Italien: Parker Hannifin S. p. A Electromechanical Automation Via Gounod 1 I-20092 Cinisello Balsamo (MI), Italy Tel.: +39 (0)2660 12459 Fax: +39 (0)2660 12808 E-mail: sales.sbc@parker.com mailto:sales.sbc@parker.com...
Page 26
Parker EME START UP 1. START UP Inhalt In diesem Kapitel finden Sie Ziel dieser Anleitung..........................4 Vorbereitung ............................5 Compax3 konfigurieren .........................10 Compax3 inbetriebnehmen ........................14 1. START UP ....................3 Ziel dieser Anleitung................4 1.1.1. Aufgabe: Compax3 Inbetriebnehmen, Motor bewegen ........4 1.1.2.
START UP START UP Ziel dieser Anleitung In diesem Kapitel finden Sie Aufgabe: Compax3 Inbetriebnehmen, Motor bewegen................. 4 Erforderliche Komponenten........................4 Beschrieben wird die Inbetriebnahme eines leerlaufenden Motors (Motor ohne Last). Beachten Sie die Sicherheitshinweise im Installations - Handbuch Compax3 Diese Anleitung gilt für folgende Geräte: Compax3SxxxVx + Ergänzung Compax3HxxxV4 + Ergänzung...
Parker EME START UP Vorbereitung In diesem Kapitel finden Sie Installation des C3 ServoManagers ....................... 5 Notwendige Verdrahtungen........................6 1.2.1. Installation des C3 ServoManagers Der Compax3 ServoManager kann direkt von der Compax3-CD installiert werden. Klicken Sie auf den entsprechenden Hyperlink bzw. starten Sie das Installationsprogram "C3Mgr_Setup_V..
Page 29
START UP START UP 1.2.2. Notwendige Verdrahtungen Anschlüsse Compax3S Bei V2 Gerät (einphasig) Bei V2 Gerät (dreiphasig) X1: 230VAC/240VAC X1: 230VAC/240VAC Pin1 = L Bei V4 Gerät (dreiphasig) Pin2 = N X1: 400VAC/480VAC Pin3 = PE Pin1 = L1 Pin2 = L2 Pin3 = L3 Pin4 = PE X3: Motor...
Page 30
24VDC Steuerspannung an X4/1 und X4/2 anschließen. Freigabe - Eingang X4/3 mit 24VDC belegen. Compax3 mit PC verbinden, Compax3 X10 über RS232-Kabel (Parker - Kabel SSK1) mit PC (COM1 oder COM2) verbinden. Motor an Compax3 anschließen. Motorkabel (Parker - Kabel MOK..) an X3 anschließen (siehe Anschlüsse Compax3S).
Page 31
START UP START UP Leistungsanschlüsse Hinweis Die Positionen (1) und (2) sind erst für den späteren Betrieb relevant. (1): Anschluss Ballastwiderstand (2): Anschluss externe Versorgung des Lüfters bei C3H1xxV4 Frontplatte der Steuerung 24VDC RS232/RS485 Die RS232 Programmierschnittstelle unter der oberen Blindabdeckung ist nur verfügbar, wenn die Brücke (an X10) auf der Steuerung bestückt ist.
Page 32
24VDC Steuerspannung an X4/2 (GND24V) und X4/3 (+24VDC) anschließen. Compax3 mit PC verbinden, Compax3 von der Programmierschnittstelle über das Adapterkabel und RS232- Kabel (Parker - Kabel SSK1) mit PC (COM1 oder COM2) verbinden. Motor an Compax3 anschließen. Motorkabel an M1, M2, M3 anschließen (siehe Anschlüsse Compax3H).
START UP START UP Compax3 konfigurieren C3 ServoManager aufrufen. 1.3.1. Schnittstelle PC - Compax3 einstellen Wählen Sie die PC - Schnittstelle über die Sie die RS232 - Verbindung hergestellt haben (Verbindung über SSK01). Menü Optionen: COMPort öffnen 1.3.2. Compax3 Gerätetyp einstellen Um den angeschlossenen Gerätetyp zu definieren, wählen Sie im Verzeichnisbaum Geräteauswahl, Online Geräteidentifikation.
Parker EME START UP 1.3.3. Konfigurationsablauf Wählen Sie in der Baumstruktur den Eintrag "Ixx Konfiguration" aus. Starten Sie durch einen Klick auf den Button "Start Komplettkonfiguration" die Konfiguration von Compax3. 190-120112 N2 C3 Start Up November 2006 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
Page 35
START UP START UP Wählen Sie den angeschlossenen Motor aus (Angaben auf Motortypenschild beachten). Bestätigen Sie die Angaben mit dem Button "Weiter". Alle folgenden Konfigurationsfenster enthalten passende Standardwerte. Deshalb können Sie mit "Weiter" ohne Eingaben bestätigen werden, bis Sie zum Fenster Zusammenfassung gelangen.
