Summary of Contents for Parker ORIGA P120 Series
- Page 1 Assembly Instructions: Series P120, Series P210, and Series 2000...
- Page 2 Assembly Instructions Series P120 Ø 40-80mm Series 2000 and Series P210 Ø 16 Ø 10mm...
- Page 3 Assembly Instructions (Series P120, Series P210, Series 2000) Series P210 and Series 2000...
- Page 4 Assembly Instructions...
- Page 5 Assembly Instructions...
- Page 6 THE NEW R EV ISED 2000 R ODL ESS V ER SION In the spirit of continuous improvement, Parker ORIGA Corporation has upgraded its 2000 series Rodless cylinder. Current customers needing the old version 2000 repaired, rebuilt or remanufactured will need the following information.
- Page 7 FIGURE 2 Were there any changes to the dimensions for the piston mounts NR25, NR30 and NR35? The catalog dimensions did not change. Were there any changes to the dimensions for the cylinder mounts NR4, NR7 and NR8? The catalog dimensions did not change. Did the maximum loads and maximum moments change as reflected in the catalog? No, they did not.
- Page 8 10 7 15 16 8 20 24 NOTE: FOR 25mm ONLY, ITEMS 23, 26 & 28 ARE AN INTEGRAL PART OF THE CAP (ITEMS 17 & 18) FIGURE 3...
-
Page 9: Upgrade Kits
UPGRADE KITS How do I rebuild my old 2000 series cylinder and at the same time upgrade it to the 2000-revised version? An “Upgrade Kit” will now be required to repair a Series 2000 cylinder out in the field. An “Upgrade Kit” will consist of a piston assembly, end cap assembly, piston mount assembly and service pack. - Page 10 Did the switches (Hall Effect and Reed) change? Yes, it did. The switches used on the revised 2000 cylinders will now be the same switches that are used in our OSP-P line of cylinders. It’s worth noting that these switches are more compact. See Figure 4 on how this switch is attached to the barrel.
- Page 11 SWITCH KIT ASSEMBLY FOR 2000 SERIES CYLINDER 1) Choose which of the available barrel sides you want to mount your switch. Assemble one bracket with its two “claws” going inside the barrel groove as shown above. 2) Assemble the second bracket facing opposite the first, with one leg going in between the legs of the first bracket as shown above.
- Page 12 Will the P120 series Rodless cylinders still be available? The P120 Series cylinders haven’t changed and are still available. Revised OSP-P 2000 Series Series 2000 Series FIGURE 5: Pictorial contrast of current and old line of Rodless cylinders...
- Page 14 REVISED 2000 SERIES (25mm to 50mm) 10 7 15 16 8 20 24 NOTE: FOR 25mm ONLY, ITEMS 23, 26 & 28 ARE AN INTEGRAL PART OF THE CAP (ITEMS 17 & 18) NOTE: FOR 25m m ONLY, ITEMS 23, 26 & 28 ARE AN INTEGRAL PART OF T HE CAP (ITEMS 17 &...
- Page 15 Parts are supplied Item Description in the following kit Barrel Purchase separate Magnet strip Purchase separate Inner band Service pack Outer band Service pack Piston mount screw Piston mount kit Outer bandlock screw End cap assembly Piston Piston assembly kit Support ring (white, red, green) Piston assembly kit Slide shoe (yellow, tan, black)
- Page 16 Typified by ideally matched materials and fully developed design The support ring should have minimum play, but should still offer details, Parker ORIGA cylinders have a very long operational life. free movement inside the barrel. However, the service life may be reduced by extreme and demanding 2.
- Page 17 without the piston seal, should be inserted into the barrel first. Slide Outer Band: the piston all the way to one end of the barrel. The piston should 1. Outer Band: lay the outer band (item #4) across the top of the be positioned so that it sticks out past the end of the barrel.
-
Page 18: Part Numbers
Part Numbers Series 2000 Designation Bore Sizes Series 2000 10mm 16mm 25mm 32mm* 40mm 50mm** Part Number SP10-B-1 SP16-B-1 SP25R-B-1 SP32R-B-1 SP40R-B-1 SP50R-B-1 Buna-N Service Pack Single Piston Part Number SP10-V-1 SP16-V-1 SP25R-V-1 SP32R-V-1 SP40R-V-1 SP50R-V-1 Viton Service Pack Single Piston Part Number SP10-B-2 SP16-B-2... -
Page 19: Ordering Information
Ordering Information Series 2000 Series P120 SP32R-B-1 X S SP124-B-S X S Service Pack Service Pack Bore Size=10, 16, 25, Bore Size: 124=40mm, 32, 40, 50 126=63mm, 128=80mm (R = Revised Series) B= Buna-N, V= Viton B= Buna-N, V= Viton 1= Single Piston S= Short Piston 2= Double Piston... - Page 20 Parker ORIGA CORPORATION • 100 West Lake Drive, Glendale Heights, IL 60139 • tel (630) 871-8300 • fax (630) 871-1515 Internet: http://www.parkeroriga.com Z320-05/08...