Parker EME START UP 1.3.3.1 Download Konfiguration Im Fenster Zusammenfassung haben Sie die Möglichkeit Ihre Konfigurationsdatei zu benennen und einen Kommentar hinzuzufügen. Aktivieren Sie das Kontrollkästchen "Download-Dialog aufrufen". Starten Sie den Download mit dem Button "Fertig stellen". Bestätigen Sie das nächste Fenster mit dem Button "Regler freischalten und Start Download Konfiguration".
START UP START UP Achtung! Diese Abfrage ist nur relevant wenn das Gerät vorher bestromt war. Betätigen Sie den Button "Nein", um das Fenster zu schliessen. Compax3 inbetriebnehmen Wählen Sie in der Baumstruktur den Eintrag "Optimierung" aus. Starten Sie durch einen Klick auf den Button "Start Optimierung" das Optimierung - Fenster.
START UP START UP 1.4.2. Inbetriebnahme In diesem Kapitel finden Sie Testbewegungs - Parameter festlegen ....................17 Testbewegungen ausführen ......................... 19 Darstellung der Werte auf Oszi und in der Statusanzeige ..............21 Inbetriebnahme aktivieren Betätigen Sie den Button "Testbewegungsparameter eingeben" im Fenster Inbetriebnahme (nächstes Bild rechts unten).
Parker EME START UP 1.4.2.1 Testbewegungs - Parameter festlegen Im diesem Fenster haben Sie die Möglichkeit ein Testbewegungsprofil auszuwählen. Alle eingestellten Werte der "Allgemeinen Inbetriebnahme Einstellungen" und der "Testbewegungen" sind Vorschlagswerte und können übernommen oder bei Bedarf angepasst werden. Mit dem Button "Defaultwerte für Oszi setzen" aktivieren Sie Voreinstellungen für das Oszilloskop (siehe Bild unten <11>).
Page 41
START UP START UP Bewegungsprofile Es stehen 2 Test-Bewegungsprofile zur Auswahl. Wählen Sie eine relative Testbewegung: Relative Bewegung (Testbewegung 1) Absolute Bewegung (Testbewegung 2) Sie haben ebenso die Möglichkeit eine absolute Testbewegung zu wählen, in diesen Fall ist es jedoch erforderlich einen Maschinennull zu definieren. Eingaben übernehmen Drücken Sie den Button "Eingaben übernehmen"...
Parker EME START UP 1.4.2.2 Testbewegungen ausführen <1> Aktivieren des Inbetriebnahme-Modus. Die Funktions - Buttons werden freigegeben. Falls kein Fehler ansteht blickt die grüne LED an Compax3. Ansonsten steht an Compax3 ein Fehler an; die rote LED leuchtet. Prüfen Sie auf korrekte Spannungsversorgung, sowie auf Freigabe des Enable - Eingangs an X4/3.
Page 43
START UP START UP Beschreibung weiterer Buttons: <5>Maschinen-Null anfahren. <6>Hand -, fahren in negative Richtung. <7>Hand +, fahren in positive Richtung. <8>Motorhaltebremse aktivieren bzw. freigeben (falls vorhanden). <9>Quit, quittieren der Störung nach der Fehlerbehebung. <10>Zusätzliche Ein/Ausgänge aktivieren (als Option verfügbar). 190-120112 N2 C3 Start Up November 2006 Artisan Technology Group - Quality Instrumentation ...
Parker EME START UP 1.4.2.3 Darstellung der Werte auf Oszi und in der Statusanzeige Fenster 1: Darstellung der Statuswerte auf dem Oszilloskop (starten durch "RUN" in den Oszilloskop - Einstellungen) Fenster 2: Oszilloskop-Einstellungen Fenster 3: Zyklische Anzeige von Statuswerten Fenster 4:...
Index START UP 2. Index Aufgabe Compax3 Inbetriebnehmen, Motor bewegen • Bewegungsprofile • 18 Compax3 Gerätetyp einstellen • 11 Compax3 inbetriebnehmen • 15 Compax3 konfigurieren • 11 Darstellung der Werte auf Oszi und in der Statusanzeige • 22 Download Konfiguration • 14 Eingaben übernehmen •...
